BIOSTAR T5 XE CFX-SLI LGA 1156 Intel P55 ATX Intel Motherboard
- Intel P55
- Core i7 (LGA1156) / i5 (LGA1156)
- DDR3 800/1066/1333/1600(OC)/1866(OC)/2000(OC)
Specs
Reviews (77)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Biostar T5 XE CFX-SLI
| Brand | BIOSTAR |
|---|---|
| Model | T5 XE CFX-SLI |
| CPU Socket Type | LGA 1156 |
|---|---|
| CPU Type | Core i7 (LGA1156) / i5 (LGA1156) |
| Chipset | Intel P55 |
|---|
| Onboard Video Chipset | None |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 800/1066/1333/1600(OC)/1866(OC)/2000(OC) |
| Maximum Memory Supported | 16GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 2 x PCI-E x16 Slot (CFX x8 or SLI x8) |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 2 x PCI Slots |
| PATA | 1 x ATA133 2 Dev. Max |
|---|---|
| SATA RAID | 0/1/5/10 |
| Audio Chipset | Realtek ALC888 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Realtek 8111DL |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 2 x PS/2 / 6 x USB 2.0/1.1 |
|---|---|
| PS/2 | 2 |
| USB 1.1/2.0 | 6 x USB 2.0 |
| Audio Ports | 6 Ports |
| Onboard USB | 2 x USB header (support 4 ports) |
|---|
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12" x 8.66" |
| Power Pin | 24 Pin |
| Features | 4+2 phase power design 100% X.D.C Japanese solid capacitor Clean-Tone2 Audio Technology Toverclock UTILITY G.P.U (Green Power Utility) for Dynamic CPU power consumption control Support ATI CrossfireX technology Support nVidia SLI Technology |
|---|
| Package Contents | BIOSTAR T5 XE Motherboards 1 x IDE Cable 2 x SATA Cable 1 x SATA Power Cable 1 x SLI Setter 1 x I/O Shield 1 x CD Driver 1 x User Manual |
|---|
| First Listed on Newegg | September 28, 2009 |
|---|
