Habey RPC-810 Black Heavy Duty 1.2mm Cold-rolled Steel, Texture Power Coated 4U Rackmount Server Chassis 2 External 5.25" Drive Bays

Sold and Shipped by Newegg

  • 2 External 5.25" Drive Bays
  • 2 120mm Fans

ICON Loading...
  • Overview
  • Specifications
  • Warranty & Returns
  • Reviews


4U Short-Depth Steel Industrial Rackmount Chassis
Model: RPC-810

RPC-810 RPC-810 RPC-810 RPC-810
  • 4U Steel Rackmount Chassis
  • 2 x 5.25" External Drive Bays
  • Six Internal 3.5" Shock-Resistant Drive Bays in a Removable Cage
  • Two Front Accessible USB Ports
  • Lockable Front Door

Technical Specifications

Model RPC-810
Chassis Standard 4U 19" Steel Rackmount
Enclosure Materials Heavy Duty 1.2mm Cold-Rolled Steel, Texture Power Coated
Internal Drive Bay Six internal 3.5" shock-resistant drive bays in a removable cage
External Drive Bay 2 x 5.25" External Drive Bay
Front Panel Control Power on/off Button, System Reset Button, 2 x USB Port
Front Panel LED 1 x LED Power, 1 x LED HD Activity
Cooling System Front 2 x 120mm, Optional Rear 2 x 60mm, Optional Top 2x 80mm
Expansion Slot 7 x Standard PCI Slot, Optional 12 x Standard PCI Slot SBC Backpanel
System Board Support MicroATX, Standard ATX up to 12" (W) x 10" (D)
Power Supply Support Support Standard ATX Power Supply
Power Supply No
Color Black
Dimensions 19 x 18.5 x 7" (485 x 470 x 177mm)
Weight 36 lbs (16.5kg)
Gross Weight 36 lbs (16.5kg)
Package Dimensions 24 x 22 x 11" (612 x 562 x 258mm)



Learn more about the Habey RPC-810

Warranty, Returns, And Additional Information

Customer Reviews of the Habey RPC-810

Do you own this product? Write a Review

ICON Loading...

Filter Results

  • Andrew H.
  • 6/6/2012 7:30:15 AM
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsVery Impressed

Pros: -Well built
-enclosed hard drive bay
-lockable front panel
-front panel wires are all together making it easy to manage cable placement

Cons: -No knockout for a VGA on back panel (not really a big deal)

Other Thoughts: Awesome case.. I had purchased the RPC-800 from Habey and was pleased but had to return due to the handles sticking out too far for our rack. This case fits perfectly as it does not "bubble" out in the front like the 800 does.

Did you find this review helpful? Yes No

  • Lee F.
  • 3/25/2010 8:14:24 PM
  • Ownership: 1 day to 1 week
  • Verified Owner

3 out of 5 eggsDecent but cramped

Pros: Shock-mount drive cages, lots of 3.5" bays, pretty good construction compared to other cheap rackmount cases I've worked with.

Cons: The case is very short. The back of the hard drive cage is less than an inch from the front of a full-ATX motherboard. Optical drive cage overlaps motherboard and will interfere with memory modules that have tall heat spreaders.

Other Thoughts: Make sure you don't use this case with a board that has front-facing SATA ports, like the MSI X58 Pro-E (Newegg #N82E16813130226), because they will be right up against the back of the hard drive cage. I had to drive an hour to find a local store that sold SATA cables with right-angle ends, and still had to plug them in before installing the board. I also had to knock off about an inch of the optical drive cage with a Dremel to clear the heat spreaders on my memory modules, but this probably wouldn't have been an issue with naked DIMMs. Looking now I see "short depth" listed as a feature, didn't notice that before I ordered.

Did you find this review helpful? Yes No
