ASRock X99M Extreme4 LGA 2011-v3 Intel X99 SATA 6Gb/s USB 3.0 Micro ATX Intel Motherboard
- Intel X99
- Intel Core i7 and Xeon 18-Core Processors Family for the LGA 2011-3 Socket
- DDR4 3000+(OC) / 2933+(OC) / 2800(OC) / 2400(OC) / 2133 / 1866 / 1600 / 1333 / 1066
Overview
Specs
Reviews
X99M Extreme4
Product Brief
- ASRock Super Alloy
- XXL Aluminum Alloy Heatsink
- Premium 60A Power Choke
- Premium Memory Alloy Choke
- Ultra Dual-N MOSFET (UDM)
- NexFET™ MOSFET
- Nichicon 12K Platinum Caps
- Sapphire Black PCB
- Supports Intel® CoreTM i7 and Xeon® 18-Core Processors Family for the LGA 2011-3 Socket
- Digi Power, 12 Power Phase design
- Supports Quad Channel DDR4 3000+(OC), Supports ECC*, RDIMM Memory
- Supports ECC*, RDIMM Memory
- *ECC is supported with Intel Xeon processors.
- 2 PCIe 3.0 x16, 1 PCIe 2.0 x16
- Supports AMD Quad CrossFireXTM and NVIDIA® Quad SLITM
- 7.1-Channel HD Audio with Content Protection (Realtek ALC1150 Audio Codec), Supports
Purity Sound™ 2 & DTS Connect
- Intel Gigabit LAN + Qualcomm Atheros Gigabit LAN
- 10 SATA3, 1 eSATA, 1 Ultra M.2 (PCIe Gen3 x4 & SATA3)
- 6 USB 3.0 (2 Front, 4 Rear), 8 USB 2.0 (4 Front, 4 Back)
- 1 COM Port Header, 1 Thunderbolt AIC Connector
- Supports ASRock Cloud, HDD Saver Technology, Full Spike Protection, APP Shop
The extra large massive aluminum alloy heatsinks dramatically take away heat and cool down MOSFETs, chipsets.
The next generation NexFET MOSFETs provide lower Rds(on) 2.9mΩ, delivering higher efficiency and lower temperature.
Pure black PCB surface. The new Sapphire Black PCB shows rock-solid quality and gives the Sapphire Black PCB motherboard a more mysterious look.
Specially designed for memory power delivery, the new-gen alloy chokes feature a highly magnetic and heat resistant design, thus delivering more stable and reliable power to the motherboard
Nichicon's supreme 12K platinum capacitors! The industry's longest lifespan – 12,000 hours.*
*Tested under industry standard 221°F (105°C) ambient temperature.
Combining with two silicon dies into one MOSFET, Ultra Dual-N MOSFET provides larger die area and lower Rds(on), so the power supply for the CPU Vcore is more efficient.
Compared to traditional chokes, ASRock's new-gen premium power chokes effectively increase saturation current up to three times, providing enhanced and improved Vcore voltage to the motherboard.
Designed with a 12 Power Phase Design, this motherboard features sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.
Dual Gigabit LAN – This motherboard provides two Gigabit LAN ports, Intel® I218V & Qualcomm® Atheros® AR8171.
This motherboard supports DDR4 ECC and RDIMM (Registered DIMM) memory modules which deliver server-grade performance and durability for high-powered computing systems.
By adopting digital Pulse-width modulation (PWM), ASRock motherboards can provide CPU Vcore voltage more efficient and smoothly.
The onboard M.2 socket is a new interface for connecting Next Generation Form Factor (NGFF) SSDs or other devices. ASRock is the best in the world at implementing PCIe Gen3 x4 M.2 socket on motherboards. The ultimate Ultra M.2 interface pushes the speed up to 32Gbps which is 6X faster compared to other M.2 Gen2 x1 solutions that are limited to 5Gbps. In addition to support PCIe Gen3 x4 M.2 modules, the Ultra M.2 also supports SATA3 6Gbps M.2 modules.
Purity Sound™ 2 includes 7.1-channel HD audio with Realtek ALC1150 audio codec, 115dB SNR DAC with Differential Amplifier, TI® NE5532 Premium Headset Amplifier, cap less Direct Drive technology, EMI shielding cover, PCB isolate shielding and DTS Connect. As Nichicon audio capacitors are what every audiophile has been longing for on a PC, ASRock applied these high quality capacitors for Purity Sound™ 2.
There's a dedicated 4-pin HDD Saver Connector placed near the SATA ports. By connecting it to the HDDs, you can shut down or turn on the HDDs via software when needed. HDD Saver Technology secures more privacy, saves more energy, and extends HDD life.
Some sensitive digital components on the motherboard are vulnerable to power surges, the excessive current may cause your system to malfunction immediately. ASRock Full Spike Protection includes various technologies to prevent your motherboard's components (USB, LAN, MOSFETs) from being damaged by these unexpected voltage spikes.
We provide various apps and support software for users to download. You can easily optimize your system and keep your motherboard up to date with ASRock APP Shop.
