General

Brand

Wilson Electronics

Model

841262

Type

Amplifier

Specification

Specifications

Frequency: 824-894 MHz / 1850-1990 MHz

Gain: 62 dB / 62 dB

Max Output Power: 2.5 watts

Max RF (up/down): 34 dBm / 15.7 dBm

Noise Figure: 3.5 dB nominal

Flatness: ±5 dB

Isolation: > 90 dB

Power Requirements: 120-240 V AC, 50-60 Hz, 8 W max

Connectors: F-Female

Dimensions: 6.2" x 4.2" x 1.5"

Weight: 0.64 lbs.

Feature

Features

Complete package - everything you need is in the box

Wireless operation - no connection to cell phone or data card

Works in any inside location where improved cellular signal is needed: homes, offices, buildings

Power control logic ensures maximum output power is within cellular standards

Works wirelessly with multiple cell phones and data cards simultaneously

Works on all generations of CDMA, TDMA and GSM

FCC and IC type accepted

Significantly improves voice and data quality

Greatly reduces disconnects and drop-outs

Multiple cell phones and data cards can be amplified simultaneously

Significantly improves voice and data signal quality

Increases data communication rates needed for 3G technologies

Receives and transmits better than your cell phone

Designed for use with standard TV cable common in many homes

Extends cell phone battery life

Easy to install and use, and it's affordable

Package Contents: Wilson SIGNALBOOST DB Pro Cellular Signal Amplifier, 75 Ohm Omni Outside Antenna, Wall Mount Inside Panel Antenna, 20' White RG6 Coax, 30' White RG6 Coax, 50' White RG6 Coax
