Deactivated Item
-
-
-
Manufacturer Contact Info
Return Policies
This item is covered by Newegg.com's Standard Return Policy.
- Return for refund within: 30 days
- Return for replacement within: 30 days
- Restocking Fee: Yes
|
-
- 5
-
- 72%
- 4
-
- 14%
- 3
-
- 6%
- 2
-
- 3%
- 1
-
- 5%
| Product Rating: |

|
| Total Reviews: |
66 |
Nice
- Pros: Nice, did what i needed. Wasnt DOA. I really like this board. Manuel is alittle lacking in areas. Tech support is o.k. if u can understand them though there accent
- Cons: One of the chipsets is alittle close to the graphics card. If it wasnt for this and possiblity to cause graphic card heat issues it would be perfect!
- Other Thoughts: AMD Phenom II X3 720, GIGABYTE GA-MA790X-UD4,Microsoft Windows Vista Home Premium 64-bit, G.SKILL 4GB (2 x 2GB), SAPPHIRE 100225L Radeon HD 3870. Set up gives me 60-74 fps on WoW.
questionable
- Pros: good placement on all connectors and slots as well as good price.
- Cons: installed phenom x4 9600 with 4 1 gig sticks of crucial and board would not read ram correct. i manually reset ram to 1066 and started getting run time errors, so i flashed bios which acted like it took but then quit booting which should not have been an issue except for the fact that the 2nd bios failed to kick in. newegg fortunately has rmaed the board will have to try different configuration to see if i can make it work right.
- Other Thoughts: gigabyte is normally a good quality board hopefully this new board will operate correctly and restore faith in the product
Gigabyte GA MA790X-UD4
- Pros: Excellent layout! Handles all processors on the market. Overclocking facilities are better than average but a little confusing and busy. Most software works as described. Runs pretty cool and not lock-ups.
- Cons: WILL NOT USE DDR3 RAM! What a dissappointment. It will handle DDR2 1200 and is supposed to overclock to 1333. I haven't figured that one out yet.
With the Phenom II x4 940 the sound distorted above 3.6Ghz. I installed a Creative Labs Audigy 24bit Sound card and it cured that problem. I have my Phenom II 940 OC'd to 3.6GHz on this board and it's stable in XP but will only handle 2.98 in Vista Hm Basic. Puzzling. My goal is 3.8 Hz.
- Other Thoughts: My multiplier is 14 x 258 FSB and voltage is 1.36. This yeilds 3.6. I plan to lower the multiplier and increase the FSB and then increase the cpu voltage.
My ultimate goal is to get 3D Mark 06 above the 15,700 mark or higher. My ultimate goal is 20,000. I would have to improve on the Video Graphics card to a 4870 x2. My Windows Experience is 5.4 and the HD is my only item below 5.9. So I will be tweaking this slowly until I get the desired results.
| Model |
| Brand |
GIGABYTE |
| Model |
GA-MA790X-UD4 |
| Supported CPU |
| CPU Socket Type |
AM2+/AM2 |
| CPU Type |
Phenom FX / Phenom / Athlon 64 FX / Athlon 64 X2 |
| FSB |
2600MHz Hyper Transport (5200 MT/s) |
| Chipsets |
| North Bridge |
AMD 790X |
| South Bridge |
AMD SB750 |
| Memory |
| Number of Memory Slots |
4×240pin |
| Memory Standard |
DDR2 1200/1066
Whether 1200 MHz memory speed is supported depends on the CPU being used |
| Maximum Memory Supported |
16GB |
| Channel Supported |
Dual Channel |
| Expansion Slots |
| PCI Express 2.0 x16 |
1 x PCI Express x16 slot, running at x16 (PCIEX16_1)
1 x PCI Express x16 slot, running at x8 (PCIEX8_1) |
| PCI Express x1 |
3 |
| PCI Slots |
2 |
| Storage Devices |
| PATA |
1 x ATA100 2 Dev. Max |
| SATA 3Gb/s |
6 |
| SATA RAID |
0/1/0+1/5/JBOD |
| Onboard Video |
| Onboard Video Chipset |
None |
| Onboard Audio |
| Audio Chipset |
Realtek ALC889A |
| Audio Channels |
8 Channels |
| Onboard LAN |
| LAN Chipset |
Realtek 8111C |
| Max LAN Speed |
10/100/1000Mbps |
| Rear Panel Ports |
| PS/2 |
2 |
| USB 1.1/2.0 |
8 x USB 2.0 |
| IEEE 1394 |
2 x IEEE 1394a |
| S/PDIF Out |
1 x Optical, 1 x Coaxial |
| Audio Ports |
6 Ports |
| Onboard USB |
| Onboard USB |
2 x USB 2.0/1.1 headers |
| Onboard 1394 |
| Onboard 1394 |
1x 1394a |
| Physical Spec |
| Form Factor |
ATX |
| Dimensions |
12.0" x 9.1" |
| Power Pin |
24 Pin |
|
|
Reviewed By: CTE069 on 3/18/2009
Tech Level: average - Ownership: 1 day to 1 week
