Coboc HM-SW-4KUP-3X1A 3 in 1 out Amplified HDMI® Switcher w/ 4K*2K,3D HDCP 1080P and IR Remote, Extract Optical Toslink or Stereo Audio Output - Up-Scaling 1080P to UHD 4K at 24/25/30fps input.

Open Box

Sold and Shipped by Newegg

3 x 1 Ports HDMI Scaler Switch w/ Audio Extractor
One HDMI / MHL Dual-input Interface
4K2K and 1080P
Up Scaling 1080P@24/25/30fps to 4K x 2K
Extract Audio to R/L ,Toslink Outputs

Specifications
Warranty & Returns
Q&A

Learn more about the Coboc HM-SW-4KUP-3X1A

Model

Brand: Coboc

Model: HM-SW-4KUP-3X1A

Details

Type: HDMI 4K Scaler Switch

Color: Black

Ports: 3

Audio: Yes

Specifications: Type: 3 Ports HDMI Switch with Audio Extractor
Standard : Compliant with HDMI 1.4 & HDCP 1.4
Video Bandwidth: 300MHz/9.0Gbps total
4K2K/ULTRA HD Support:4096×2160p@24 Hz and 3840×2160p@24/25/30 Hz
1080P Support:1080P@24/25/30/60 Hz
3D Video Support:Full 3D such as 1080P@23.98/24Hz,720P@59.94/60Hz/50Hz
Color Depth : 12 bit per channel,total 36bit and xvYCC color space
3D Video Support:Full 3D such as 1080P@23.98/24Hz,720P@59.94/60Hz/50Hz
Audio Supports: LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
Input Video signal: 5.0 Volts P-P
Input DDC signal: 5V (peak-to-peak)
Max.transmission distance:
Ultra HD 4K x 2K Resolution - 28AWG HDMI cable/ 5 meter input and 5 meter Output
Full HD 1080P Resolution - 28AWG HDMI cable/ 10 meter input and 10 meter Output
Enclosure: Metal
New Weight:303g
Dimension(W-H-D):6.4 x 1.0 x 2.5in.

Input - 3 x HDMI Type A (19 pin female)
Output - 1 x HDMI Type A (19 pin female)
1- Optical Toslink Digital Audio
1- Analog Stereo RCA L/R Terminal
Control - LMAGE Mode Switch
LED - Front Panel Indicators

Power supply:
100-240V @50/60Hz AC input
5V 1A DC output

Connectors

Input Connector: 3 - HDMI Female Input

Output Connector: 1 - HDMI Female Output
1- Optical Toslink Female
1- Analog Stereo RCA L/R Terminal

Features

Features: Switcher allows user to input three HDMI sources and switch between these sources to provide a single HDMI output to a display, and extract a 2CH LPCM audio signal via Stereo L/R or Coax digital from the HDMI source be selected.
This switcher can be controlled via the supplied remote control or by using the input switching button on the front of the device.
Input 1 - HDMI/MHL dual-input means this device is built in MHL process chipset in system,support MHL signal input via a MHL PASSIVE cable(not a expensive MHL ACTIVE adapter cable).Allow you Connect mobile device that support MHL output like Samsung Galaxy to your home theater easily.
The ability of UP-Scaling 1080P signal to 4K is a crucial function when working with 1080P@24/25/30Hz sources in a complex AV system and switch the HDMI sources to 4Kx2K displays
Device incorporates two output modes
Bypass mode (input folows output) - device reads and analyzes the EDID information from souce and display,realize the handshake,output the highest supported resolution between source and displays,ensuring maximum compatibility in any system.Support 1080P@60Hz,3D,2160p@30Hz.
LMAGE mode (upscaling) - designed to user who upgrade 4K display,but still using legacy 1080P source.When Connect 4K display in your AV system,device would up-scale 1080P@24/25/30Hz signal to 4K x 2K at corresponding refresh rate.In LMAGE mode,make sure that the HDMI output of your source defaults to or can be set to refresh rate at 24/25/30Hz

Feature
Compliant with HDMI 1.4, HDCP 1.4 and backword compliant with DVI 1.0
One HDMI / MHL dual-input interface,compliant with MHL 2.0
Clock Rate up to 25MHz- 300Mhz, Maximum Bandwidth up to 9Gbps
Incorporate two output modes
bypass mode - Support 1080P@60Hz,3D,4096×2160p@24Hz and 3840×2160p@24/25/30 Hz resolution output
