Item#: N82E16813138352

BIOSTAR TZ77B LGA 1155 Intel Z77 HDMI SATA 6Gb/s USB 3.0 ATX Intel Motherboard with UEFI BIOS

  • Intel Z77
  • Core i7 / i5 / i3 (LGA1155)
  • DDR3 2600(OC)/2400(OC)
ICON Loading...

The BIOSTAR TZ77B is a great foundation for your next PC build supporting the state-of-the-art Intel 3rd generation Core processors in LGA 1155 packaging. The Z77 chipset natively supports USB 3.0 technology bringing the USB peripherals data transfer to a new level at up to 5Gbps. Intel Smart Connect Technology keeps you always up to date with social networking even when system is asleep, while Intel Rapid Start Technology allows your PC to resume from deepest sleep in a flash.

6-phase power design and 100% X.D.C solid capacitor permit excellent quality and reliability in rigorous environment. BIO-Remote 2 technology turns your Android or Apple products into a remote control, making your smartphone even smarter. The ATI CrossFireX technology along with PCIe 3.0 pushes your graphics performance to limits by enabling multiple graphics card to co-work in a single system.



  • newegg SRT(Intel Smart Response Technology) Intel Smart Response Technology is an Intel Rapid Storage Technology(RST) caching feature that improves computer system performance. It allows a user to configure computer systems with an SSD used as cache memory between the hard disk drive and system memory. This provides the advantage of having a hard disk drive(or a RAID volume) for maximum storage capacity while delivering an SSD-like overall system performance experience.
  • newegg 100% Solid Caps With armor-plated Biostar Technology, all capacitors are placed with 100% solid capacitors that have a lasting life cycle, durability and stability for crucial components.
  • newegg PCI-E Gen 3.0 Ready PCI-E 3.0 is the next evolution of the ubiquitous and general-purpose PCI Express I/O standard. At 8GT/s bit rate, the interconnect performance bandwidth is doubled over PCI-E 2.0, while preserving compatibility with software and mechanical interfaces.
  • newegg UEFI BIOS Unified Extensible Firmware Interface (UEFI) is a brand new framework that provides a revolutionary interface. It is a modern clear and easy-to-use graphical user interface. The UEFI comes with a colorful easy-understand icons leads users into the setup layer directly.
  • newegg BIO-Remote 2 BIO-Remote2 Technology is featuring users a better Home Theater environment. Users who own either Android mobile or Apple goods are able to access and control your PC remotely; At this moment, your smart device became an intelligent and functional remote controller; more than that, BIO-Remote2 also includes both function of mouse pad and power point presentation mode.
  • newegg HDMI 3D Visual The HDMI 3D Visual provides a level of interoperability for devices designed to deliver 3D content over the HDMI connection. The latest HDMI Specification adds key enhancements to support the market requirements for bringing broadcast 3D content into the home featuring key enhancements for 3D applications including the addition of mandatory 3D formats for broadcast content.

Learn more about the Biostar TZ77B

Model

Brand
BIOSTAR
Model
TZ77B

Supported CPU

CPU Socket Type
LGA 1155
CPU Type
Core i7 / i5 / i3 (LGA1155)

Chipsets

Chipset
Intel Z77

Memory

Number of Memory Slots
4×240pin
Memory Standard
DDR3 2600(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066
Maximum Memory Supported
32GB
Channel Supported
Dual Channel

Expansion Slots

PCI Express 3.0 x16
1
PCI Express 2.0 x16
1 @x4
PCI Express x1
2
PCI Slots
2

Storage Devices

SATA 3Gb/s
4
SATA 6Gb/s
2 x SATA 6Gb/s
SATA RAID
0/1/5/10

Onboard Video

Onboard Video Chipset
Supported only by CPU with integrated graphic

Onboard Audio

Audio Chipset
Realtek ALC892
Audio Channels
8 Channels

Onboard LAN

LAN Chipset
Realtek 8111E
Max LAN Speed
10/100/1000Mbps

Rear Panel Ports

PS/2
1
Video Ports
D-Sub + DVI
HDMI
1 x HDMI
USB 3.0
2 x USB 3.0
USB 1.1/2.0
4 x USB 2.0
Audio Ports
6 Ports

Internal I/O Connectors

Onboard USB
2 x USB 3.0 + 4 x USB 2.0
Other Connectors
1 x Front Audio Header
1 x Front Panel Header
1 x S/PDIF-OUT Header
1 x CPU FAN Header
2 x System FAN Header
1 x Serial Header
1 x CIR Header

Physical Spec

Form Factor
ATX
Dimensions
11.61" x 9.06"
Power Pin
24 Pin

Features

Features
Maximum CPU TDP (Thermal Design Power) : 95Watt

Support the Intel 3rd and 2nd generation Core i7 and Core i5 processors in the 1155 package

Intel Z77 single chip architecture

Support 4-DIMM DDR3-2600(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333 up to 32G maximum capacity

Support SATA 6Gb/s 2X speed than current SATA 3G

Support Intel Smart Response Technology

Support USB 3.0

100% X.D.C solid capacitor

BIOSTAR G.P.U (Green Power Utility) Technology for Energy Saving

BIOSTAR Toverclocker utility

Quick Info

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years


Customer Reviews of the Biostar TZ77B

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • SCOTT S.
  • 1/24/2014 12:53:26 AM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

2 out of 5 eggsDisappointed

Pros: Was and worked as advertised for a little less than a year.

Cons: Very delicate and thin. Components are of low quality

Other Thoughts: I owned this a little less than a year and was very satisfied with it until recently. I recently upgraded my GPU. I always take all the precautions when working with hardware. Simply removing my old card gently caused the PCIe 3.0 slot to stop functioning. I have been trying to email Biostar support but they are very slow replying.

Did you find this review helpful? Yes No

  • Anonymous
  • 10/11/2013 9:10:48 AM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsAwesome MOBO

Pros: -Intel
-Color Scheme
-ATX
-UEFI BIOS
I love this board, no problems with it, worked right out of the box. Installed my 8gb, no problems, super fast. Great Price!

Cons: none

Did you find this review helpful? Yes No

  • Eric M.
  • 9/15/2013 8:39:02 AM
  • Tech Level: Average
  • Ownership: 1 day to 1 week
  • Verified Owner

3 out of 5 eggsboth bad and good.

Pros: good quality
handles itself well under a load
pretty decent for a budget mobo.

Cons: overclock is somewhat complicated

Other Thoughts: i had one of this previously in a rig that i bought from a friend, i really liked the setup and was pleased with the mobo easy to use and boot up. this time around, i wanted to build a new rig and decided i would go with the same mobo. however, as soon as i installed it failed to post. i revised all other cables and wiring to make sure everything was properly connected and everything else was fine, but again, no post, no display no nothing. It was somewhat upsetting but none the less, i submitted an RMA and it was handled in a prompt manner, i got my refund and i orderd a TZ77A this time instead.

to sum it up; i received a bad product sent it back and am in the process of getting a new one; all done hassle free.

Did you find this review helpful? Yes No

  • LI-Ping T.
  • 8/11/2013 9:31:24 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

1 out of 5 eggsCustomer support

Pros: Lots of PCI ports. Cheap Z77 that allowed Crossfire.

Cons: One of the Sata 6gb ports didn't work. USB ports stopped operating after a couple months of usage. Didn't care about it too much until it happened more and more often. Motherboard just died recently. Front audio USB didn't work.

Other Thoughts: I have contacted the RMA service about the 5 year limited warranty multiple times but still have not even gotten an automated return message.

Manufacturer Response:

Sorry to hear of your troubles, please see RMA Request form Link for warranty service.

http://www.biostar-usa.com/app/en-us/support/rma.php

Did you find this review helpful? Yes No

  • Thae Y.
  • 8/1/2013 11:20:20 AM
  • Tech Level: Average
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsgood

Pros: works as expected. fast driver installation.

Cons: none

Did you find this review helpful? Yes No

  • Ehab A.
  • 7/11/2013 1:13:19 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week

3 out of 5 eggsDoes not help make a clean build.

Pros: * Z77 for a moderate price.
* everything is unlocked (VCore+Multiplier). So, you can do your own CPU/memory overclocking comfortably.

Cons: * Some of the connectors are placed in such an awkward place that it does not help you with the cable management. Look at the picture and notice the red front audio connector right behind the built-in 3.5mm jacks.
**The IO connectors are usually placed to the back of the case and the front audio is in the front side of the case...so your cable will extend over the width of the motherboard..which is not nice.
**Likewise with the front USB 3.0 connector (the blue one just north of the red PCI-e slot).
**Gigabyte does better with the SATA connectors. The SATA connectors in a gigabyte mobo face sideways.

*The BIOS interface is so retro. Other mobos have 3D bios interface.

Other Thoughts: Sorry newegg!....this the only item from the build I bought from another company.

Did you find this review helpful? Yes No

  • Tyler P.
  • 7/7/2013 4:32:55 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsGood Mobo

Pros: Good motherboard

Cons: Audio header in weird location.

Did you find this review helpful? Yes No

  • Garrett S.
  • 7/3/2013 7:41:03 PM
  • Tech Level: Average
  • Ownership: 1 month to 1 year
  • Verified Owner

4 out of 5 eggsSound issues

Pros: Overall, this motherboard is good for overclocking and has a decent amount of I/O

Cons: Every time I put my computer in 'Sleep' mode, the sound out of the audio jack doesn't work until I go to the Realtek sound manager GUI and switch it from "Mute rear device..." to "Make front and rear output devices playback..." or vice versa. Not a huge issue, but it can be a nuisance to some.

Oh, I sent a rebate for this board, and it never came back. :,(

Did you find this review helpful? Yes No

  • Richard K.
  • 6/9/2013 6:34:49 AM
  • Tech Level: Average
  • Ownership: 1 month to 1 year
  • Verified Owner

2 out of 5 eggsBiostar rebate a scam

Pros: Works as advertised

Cons: Biostar does not honor rebates.

Other Thoughts: Do not count on Biostar sending any rebate money. It's been 4 moths and nothing. will never purchase anything Biostar

0 out of 1 people found this review helpful. Did you? Yes No

  • Paul L.
  • 6/3/2013 11:01:34 PM
  • Tech Level: Somewhat High
  • Ownership: more than 1 year
  • Verified Owner

4 out of 5 eggsDoes what it needs to do on the cheap

Pros: It's a pretty decent basic on-the-cheap mobo that seems to be capable of some basic overclocking (although that's not my thing).

Cons: Not the greatest layout, SATA plugs are in a bit of a weird spot and could use some more fan headers. Not enough for my Antec case. Doesn't recognize XMP profile for my Mushkin RAM modules and I can't figure out how to set the timings right since it's a faster-than-usual speed. Sometimes boots into code 99 which isn't explained anywhere and requires a hard reset before POST.

Other Thoughts: It does what it has to do and hasn't failed on me... yet. Have had it just over a year.

Did you find this review helpful? Yes No
