SUPERMICRO X9SRA Single Socket R (LGA 2011) E5 ATX Workstation/Server Motherboard DDR3 1600 12xUSB, 2x PCI-E 3.0 x16

  • LGA 2011
  • Intel C602 Chipset
  • 8 x 240pin

ICON Loading...
  • Overview
  • Specifications
  • Warranty & Returns
  • Reviews

SUPERMICRO X9SRA Single Socket R (LGA 2011) E5 ATX Workstation/Server Motherboard



  • Single socket R (LGA 2011) supports Intel® Xeon® processor E5-2600/1600 and E5-2600/1600 v2 family† , 2nd and 3rd Gen. Core i7 series processors (Ci7 CPU only works w/ Non-ECC UDIMM)
  • Intel® C602 chipset
  • Up to 512GB ECC DDR3, up to 1866MHz; 8x DIMM slots
  • Expansion slots: 2x PCI-E 3.0 x16, 1x PCI-E 3.0 x4 (in x8), 1x PCI-E 2.0 x4 (in x8), 1x PCI-32
  • Dual Gigabit Ethernet LAN ports; Intel® 82579LM and Intel® 82574L
  • 2 SATA3 (6Gb/s), 4 SATA (3Gb/s), & 4 SATA2 (3Gb/s) ports via SCU
  • 4 USB 3.0 (5Gbps) ports (2 rear, 2 via header) & 14 USB 2.0 ports (8 rear, 6 via header)
  • DOM power connector support


Product SKUs
MBD-X9SRA -B X9SRA (Bulk Pack)
Physical Stats
Form Factor ATX
Dimensions 12" x 9.6", (30.48cm x 24.4 cm)
  • Intel® Xeon® processor E5-2600/1600 and E5-2600/1600 v2 family† (up to 12 cores and up to 150W)
  • Single Socket R (LGA 2011)
Note † BIOS version 3.0 or above is required
CPU Intel® 2nd and 3rd Gen. Core i7 series processors with Non-ECC UDIMM only
System Memory
Memory Capacity
  • 8x 240-pin DDR3 DIMM slots
  • Up to 512GB DDR3 ECC LRDIMM
  • Up to 256GB DDR3 ECC RDIMM
  • Up to 64GB DDR3 ECC/non-ECC UDIMM

    Note: LRDIMM only works with Intel Xeon E5-2600 and E5-2600 v2 family processors
Memory Type
  • 1866/1600/1333/1066MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
DIMM Sizes 32GB, 16GB, 8GB, 4GB, 2GB, 1GB,
Memory Voltage 1.5 V, 1.35 V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset Intel C602 chipset
  • SATA3 (6Gb/s) and SATA2 (3Gb/s)
  • RAID 0, 1, 5, 10 support (Windows)
  • RAID 0, 1, 5, 10 support (Linux)
Network Controllers
  • Intel® 82579LM and 82574L, 2x Gigabit LAN ports
  • Virtual Machine Device Queues reduce I/O overhead
  • Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
  • RealTek ALC889 7.1 High Definition Audio with S/PDIF header
Super I/O Winbond
Input / Output
SATA 2x RJ45 Gigabit Ethernet LAN ports
SCU 4x SATA 2.0 ports (3Gb/s) via SCU
LAN 2x RJ45 Gigabit Ethernet LAN ports
  • 4x USB 3.0 ports (5Gbps)
  • 14x USB 2.0 ports total (8x rear + 6x via header)
Audio Line-in / Line-out / Microphone Ports
Keyboard/Mouse PS/2 Keyboard/Mouse port
Serial Port / Header 2x headers



Whats in the Box

  • newegg Intel Xeon E5 CPU Support Based on Intel C602 chipset, the SUPERMICRO X9SRA server motherboard supports eight-core Intel Xeon E5-2600/E5-1600 processors to address the demanding needs for high performance and balanced architecture by modern business. The Intel Xeon E5 processor packs more cores, larger cache, greater memory, and new technologies like Intel Turbo Boost Technology 2.0, delivering up to 80% performance boost, reduced I/O network latency and increased energy efficiency.
  • newegg Memory The SUPERMICRO X9SRA has eight DIMM sockets that can support up to 256 GB of DDR3 RDIMM, delivering ample capacity for demanding applications.
  • newegg Flexible Storage with RAID Support 4 x SATA 3.0Gb/s + 2 x SATA 6.0Gb/s ports with RAID 0/1/10 support permit flexible storage configuration with enhanced performance and data security.
  • newegg Dual Gigabit LAN Ports Incorporating Intel 82579LM and 82574L GbE controllers in the motherboard, the SUPERMICRO X9SRA server motherboard is outfitted with two Gigabit Ethernet LAN ports to optimize network bandwidth, data throughput and communication efficiency.
  • newegg Easy Expandability Two PCIe 3.0 x16 slots, one PCI-E 3.0 x4 (in x8) slots, one PCIe 2.0 x4 (in x8) slot and one PCI slot support a range of I/O expansion cards and discrete graphics cards for flexible expansion.

Learn more about the SuperMicro X9SRA

Warranty, Returns, And Additional Information
  • Warranty
  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 3 years
  • Read full details

Customer Reviews of the SuperMicro X9SRA

Do you own this product? Write a Review

ICON Loading...

Filter Results

  • Glenn B.
  • 6/8/2015 7:34:48 PM
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsPerfect NAS board

Pros: This board had the right number of PCIE slots for the controllers I needed. The board is rock solid. The technical support was awesome, I had a case grounding issue and they were able to diagnose it with beeps over the phone.

Cons: You need to know what memory to buy for it. Use the vendor chart and stray at your own risk.

Did you find this review helpful? Yes No

  • Scott A.
  • 12/4/2014 2:08:33 PM
  • Ownership: more than 1 year

4 out of 5 eggsVery Satisfied

Pros: This board has been running in a home server now for 2+ years, both for media distribution and backup of home computers. It has been stable with the ability to house 10 SATA/SAS drives on the board itself, including usb 3.0 header.

Cons: One memory bank was bad or had a short. LGA 2011 socket R processors are expensive with odd cooler requirements. Bios is complicated and a little difficult to navigate

Other Thoughts: Very satisfied with this board, by far the most expensive I have ever purchased, but has been worth it. It has run multiple OS from Windows Server, 7, and now linux server without hesitation. Never, ever froze, and distributes video without a hitch. Backs up multiple home computers. linux server has also been excellent in combination with this board, with the only hiccup finding and installing drivers for Highpoint RR644L which I still can't figure out...

3 out of 3 people found this review helpful. Did you? Yes No

4 out of 5 eggsOverall solid

Pros: Large maximum memory size with ECC support, USB 3.0, onboard audio, and a pair of PCIe 3.0 x16 slots make this a great platform for a user workstation with an add-in video card.

Cons: Not many other usable PCIe slots. Although it has 2 x8 slots, they are next to each other at the end of the board. My LSI RAID card was touching the power supply next to the end of the board. This would be fine if your case has lots of room between power supply and MB.

I also had memory slot issues, but it seemed to be caused not by grounding problems, but instead by bending of the motherboard. If I didn't completely tighten the screws holding down the motherboard, all memory slots work fine.

Other Thoughts: Despite what other reviewers have said, this motherboard has a standard Intel LGA2011 heatsink attachment configuration. LGA2011 is different from older Intel sockets, but this motherboard is the same as all other "wide" LGA2011 ILM boards, which is most of them. Any heatsink advertised as supporting the 2011 socket will work on this motherboard.

1 out of 1 people found this review helpful. Did you? Yes No

  • Bruce S.
  • 4/18/2014 2:59:04 PM
  • Ownership: 1 day to 1 week

2 out of 5 eggsX9SRA

Pros: You can build a Xeon based workstation that can support up to 256 Gb RAM.

Cons: Came with old firmware which doesn't support Intel Xeon E5-2640 v2 CPU or video cards installed in computer. You need to get a X9SRA with bios version 3. Newegg inventory / stock of Supermicro X9SRA is old. I have built literally hundreds of computers for the University over the last 20 years so I am an experienced builder. I have never seen a motherboard that promises so much, but comes with an outdated bios that does support what is advertised.

Other Thoughts: I am very disappointed with this motherboard that I received from Newegg. It did not come with the latest bios to support the latest ivy bridge CPUs. The specs say it supports the Intel Xeon E5-2640 v2 Ivy Bridge-EP 2.0GHz, but unless you get bios version 3 you can't even see the POST video or even upgrade the bios unless you have an old Xeon CPU lying around. Newegg, you should make sure that the motherboards you sell has the latest bios.

3 out of 5 people found this review helpful. Did you? Yes No

  • Sean L.
  • 1/2/2014 12:13:04 PM
  • Ownership: 1 day to 1 week
  • Verified Owner

2 out of 5 eggsweird motherboard

Pros: usb 3, cheepish

Cons: heatsink form is not normal, no vga or dvi output. this is a strange design probably more for desktops/workstations than servers

Other Thoughts: I would get one of the other boards if you want an easier time finding good fitting components (especially for a 1u setup the IO shield doesn't fix even a supermicro chasis)

0 out of 2 people found this review helpful. Did you? Yes No

  • donald m.
  • 11/5/2013 3:00:50 PM
  • Ownership: 1 day to 1 week

2 out of 5 eggsDon't forget the Basics, Supermicro!

Pros: Works perfectly as far as I know once configured

Cons: Supermicro board came with firmware version 1.1 on it. Had to put a generation 1 Xeon on it for it to give video then flash to version 3 so it could work with my i7 4930K. This was after hours of troubleshooting video issues, changing memory and other hardware out...

Is it 2013?? Do I really have to flash my BIOS to get video, Supermicro? If I bought from a local store I'd return this board in a hot second on principle.

No motherboard manual... possible diagnostic hints or beep codes to look up...

No DVD with drivers...

What a total joke

Other Thoughts: Doesn't include a driver disc. I had to get on another PC and transfer drivers via flash drive. Again, what is it, 2013?? I have no idea what those clowns are doing.

4 out of 7 people found this review helpful. Did you? Yes No

  • John L.
  • 10/4/2013 10:37:54 PM
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsbest of both worlds

Pros: Great mb with Total of 10 sata connectors to build a decent nas solution whether it's all in one zfs with esx or the new Microsoft windows 2012 automated storage tiering. Took me less than 2 hour to put everything together and all rdimm slots works. If you go with ms, you can play games as the mb has 2 pcie x16. It allows perfect consolidation for home lab. Idle power is very impressive as well. I get lower than 58 watts for 10 sata drives (while spinning) with a nvidia geforce 650 ti boost. Haswell may be Better but you are limited to 32gb. This mb can scale lot higher in memory up to 256gb. We all know cpu isn't the bottleneck these days. It's memory and storage esp if testing lots of vms. You also get the nice ecc for copying data do storage.

Cons: Would be nice if supermicro has a better bios similar to asus. My favorite bios is the asus efi.

Other Thoughts: I like to see 10 sata 6 across the board and perhaps a micro atx mb with same features of this mb.

2 out of 2 people found this review helpful. Did you? Yes No

  • Ian S.
  • 3/30/2013 4:47:30 PM
  • Ownership: 1 month to 1 year
  • Verified Owner

3 out of 5 eggs

Pros: Great feature set.

One of the few server LGA2011 boards out there.

Cons: After about two months, half the RAM slots failed. Does not error, but does not use RAM installed in them.

Onboard "RAID" is software based.

No onboard graphics.

Other Thoughts: Looks like RAM slot failure is common for LGA2011 server boards.

0 out of 2 people found this review helpful. Did you? Yes No

  • Brian H.
  • 3/15/2013 12:45:48 PM
  • Ownership: 1 month to 1 year

1 out of 5 eggsBad DIMM

Pros: Decent when working, works well with good DIMM slots. Works well with the i7 Extreme Processor.

Cons: Several DIMM slots did not work. After I RMA'd, I received a new motherboard with the same issues. The bad DIMM slots are even in the same place, which makes me think it wasn't even tested, just rubberbanded.

I'm kind of surprised, usually Supermicro is a good place to get server grade motherboards. Not sure if I will RMA again, I'll just refund this for a Sabertooth workstation.

1 out of 3 people found this review helpful. Did you? Yes No

  • Kiran N.
  • 2/27/2013 6:49:58 AM
  • Ownership: less than 1 day

1 out of 5 eggsUnexpected from SM

Pros: Well i haven't found one yet, except the SM brand.

Cons: Received board after 3 hours i opened to fire it up, connected every thing no post.

Played trial and error and elimination game, remove this and remove that all combinations, no post.

Confirmed as DOA and returned, newegg successfully processed it .

real Cons
1. You need Super micro heatsink.
2. Different mounts, you can live with but why ?

2 out of 4 people found this review helpful. Did you? Yes No
