Question 1

will this motherboard be compatible with an intel i7 cpu?

Accepted Answer

This motherboard is compatible with an intel i7 LGA 1150 socket only, 4th generation of intel cpu. Pretty much the haswell type processors. CPU I purchased with motherboard is a i7 4770k, very good cpu compared to the i7 920 i had. There are different types/generations of the i7 so make sure u get the one with the same cpu socket as the motherboard.

Question 2

will this support a i5 intel processor?

Accepted Answer

This is what this board officially supports In i5...
Core i5 4690K 3.90 GHz
Core i5 4670K 3.40 GHz
Core i5 4670S 3.10 GHz
Core i5 4670T 2.30 GHz
Core i5 4670 3.40 GHz
Core i5 4570S 2.90 GHz
Core i5 4570T 2.90 GHz
Core i5 4570 3.20 GHz
Core i5 4440S 2.80 GHz
Core i5 4440 3.10 GHz
Core i5 4430S 2.70 GHz
Core i5 4430 3.00 GHz

Question 3

Hi there, looking to build a haswell i7 system soon and I have been an EVGA motherboard & graphics cards users for years. Sadly it seems that they are offering less of a selection then they used to. Now I apologize since this has already been asked in a way but I would like more of a straight answer before purchasing a $220 motherboard.

Is this PCIE 3.0 or 2.0?

I do not wish to know if the board is compatible with PCIE 3.0 cards, I just want to know straight up, are the PCIE lanes 3.0 or 2.0 because in 30mins of searching the internet for clear specs I have not yet been able to find a direct answer.

Also I was planning on going with 2 EVGA gtx7604gb in sli on this board, If I were to install a 3rd video card, say a old 9800gt, as a stand alone physics card would it cause the lanes to run in 8x4x4? or would my 2 cards in sli still run at 8x8?

I want to thank anyone who responds in advance for your help

Accepted Answer

According to HWINFO64 under Windows 7 Ultimate, it is a PCI 3.0 MOBO:

HWiNFO64 Version 4.30-2060

XXXXXXXX -----------------------------------------------------------------

[Current Computer]
  Computer Brand Name:                    EVGA
 [Operating System]

Motherboard ---------------------------------------------------------------

[Computer]
  Computer Brand Name:                    EVGA
 [Motherboard]
  Motherboard Model:                      EVGA 141-HW-E877
  Motherboard Chipset:                    Intel Z87 (Lynx Point)
  Motherboard Slots:                      4xPCI Express x1, 2xPCI Express x8, 1xPCI Express x16
  PCI Express Version Supported:          v3.0
  USB Version Supported:                  v3.0
 [PCH Features]
  USB Port Count:                         10 ports
  RAID Capability:                        Not Supported
  SATA Ports 2 and 3:                     Supported
  SATA Port 1 6 Gb/s:                     Supported
  SATA Port 0 6 Gb/s:                     Supported
  PCI Interface:                          Supported
  PCI Express Ports 5 and 6:              Not Supported
  USB Redirect (USBr):                    Not Supported
  Intel Anti-Theft Technology:            Supported
  PCI Express Ports 7 and 8:              Supported
  PCH Integrated Graphics Support:        Supported
  Data Center Manageability Interface (DCMI): Supported
  Node Manager:                           Supported
  PCH PEG/DMI Ratio:                      5/5
 [BIOS]
  BIOS Manufacturer:                      American Megatrends
  BIOS Date:                              07/26/2013
  BIOS Version:                           4.6.5
  EFI BIOS:                               Capable
  Super-IO/LPC Chip:                      Fintek F71879A/F71889A

Question 4

Will this board run windows 8?

Accepted Answer

Yes it will. I'm running windows 8.1 pro 64 bit, no problem. Hope this helps.

Question 5

Hello, I'm building a new pc for gaming.  Is this motherboard compatible with a *CM Hyper 212+ cpu cooler (specifically would the width of the cpu cooler allow it to fit into position with that heatsink so close to the cpu socket)?  Also will I be able to fit a GTX Titan onto it?  Thank you

Accepted Answer

I just installed this MB the other day with a ZALMAN CNPS9500A-LED 92mm 2 Ball CPU Cooler.  The CM Hyper looks like it is much narrower than what I put in so I doubt you'll have an issue.  I also put in a EVGA ACX Cooler 03G-P4-2784-KR GeForce GTX 780 3GB 384-Bit GDDR5 PCI Express 3.0 SLI Support Video Card and it looks about the same as the titan size wise.  So I doubt you'll have an issue their either.  My only concern with the CPU cooler would be your power supply.  I put mine in a Cooler Master HAF X - High Air Flow Full Tower Computer Case with Windowed Side Panel and USB 3.0 Ports and with the bottom mounted PS there was no space issues at all.

Question 6

what everyone using for memory ??

Accepted Answer

G.SKILL Trident X Series 16GB (2 x 8GB) 240-Pin DDR3 SDRAM DDR3 2666 (PC3 21300) Desktop Memory Model F3-2666C12D-16GTXD

Question 7

The specs state that this board has "PCI Express 3.0 Support." What does that mean? Would it utilize a PCIe 3.0 GFX card to it's full capabilities or does it just accommodate it, i.e. EVGA GTX 780?

Accepted Answer

That means you would need to use an Ivy Bridge series cpu (22nm silicon) or newer in order to enable/utilize the PCIe 3 support - at which point your PCIe 3 graphics card can perform as it was intended.
(which isn't going to be by any significant amount unless the card manufacturer has certain features throttled down when plugged into a PCIe 2 gen slot)

Question 8

How many fan headers does this motherboard have on it?

Accepted Answer

It has 6 fan headers, there may be one or two more tucked away, but 6 is all I use. That is including CPU fan. Will open up my tower when I get home and update this for a final official count.

Question 9

Would the BIOS version that ships with this motherboard support an i7-4790K out of the box?  If not, is flashing possible without a CPU installed?  I'm aware that Z87 supports 4th-gen Core processors but I've read that board manufacturers have had to issue BIOS updates to ensure compatibility with Devil's Canyon.  I know EVGA has, as well, but I don't have a spare LGA 1150 processor to boot to BIOS in case I need to flash out of the box.  Thanks.

Accepted Answer

Hi Kevin!
I am using an I-7 4770 cpu with the MB your asking about. it appears the two chips are quite similar with only a few differences. I didn't have to make any bios changes and the system is a rock! I haven't shut the system off with the exception of when thunder storm threatens in the area! Here's what I am running: Kingston Hyper X 3K SH103S3/480G 2.5" 480GB SATA II (for the OS) EVGA GeForce GTX 770 DUAL Super Clocked 2GB 256-bi
Intel Core i7-4770K Haswell 3.5GHz LGA 1150 84W Qu
2 x G.SKILL Sniper Gaming Series 16GB (2 x 8GB) 240-Pi
EVGA Z87 FTW (141-HW-E877-KR) LGA 1150 HDMI SATA 6
Microsoft Windows 7 Ultimate SP1 64-bit - OEM

Like I said, the system rocks! I don't think you can flash the board "system" without the board being operational, you might check with EVGA. Since the 4770 and 4790 are quite similar the 4790 might just work without having to change anything. Again, EVGA should be able to answer your question and be more helpful.

Question 10

Would this work on an adata xpg 2400mhz ram card and a gigabyte windforce gtx 760 4gb?

Would 2 graphics cards that big actually fit in sli?

how many internal usb 3.0 connectors does is have?

I'm mostly worried about the ram working so if someone could give me advice on that...

Accepted Answer

I do not know the dimensions of the graphics card but there are other reasons you cannot use two high speed graphics cards - there is only one PCIe 16x slot.  The slots are as follows (in order):
PCIe 16x/8x
PCIe 8x/4x
PCIe 4x
PCIe 1x (short)
PCIe 1x (long)
There are many memory sets for this computer.  Memory manufactures have charts that will tell you what memory will work.
There are two USB 3.0 headers and two USB 2.0 headers on the mobo.
EVGA is consumer friendly - give them a call - they will answer any additional questions.

CPU Socket Type	LGA 1150
CPU Type	4th-generation Core i7/i5/i3(LGA1150)

Number of Memory Slots	4x240pin
Memory Standard	DDR3 2666+/2400/2133/1600/1333/1066/800
Maximum Memory Supported	32GB
Channel Supported	Dual Channel

Serial ATA (SATA)	8 (6/Z87 PCH - 2/Marvell 9220)
SATA RAID	0/1/5/10/JBOD

Audio Chipset	Realtek ALC898
Audio Channels	8 Channels

LAN Chipset	Intel I217
Max LAN Speed	1Gbps
Bluetooth	Bluetooth V2.1

EVGA Z87 FTW (141-HW-E877-KR) LGA 1150 HDMI SATA 6Gb/s USB 3.0 ATX Intel Motherboard

Learn more about the EVGA Z87 FTW (141-HW-E877-KR)

Customer Reviews of the EVGA Z87 FTW (141-HW-E877-KR)

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

PCI Express x16	4 (1x16,2x8,1x8+2x4,1x8+4+4+1)
PCI Express x1	1 x PCI Express x1

HDMI	1 x HDMI
DisplayPort	1 x DisplayPort
USB 3.0	4 x USB 3.0
USB 1.1/2.0	4 x USB 2.0
eSATA	2 x eSATA
Audio Ports	5 Ports

Physical Spec
Form Factor	ATX
Dimensions (W x L)	12.0" x 9.6"
