Item#: N82E16814195115

AMD FirePro W600 100-505835 2GB 128-bit GDDR5 PCI Express 3.0 x16 Workstation Video Card

  • FirePro W600
  • 2GB GDDR5
  • PCI Express 3.0 x16

ICON Loading...
  • Overview
  • Specifications
  • Warranty & Returns
  • Reviews


  • Single-slot graphics card capable of driving up to six displays or projectors
  • Overlap support for up to six projectors for seamless projections
  • DisplayPort 1.2 support enables multi-stream audio capabilities
AMD FirePro™ W600 professional graphics is the ideal solution for powering display walls designed to attract, inform and engage audiences or foster collaborative interaction and decision making. It's the powerful, flexible and affordable multi-display professional graphics product the display-wall market needs.

AMD FirePro™ W600 professional graphics is the most powerful solution available for configuring display walls featuring multiple displays — no other single-slot professional graphics card is capable of driving up to six displays (with independent audio streams), features the latest graphics memory technology for exceptional multimedia performance and only consumes 75W maximum power
  • Six Mini DisplayPort outputs for driving six displays or projectors
  • Bezel compensation and projector overlap
  • Maximum resolution of 4096 x 2160, 30 bits per pixel at 60Hz
  • Decode two simultaneous HD video streams
  • 2GB graphics memory
  • 75W maximum power consumption
  • PCIe® x16 bus interface, PCIe® 3.0 compliant
  • Full height / half-length form factor
  • OpenGL 4.2 and DirectX® 11 support
highlights1 highlights2 highlights3
Superior Performance

AMD FirePro W600 features 2GB of GDDR5 memory, the latest memory technology designed specifically for graphics architectures, and is capable of supporting real-time 2D and 3D high resolution images, animations, 3D content and live/prerecorded video (HD and SD) with exceptional visual quality.
Energy-Efficient Design

Great performance output, at little power consumption. The AMD FirePro W600 with 75W maximum power consumption require no additional PCIe power connectors and can be easily deployed in smaller, more energy efficient system. AMD PowerTune Technology provides direct control over GPU power usage, while the AMD ZeroCore Power Technology helps to reduce GPU power consumption at idle by up to 95%.

Display Outputs and Adapters
  • Six Mini-DisplayPort outputs
  • Optional Six Mini-Display Port to single-link DVI adapter kit sold separately; part number 199-999440
System Requirements
  • Single available PCIe® x16 lane; PCIe® 3.0 for optimal performance
  • 256MB System memory
  • Internet access for software installation
  • 350W or greater power supply with 75W available for the graphics card
  • Microsoft® Windows Vista®, Windows® 7 or Linux® (32-bit or 64-bit)
Warranty and Support
  • Three-year limited product repair/replacement warranty
  • Direct toll free phone and email access to dedicated workstation technical support team
  • Advanced parts replacement option
What's In The Box


Learn more about the AMD 100-505835

Warranty, Returns, And Additional Information
  • Warranty
  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years
  • Read full details

Customer Reviews of the AMD 100-505835

Do you own this product? Write a Review

ICON Loading...

Filter Results

  • WAYNE J.
  • 7/11/2015 7:33:12 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsNice board

Pros: Does what it claims to do. Was big improvement over the Matrox M9148 which was a 4 DP card that cost $400 in 2011. The Matrox was always the computer weak link even with the latest bios & drivers. Desktop graphics experience rating was 4.0 and with 4 2560x1600 monitors desktop performance was borderline. (Did better with 3, though)
The W600 jumped the experience rating to 7.1 for both desktop and gaming, driving the very same 4 Dell 30" DP monitors PLUS I was able to add a 60" whiteboard. The whiteboard had required its own computer, but now the W600 carries it as well, freeing up a pretty good computer for a nice upgrade for one of my users. This Matrox to W600 upgrade was a gamble, but I'm really happy with the result. I'll reuse the Matrox in a 2-monitor desktop rig.

Cons: The purchase choice I made was straight from AMD (thru Newegg.) The only thing in the box was the card and an extra mounting clip. I could NOT find W600 drivers on the AMD site. The drivers I DID download from AMD would not install. Finally found drivers for it at and those installed perfectly. Had I known AMD would not supply drivers, I would have purchased the "Sapphire FirePro W600 Graphics Card" who DID supply drivers.

Did you find this review helpful? Yes No

  • Sylwester C.
  • 1/21/2013 8:09:39 AM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

3 out of 5 eggsFirePro or FireInd

Pros: Low power (75W), standard PCI size, single slot, 6 monitors driven from a single card.

Cons: Noise: consistent stable few kHz tone coming from the fan. It can be heard through a noise coming from two Dell's Vostro desktops: 410 and 470 - in total 6 fans.

Other Thoughts: The "profesional" designation is a bit misleading here. It should be "industrial" rather. The tone coming from the fan can be heard all the time in a quiet small office environment. However it should not cause any problems in a noisy airport, restaurant or conference room.

3 out of 3 people found this review helpful. Did you? Yes No

  • Charles S.
  • 8/22/2012 2:17:27 PM
  • Tech Level: High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsGood Quality

Pros: - Plenty of power to run six 1080p TVs
- Drivers work well on Windows 7 for mirroring or extended display
- Single-width card that supposedly uses only 75 watts
- Quiet

Cons: None

Other Thoughts: Be sure to get AMD-certified active dongles: . Download the latest drivers from AMD. Finding the right one can be tricky; use Google search instead of AMD search.

9 out of 10 people found this review helpful. Did you? Yes No
