StarTech 2x4 Port Matrix DVI Audio Video Switch VS420RDVIA

Max Output Support 4 x DVI
Max Source Support 2 x DVI

Overview
Specifications
Warranty & Returns
Reviews
Q&A

Share two distinct DVI inputs with audio between four displays with the StarTech VS420RDVIA! Each display can be set to show either input, or be off independently, for the maximum digital signage configurations or multi-monitor presentations. The StarTech VS420RDVIA can be remotely controlled via the included remote control. It is rack-mountable.

Showing item detail

Connect two sources to four displays for the maximum flexibility The StarTech VS420RDVIA has two DVI inputs for connection to two sources, and four DVI outputs for connection to four displays. Through the front panel, you can choose a source for each display independently, so your combinations will be maximized. Up to 1600 x 1200 resolution video is supported.
Audio will also be transferred All DVI connectors have an accompanying audio port. The audio from the source can also be transferred to remote speaker systems.
Displays can be independently off You can even independently toggle the video (and audio) on or off for each display. This design prolongs the lifespan of the monitor and also reduces power consumption, delivering an economical and environmentally friendly solution.
Remotely control the switch An IR Remote Control and an additional (external) IR cable sensor are included. You can control the switch just with the remote control, or with both the remote control and the external sensor. Now you can install this switch in a discreet location, and remain in full control of it.
Rack-mountable The StarTech VS420RDVIA is mountable in any 19-inch (wide) rack/cabinet. Ear-mounts are included.

Learn more about the STARTECH VS420RDVIA

Model

Brand: StarTech

Model: VS420RDVIA

Performance

Max Source Support: 2 x DVI

Max Output Support: 4 x DVI

Audio: Connector A: 2 - 3.5 mm Mini-Jack (3 Position) Female
Connector B: 4 - 3.5 mm Mini-Jack (3 Position) Female

Connection

DVI: Connector A: 2 - DVI-I (29 pin) Female
Connector B: 4 - DVI-I (29 pin) Female

Power

Power Supply: Output Current: 1.5A
Output Voltage: 12 DC

Specification

Specification: Rack-Mountable: Yes
Daisy-Chain: Yes
Maximum Cable Length: 16.4 ft [5 m]
Color: Black
Enclosure Type: Aluminum

Feature

Feature: This 2x4 Port Matrix DVI Audio Video Switch lets you select between two DVI-I sources for display on up to four monitors. At the push of a button, the DVI and audio matrix switch lets you select the audio and DVI input that will be delivered each display - providing the versatility needed to simplify digital signage configurations or multi-monitor presentations.

Providing simple, yet comprehensive control of DVI signal transmissions, the 2x4 matrix switch lets you independently toggle video (and audio) on or off for each display. This not only helps prolong the lifespan of the monitor but also reduces power consumption, delivering an economical and environmentally friendly solution.

StarTech.com's 2x4 port Matrix DVI A/V Switch includes an IR Remote Control and an additional (external) IR cable sensor that lets you install the switch in a discreet location while maintaining full control. For rackmounted installations, the matrix switch also includes ear-mounts that allow installation in any 19in(w) equipment rack/cabinet.
The StarTech.com Advantage

Allows two DVI computers to provide video input to display on four different monitors with audio, saving the expense of duplicate purchases

Delivers high quality resolutions up to 1600 x 1200 pixels, ensuring content is delivered clearly, as intended

This versatile DVI video switcher enables you to take control of your displays by selecting which input you want or turn off video and audio on different displays, providing robust video matrix capability

Dimensions & Weight

Dimensions: 8.7"W x 3.8"L x 1.6"H

Weight: 26.3 oz.

Package Contents

Package Content: 1 - DVI A/V Matrix Switcher
1 - Set of Ear-Mounts for Rack Mounting
1 - Remote Control
1 - IR External Sensor
1 - Power Adapter
1 - Instruction Manual

Warranty, Returns, And Additional Information

Warranty
Limited Warranty period (parts): 2 years
Limited Warranty period (labor): 2 years
Read full details

Manufacturer Contact Info
Manufacturer Product Page|
Website: http://www.startech.com|
Support Phone: 1-800-265-1844
Support Email: support@startech.com|
Support Website|
View other products from STARTECH
