APC ACF002 Rack Air Distribution Unit 2U 208/230V 50/60Hz

Model

Brand

APC

Model

ACF002

Type

Type

Rack Air Distribution Unit

Spec

Specifications

Air Flow: 420.0 CFM (198.22 lps)

Input:
Number of Power Cords: 2
Nominal Input Voltage: 208, 230
Input Power: 230 Watts
Input Frequency: 50/60 Hz
Rack Height: 2U
Input Connections: C-13 / IEC-320 C14

Color: Black

Physical:
Maximum Height: 3.50 inches (89 mm)
Maximum Width: 16.60 inches (422 mm)
Maximum Depth: 29.00 inches (737 mm)
Net Weight: 41.00 lbs. (18.64 kg)

Features

Features

The Rack Air Distribution Unit is a 2U fan unit that connects into the raised floor and pulls supply air directly into the enclosure.

This prevents the conditioned air from mixing with warmer room air before reaching the equipment.

This minimizes temperature differences between the top and bottom of the enclosure, while also preventing hot exhaust air recirculation to the inlet of the enclosure.

The product is recommended for rack enclosures with loads greater than 1.5kW and can provide airflow for loads up to 3.5kW.

It is also ideal for enclosures in raised floor environments where underfloor air distribution is inadequate.
