Item#: N82E16816117428

Intel RS3DC080 PCI-Express 3.0 x8 Low Profile Ready SATA / SAS Controller Card

  • RAID 0/1/5/6/10/50
  • 8 x SAS Internal Connectors
  • Up to 12Gb/s
  • Pin It
  • Email this page
ICON Loading...

Intel® RAID Controller Card
Model: RS3DC080

Overview

RS3DC080

Intel Corporation designs and builds the essential technologies that serve as the foundation for the world's computing devices. The Intel® RAID Products are built on a foundation of industry leading quality and innovation to support the Intel® Xeon® processor family.

The Intel® RAID Controller RS3DC080 is a mainstream product powered by LSI MegaRAID technology. It offers a complete set of Intelligent RAID features.

  • Crafted with a LSI3108 RAID-On-Chip (ROC) controller for exceptional performance
  • Hardware RAID 0, 1, 5, 6 and Spans 10, 50, 60 allow for RAID mode flexibility. RAID 6 allows for two drives to fail simultaneous while maintaining data persistence
  • Advance management tools allow for configuration optimization and superior troubleshooting

Technical Specifications

Model#
RS3DC080
Target Market
Mainstream
Board Form Factor
Low Profile MD2
Data Transfer Rate
12 Gbps
Supported Devices
SAS/SATA
RAID Level Supported
0, 1, 5, 6, 10, 50, 60
Internal Ports
8
Supported Devices
128
Embedded Memory
1GB DDR3
PCIe Host Interface
x8 PCIe Gen3
IO Processor Model
LSI3108
Included Items
Raid Controller, Quick Start User Guide, 1 standard & 1 Low Profile bracket.


Learn more about the Intel RS3DC080

Quick Info

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year


Customer Reviews of the Intel RS3DC080

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • John F.
  • 6/6/2015 7:47:33 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year

5 out of 5 eggsFastest_12GB/s_Speed

Pros: very fast & handles lots of drives & does 12gb/s sas drives.
you couple this with a few 6TB 12gb/s SAS drives and the speed will blow your mind and much better than SSD's. The intel raid web console allows multiple arrays and allows you to change drives in the array and the type of array. Do not buy if you cannot afford the 12gb/s sas drives.

Cons: very expensive. Also you have to pay a lot of attention to the harness you purchase and Newegg may not have it and you will have to buy elsewhere. Performance negates the high cost. You also need to buy the battery kit and I do not think Newegg stocks it.

Other Thoughts: I run two of these babies each with the battery kit. Performance is through the roof with say 4 ssd's in raid 0 or say the real use being several 6tb sas 12 gb/s enterprise drives in raid 0 or raid 5 and you can switch the raid config back and forth or try another like Raid 6. It is nice to have a C: drive of 24 TB! If you not need lots of space do not buy. Note that the top score for hard drive bench test on the Passmark web site is done with RS3DC080 and the 12 gb/s enterprise hard drives .

Did you find this review helpful? Yes No
