In Win open-frame chassis with a unique one-piece construction design concept combining unconventional craftsmanship techniques to create an impeccable artistry. The new gold and black design with detailed aluminum brushed hairline texture made new S-Frame truly luxurious and exquisite.
Using laser cutting machine processing to cut 4mm thick aluminum sheet metal into a 2 meter long chassis structure the In Win S-Frame is made using complete one piece metal with CNC polishing processes. The dual anodize procedures not only increased the resistance of the aluminum surface but also features a dual color presentation to give maximized visual enhancement.
Finally, the main structure of S-Frame was bent through 15 times in order to create every bending angle smooth and seamless. These processes also created a beautiful texture of brushed hairline sliding along S-Frames curves.
S-Frame's simplistic aesthetics required a selection of delicate techniques to accomplish the uniqueness, strength and perfect artistry enjoyed as the S-Frame becomes available …
Material | 4mm Aluminum, Tempered Glass |
Internal Drive Bay | 3.5" or 2.5" x 4 |
M/B Form Factor | ATX / Micro-ATX |
Power Supply | ATX12V, PSII and EPS Power Supply Mounting Area Length up to 300mm / Height up to 95mm |
I/O Port | USB3.0 x 4, HD Audio |
I/O Expansion Slots | PCI-E Slot x 8 Supports High-end Graphic Card (Length: up to 340mm, Height: up to 160mm) |
Thermal Solution | Supports - 120mm Bottom Fan x 3 - 360mm Liquid Cooling Radiator (width up to 135mm) - CPU heatsink up to 195mm |
Dimensions (H x W x D) | 560 x 313 x 755mm, 22" x 12.3" x 29.7" |
Net Weight | 17.41kg |
Gross Weight | 23.2kg |
