SUPERMICRO MBD-X10SLL+-F-O uATX Server Motherboard LGA 1150 DDR3 1600
- LGA 1150
- Intel C222
- 4 x 240pin
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Supermicro MBD-X10SLL+-F-O
| Brand | SUPERMICRO |
|---|---|
| Model | MBD-X10SLL+-F-O |
| CPU Socket Type | LGA 1150 |
|---|---|
| CPU Type | Intel Xeon processor E3-1200 v3 and 4th Gen Core i3, Pentium, Celeron |
| Other Chipset | Intel C222 |
|---|
| Number of DDR3 Slots | 4 x 240pin |
|---|---|
| DDR3 Standard | DDR3 1600 |
| Maximum Memory Supported | 32GB |
| ECC Supported | Yes |
| PCI Express x8 | 1x PCI-E 3.0 x8 (in x16) slot 1x PCI-E 3.0 x8 slot |
|---|---|
| PCI Express x4 | 1x PCI-E 2.0 x4 (in x8) slot |
| SATA | 4 x SATA 3.0Gb/s + 2 x SATA 6.0Gb/s |
|---|---|
| SATA RAID | SATA3 (6Gbps) w/ RAID 0, 1 SATA2 (3Gbps) w/ RAID 0, 1, 5, 10 |
| Onboard Video Chipset | Aspeed AST2400 |
|---|
| LAN Chipset | Intel I210-AT |
|---|---|
| LAN Speed | 10/100/1000Mbps |
| Second LAN Chipset | Intel I210-AT |
| Second LAN Speed | 10/100/1000Mbps |
| Max LAN Speed | 2 x 1Gbps |
| Video Ports | D-Sub |
|---|
| Features | Input / Output: LAN: 2x Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port USB: 2x USB 3.0 ports (1 Type-A, 1 via header) 6x USB 2.0 ports (4 rear, 2 via header) Serial Port / Header: 2x COM ports (1 rear, 1 header) DOM: SATA DOM (Disk on Module) power connector support TPM: 1x TPM 1.2 20-pin Header |
|---|
| Form Factor | uATX |
|---|---|
| Dimensions (W x L) | 9.6" x 9.6" |
| First Listed on Newegg | November 22, 2013 |
|---|
