Comprehensive CP-HDA2 HDMI Audio Splitter/De-embedder

Sold and Shipped by Newegg

Overview
Specifications
Warranty & Returns
Reviews
Q&A

The Comprehensive CP-HDA2 is a high-quality HDMI audio splitter/de-embedder, with 1 HDMI and 1 split stereo audio output, HDCP compliant and HDTV compatible. The antistatic case design of CHA2 provides good protection for stable performance, and its transmission resolution goes up to 1920x1200@60Hz. Unit comes with a 2 year warranty.

Learn more about the Comprehensive Cable and Connectivity CP-HDA2

Model

Brand: Comprehensive

Model: CP-HDA2

Details

Type: HDMI Splitters

Specifications: Input: 1xHDMI 1.3 Female
Output: 1xHDMI 1.3 Female, 1x3.5mm Stereo Audio Jack
Input Level: T.M.D.S. 2.9V/3.3V
Output Level: T.M.D.S. 2.9V/3.3V
Input Impedance: 50 Ohm
Output Impedance: 50 Ohm
Video Gain: 0 dB
Video Bandwidth: 340 MHz (10.2 Gbit/s)
Video Signal: HDMI 1.3
Maximum Pixel Clock: 165MHz
Resolution Range: Up to 1920 x 1200 or 1080P@60Hz
Delay Time: 5nS (±1nS)
CEC: Supports CEC wired infrared data pass-through using the HDMI 1.3 standard
HDCP Management: Compliant with High-bandwidth Digital Content Protection (HDCP) using DVI and HDMI 1.3 standards.
Audio Frequency Response: 20Hz - 20KHz
CMRR: >70dB@20Hz~20KHz
SNR: >80dB
Audio Bandwidth: 20Hz - 25KHz
Stereo Channel Separation: >75dB@20Hz ~ 20KHz
THD + Noise: 1%@1KHz, 0.3%@20KHz
Power Supply: 100VAC - 240VAC, 50/60Hz
Power Consumption: 3W
Temperature: -20C - +70C
Humidity: 10% - 90%

Features

Features: De-embed and split the HDMI audio to two different format outputs
Built-in HDCP internal management, HDMI 1.3
HDTV compatible with High Definition Transmission up to 1920x1200@60Hz resolution (max)
Bandwidth: 340 MHz (10.2 Gbit/s)
Wall/table-mountable aluminum enclosure
Antistatic case design providing good protection for long-term and stable performance
