Transcend USB 3.0 Dual Expansion Card PCI Express Interface Model TS-PDU3

  • PCI to USB Card
  • Up to 5.0 Gbps Data Transfer Rate
IronEgg
BUY WITH CONFIDENCE
This product qualifies for the Iron Egg guarantee. We'll match any qualifying competitor's price.
  • Email this page
ICON Loading...
TS-PDU3TS-PDU3

Transcend USB 3.0 Dual Expansion Card PCI Express Interface
Model TS-PDU3

TS-PDU3

If you are not ready yet to switch out your motherboard, Transcend's USB 3.0 Expansion Card will allow you an opportunity to reap the benefits of USB 3.0 transfer speeds. This easy-to-install card enables you to add revolutionary new USB 3.0 ports to any desktop computer with a PCI Express slot, delivering data transfer rates up to 10 times faster than Hi-Speed USB (USB 2.0) with optimized power efficiency.

The Expansion Card's PCI Express 2.0 connection interface is compatible with virtually all current motherboards, and guarantees unrestricted two-way communication between your PC and any USB devices you plug into the card. With two SuperSpeed USB 3.0 ports, which have bandwidth up to 5Gbps, Transcend's USB 3.0 Expansion Card is ideal for use with new USB 3.0 high-capacity external storage devices, such as external hard drives and USB flash drives.

TS-PDU3

Key Features

  • Up to 10X faster than USB 2.0
  • Simultaneous bi-directional data transfer
  • Provides more power than USB 2.0
Features
TS-PDU3
  • Add USB 3.0 ports to any desktop computer with a PCI Express slot
  • Connection bandwidth up to 5Gbits per second (in USB 3.0 mode)
  • Ultra-fast PCI Express interface eliminates speed bottlenecks
  • Installs easily in single PCIe slot
  • Backwards compatible with USB 2.0 and USB 1.1 devices
  • Supports PCI bus power management interface rev. 1.2
  • Compact size saves space and inside your PC
  • Fully compatible with PCI Express 2.0
  • Two external USB 3.0 ports
  • xHCI compliant
  • Two-year limited warranty

Specifications
TS-PDU3
Dimensions (PCB size) 65mm (L) × 63mm (W)
Weight 1.5lbs (44g)
USB Bus Power Output 5DCV, 900mA (max) per port
PC Interface PCI Express 2.0 single lane (x1)
USB Ports 2 external (supports USB 1.1 / 2.0 / 3.0)
Connection Bandwidth Up to 5Gbits per second
Operating Temperature 41 - 95°F (5 - 35°C)
Operating System Supported Windows 7, Vista, XP
Certificates CE, FCC, BSMI
*Note A 4-pin or 15-pin power cable must be connected from your PC’s power supply to the USB 3.0 Expansion Card when a USB-powered device is used.

System Requirements
Desktop computer with a working PCI-Express slot. One of following Operating Systems:
  • Windows XP
  • Windows Vista
  • Windows 7
  • Windows 8
Note: Internet access to download the device driver

Learn more about the Transcend TS-PDU3

Model

Brand
Transcend
Model
TS-PDU3

Spec

Type
PCI to USB Card
External USB Ports
2x USB Ports
Data Transfer Rate
Up to 5.0 Gbps
Operating Systems Supported
Windows 7, Vista, XP
Specifications
USB Bus Power Output: 5V DC, 900mA (max) per port

PC Interface: PCI Express 2.0 single lane (x1)

Features

Features
Add USB 3.0 ports to any desktop computer with a PCI Express slot

Connection bandwidth up to 5Gbits per second (in USB 3.0 mode)

Ultra-fast PCI Express interface eliminates speed bottlenecks

Installs easily in PCIe x1 slot

Backwards compatible with USB 2.0 and USB 1.1 devices

Supports PCI bus power management interface rev. 1.2

Compact size saves space and inside your PC

Fully compatible with PCI Express 2.0

Two external USB 3.0 ports

xHCI compliant

Quick Info


Customer Reviews of the Transcend TS-PDU3

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • Frank C.
  • 10/10/2014 6:51:14 AM
  • Tech Level: High
  • Ownership: more than 1 year
  • Verified Owner

2 out of 5 eggsWon't stay IN the PCIx slot!

Pros: Allows you to have SuperSpeed USB 3.0 connections.

Cons: Will not stay seated in the PCI-e 1x lane expansion slot, even though it is mounted to the case. It works its way out of the slot, and loses connection to whatever is plugged into it. In my case, two external drives. Very annoying to have to shut down, open the case, reseat, close the case, and restart, just to be able to access data on those external drives. This happens at least once per week. It is a tower, standing upright, and the card is parallel to the floor. If the case were on its side, or if this was a pizza box type case where the card was sitting down in the mobo, might not be a problem.

0 out of 1 people found this review helpful. Did you? Yes No

  • Everett R.
  • 8/7/2014 3:16:33 AM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsdoes what it is supposed to do

Pros: needed usb 3 for speed and this gave me the speed over usb2

Cons: none

Did you find this review helpful? Yes No

  • William N.
  • 5/21/2014 7:31:55 PM
  • Tech Level: Somewhat High
  • Ownership: less than 1 day
  • Verified Owner

4 out of 5 eggsWorks

Pros: Get the drivers right and it works.
Tech support is prompt and courteous.
Price.

Cons: Unclear as to which driver to install.

Other Thoughts: Not sure I needed USB 3.0. I bought this along with a Transcend (TS-RDF5K) card reader to read my class 10 SD cards. The card reader ran almost as fast on USB 2 as it did on USB 3. This is likely a limit of my SD cards. The new card reader blew the doors off my old card reader when both were on USB 2.
Not sorry I made the purchase. Good price and now I have USB 3. Next SD cards I buy will probably be faster.

Did you find this review helpful? Yes No

  • Hailton D.
  • 4/18/2014 4:27:34 PM
  • Tech Level: Somewhat High
  • Ownership: 1 day to 1 week
  • Verified Owner

1 out of 5 eggsWorked for only a few minutes..

Pros: None.. It did not work for me at all.. I think I got a bad one.. the reviews seems nice enough, so I ordered this one, but not happy... tried everything but it still windows 7 64 bit would not install properly.. It may be that I got a bad board.. also there were no drivers had to look in website manufacturer. I also didn't forget to plug in the power and tried one at a time, no work,, even with the correct driver from the website.. Shame.

Cons: everything, since it didn't work and I might have got a bad board, who knows? ether that or it would work on a windows 8 system.. but not on my windows7 .

Did you find this review helpful? Yes No

  • Matthew f.
  • 1/19/2014 1:06:45 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

4 out of 5 eggsbuy

Pros: FAST
for when you don't have a usb 3.0 board and need an extra card it helps out so much.

Cons: need a molex connector which isn't an issue just annoying when your trying to go for a clean build.

Did you find this review helpful? Yes No

  • Frank C.
  • 1/3/2014 7:55:00 AM
  • Tech Level: High
  • Ownership: less than 1 day
  • Verified Owner

5 out of 5 eggsCheap way to add USB 3.0

Pros: Provides 2 USB 3.0 connectors to your system, and uses 1 pci-express 1.0 slot. Fast transfer speeds, easy to install.

Cons: Requires a molex connector. Drivers must be downloaded from the mfr. website.

Other Thoughts: My system has eSATA, but no USB 3.0, so I bought this to support a new VANTEC NST-380SU3-BK USB3/eSATA hard drive enclosure. At this price, and the price of the enclosure, it would be crazy to pass this up. Was up and running in about 5 minutes.

Did you find this review helpful? Yes No

  • Eric M.
  • 10/16/2013 8:50:44 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsSo far so good

Pros: Works fine, 3.0 speeds. SATA and Molex PSU connections.

Cons: none

Other Thoughts: Make sure you have an extra cable that can reach from the PSU. Some DELL users may need to re-configure their HD location so as to have a connection that can reach the card. Make sure not to plug in both PSU connections.

Did you find this review helpful? Yes No

  • CURTIS T.
  • 9/8/2013 7:29:27 AM
  • Tech Level: High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsEasy Install

Pros: Works as advertised. I get at least a 50% boost in the read and write numbers from USB 2.0.

Cons: None.

Other Thoughts: You have to go to the Transend website to download the latest drivers.

1 out of 1 people found this review helpful. Did you? Yes No
