Item#: N82E16813128463

GIGABYTE GA-P67A-UD4 LGA 1155 Intel P67 SATA 6Gb/s USB 3.0 ATX Intel Motherboard

  • Intel P67
  • Core i7 / i5 / i3 (LGA1155)
  • DDR3 2133/1866/1600/1333/1066
ICON Loading...

Learn more about the GIGABYTE GA-P67A-UD4

Model

Brand
GIGABYTE
Model
GA-P67A-UD4

Supported CPU

CPU Socket Type
LGA 1155
CPU Type
Core i7 / i5 / i3 (LGA1155)

Chipsets

Chipset
Intel P67

Memory

Number of Memory Slots
4×240pin
Memory Standard
DDR3 2133/1866/1600/1333/1066
Maximum Memory Supported
32GB
Channel Supported
Dual Channel

Expansion Slots

PCI Express 2.0 x16
2 (x16, x8)
PCI Express x1
3
PCI Slots
2

Storage Devices

SATA 3Gb/s
4
SATA 6Gb/s
2 x SATA 6Gb/s
SATA RAID
0/1/5/10

Onboard Video

Onboard Video Chipset
None

Onboard Audio

Audio Chipset
Realtek ALC892
Audio Channels
8 Channels

Onboard LAN

LAN Chipset
Realtek 8111E
Max LAN Speed
10/100/1000Mbps

Rear Panel Ports

PS/2
1 x PS/2 keyboard/mouse port
USB 3.0
2 x USB 3.0 by Renesas D720200
USB 1.1/2.0
8 x USB 2.0
eSATA
2 x eSATA 6Gb/s by Marvell 88SE9128
S/PDIF Out
1 x Optical, 1 x Coaxial
Audio Ports
6 Ports

Internal I/O Connectors

Onboard USB
2 x USB 3.0 + 6 x USB 2.0

Physical Spec

Form Factor
ATX
Dimensions
12.0" x 9.6"
Power Pin
24 Pin

Manufacturer Warranty

Parts
3 years limited
Labor
3 years limited

Quick Info

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years


Customer Reviews of the GIGABYTE GA-P67A-UD4

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • Mark N.
  • 12/11/2012 12:14:41 AM
  • Tech Level: Average
  • Ownership: more than 1 year
  • Verified Owner

1 out of 5 eggsKnown issues?

Pros: Runs, I guess.

Cons: SATA slots are giving out. Haven't been able to get anything but my 2 hard drives to post in about 8 months. Can't replace it because I don't have the time or the money.

Did you find this review helpful? Yes No

  • Anonymous
  • 1/31/2011 8:12:26 AM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month

5 out of 5 eggsGreat Board

Pros: Great Layout, lots of features..
USB3, eSATA, SLI\CF capable..
Unlike the previous reviewer I was able to boot from a USB drive to wipe my SSD (PartedMagic) before installing Windows 7.

Cons: None Yet.

Other Thoughts: Current system:

CPU: Intel Core i5-2400 @ 3.7GHz
Mobo: Gigabyte GA-P67A-UD4
RAM: 8GB Mushkin Enhanced Silverline DDR3
VGA: EVGA Geforce GTX460 SSC+
SSD: OCZ Vertex2 120GB
OS: Windows 7 Pro 64bit

Long overdue upgrade from my previous system: (Attended college, funding was low..)
CPU: AMD Athlon XP 1700+ @1.4GHz
Mobo: Matsonic something...
RAM: 1GB DDR
VGA: ATI Radeon 9600XT
HDD: Maxtor 30GB + Maxtor 80GB IDE
OS: Windows XP Pro

Did you find this review helpful? Yes No

  • Alan L.
  • 1/30/2011 1:32:51 PM
  • Tech Level: Somewhat High
  • Ownership: 1 day to 1 week
  • Verified Owner

4 out of 5 eggsIt works!

Pros: Easy to install, bios detected everything including USB mouse, keyboard, blank SSD, DDR3 1600 (first boot was 1333, then it went to 1600 on the next boot). And it worked.. unlike the Asus board I returned.

Cons: Audio port is pretty far away from the front of my case (FT02B).. had to stretch the line

Did you find this review helpful? Yes No

  • Pamela N.
  • 1/29/2011 12:16:09 AM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

1 out of 5 eggsBIOS needs work.

Pros: Pretty. Works fine with my DDR3 1600 7-8-7-24 at 1333 9-9-9-27.

Cons: BIOS are just bad. No matter the revision if I try and set my memory over 1333 I get odd POST errors including reverting back to default F4 BIOS and Windows taking several minutes to load. IF Windows actually loads then the board is rock solid but when POST fails or acts weird 2 out of 3 times it can be frustrating. Have not even tried to overclock the CPU yet. Wish I had saved money on memory.....or bought an ASUS. This is my 5th Gigabyte MB in a row and the first with problems. Guess I will give them some time to fix these issues as really do not want to hassle with an RMA.

Other Thoughts: I checked SEVERAL tech support forums and it seems this is not uncommon. I was hoping not having the new UFEI BIOS would be a plus.
P67A-UD4
i7 2600K
GTX460
2x4GB GSkill DDR3 1600 7-8-7-24
Corsair 750TX
Antec 1200
Scythe Mugen 2
OCZ Vertex 2 120GB
2 x WD 640 Blacks

Did you find this review helpful? Yes No

  • Channing M.
  • 1/27/2011 10:33:07 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

3 out of 5 eggsDon't bother trying to boot from USB

Pros: Layout is pretty good, i can't plug in the front audio ports on my case due to the board being rotated 90 degrees in the case, the cable wont fit around my video card, and i wouldn't want it to.

Everything else is laid out perfectly. No issues getting everything installed.

Build quality is top notch, nothing feels cheap and all the connectors are solid.

Cons: the bios is garbage, and not because it doesn't have UEFI, but because it's garbage. Ram doesn't detect right, wants to sit at 1333, doesn't like the intel turbo boost and just runs it at 3.3ghz no matter what. Won't boot from a bootable usb drive at all, this seems to be an issue with EVERY FREAKING GIGABYTE BOARD. USB mouse/keyboard/drives will NOT work until windows is installed. utter failure gigabyte.

If you press the reset button the board reboots, posts, reboots and goes normal.

Other Thoughts: had to manually make the ram 1600 instead of 1333, it's already whined about voltage once and defaulted back to 1333, even though it's got plenty.

build quality

0 out of 2 people found this review helpful. Did you? Yes No

  • Nick S.
  • 1/27/2011 11:05:30 AM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsNice Board

Pros: Great board, easy plug and play. Put in a crucial 64gb ssd Sata3 drive as my boot OS for windows 7. Runs very fast with no problems. Board looks cool and very solid.

Cons: Lacks IDE, had to use SATA CDrom but that's fine, time to upgrade.

1 out of 1 people found this review helpful. Did you? Yes No

  • Anonymous
  • 1/23/2011 1:39:55 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsAwesome board

Pros: Detected memory profile and just needed to switch to that profile to run at spec. Great for overclocking, for anything below 4.4Ghz all I needed to change was the multi, 4.5+ needs more tinkering. Board does all the voltage changes for you while OC'ing, making it REALLY easy to take your 2500K/2600K higher... Black PCB looks great and really like the slot layout. Dual bios really helps with overclocking mistakes as well.

Cons: None really, see other thoughts

Other Thoughts: Not really a con because I like the oldschool bios, but no UEFI bios (although I've heard that the switch to that is a possiblity in the future).

1 out of 1 people found this review helpful. Did you? Yes No

  • Henry H.
  • 1/22/2011 10:02:05 PM
  • Tech Level: Somewhat High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsGreat Board

Pros: * Great Layout IMO, all the places you would attach cables (USB, fans, etc) are on the outside of the board....makes it VERY easy for cable management
* loads of documentation, drivers, 4 SATA cables (two are 90 degree)
* had no trouble installing it into case (Antec 600), plugging in PSU, and running cables... very easy build
* considerable overclocking (havent tried it yet, but its geared for that)
* really nice looking
* raid support, even on the SATA 6 (Im running two crucial's SSD's) in a raid 0) easy install there too
* booted up on the first try and havent had any problems since
* when you take the board out of the package you can tell its well-made
* i couldnt tell any difference between the onboard sound and my previous mobo's onboard sound... its good enough for gaming/videos but Im not an audiophile that gets nervous if its not perfect so youre mileage may vary

Cons: I havent found any cons yet.

Other Thoughts: This is the most Ive paid for a mobo and I dont need all the features right now. I may use them someday but what ultimately swung me in favor of it was just aethsetics. It is really sweet looking.

Im not disappointed at all and would strongly recommend.

2 out of 2 people found this review helpful. Did you? Yes No

  • Michael T.
  • 1/16/2011 8:28:20 AM
  • Tech Level: Somewhat High
  • Ownership: 1 day to 1 week
  • Verified Owner

4 out of 5 eggsGreat board but not the very best

Pros: This is a great board and I am very satisfied with my purchase!

- Great OC capabilities!
- Reliable autorecovery
- Has all the features I need

Cons: Though this is an awesome board for the new Sandy Bridge processors, here's the issues I had during my build.

- Layout gets cluttered with Antec 900 because of SATA positioning
- Had a hard time configuring voltage timings for memory sticks
- RAID controller performance was underpar

Other Thoughts: Gigabyte utilities software are very friendly and they have some use. Comes with an SLI cord.

Core i7 2600k @ 3.8GHz (for now)
Corsair Vengeance 1600MHz (2x4gb)
Corsair 950W PSU
XFX Radeon HD 5770 950MHz 1300MHz
OCZ Vertex 2 60GB for OS
4x1TB Hitachi on RAID5 for data

5 out of 7 people found this review helpful. Did you? Yes No

  • Henry H.
  • 1/15/2011 10:56:11 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week

5 out of 5 eggsGreat choice for Sandy Bridge

Pros: Very clean layout with clearly-labeled connectors, attractive design, two rear eSata ports, optical and coaxial S/PDIF

Cons: Not pleased with the sound quality delivered by the integrated audio chip; will definitely be purchasing a dedicated sound card

Other Thoughts: I'm using this board with an i7-2600 processor (Sandy Bridge) and have had no problems. This is the first computer that I have built from scratch, and the system booted up and worked great on the first attempt.

Build:
Case: Antec Three Hundred Illusion
Memory: 8 GB G.SKILL Ripjaws DDR3 1333 RAM (F3-10666CL9D-8GBRL)
PSU: PC Power & Cooling S75QB (750 watt)
Video: EVGA GeForce GTX 465 (01G-P3-1467-AR)

4 out of 6 people found this review helpful. Did you? Yes No
