Item#: N82E16817139035

CORSAIR Professional Series Gold AX650 650W ATX12V v2.31 / EPSV12 v2.92 80 PLUS GOLD Certified Full Modular Active PFC High Performance Power Supply

  • ATX12V v2.31 / EPSV12 v2.92
  • Full Modular
  • 80 PLUS GOLD Certified
  • 100 - 240 V
  • +3.3V@25A, +5V@25A, +12V@54A, -12V@0.5A, +5VSB@3A
ICON Loading...

Corsair Professional Series Gold power supplies set a new standard for performance, quality, reliability, and energy-efficiency in consumer PSUs. 80 Plus Gold certification guarantees more than 90% efficiency at typical loads, while unflinching voltage stability, low-noise levels, and a fully modular cable set make the Professional Series Gold PSUs the ultimate choice for discerning enthusiasts. The Professional Series Gold AX650 power supply is one of the highest-quality mid-wattage power supplies for the enthusiast who wants uncompromising performance.

  • newegg ATX12V and EPS12V Compatible Supporting the latest ATX12V v2.31 and EPS12V v2.92 standards and backward compatible with ATX12V v2.2 and ATX12V v2.01 systems, the Corsair Professional Series GOLD AX650 provides maximum power stability to drive the processors as well as other components for desktop and server computer systems.
  • newegg 80 PLUS Gold Certified The 80 PLUS Gold certified power supply provides high power efficiency of at least 87% at any load between 20% and 100%, saving your money on your electrical bill, reducing heat in your computer's system and prolonging its life.
  • newegg 650W Continuous Power with Single Strong +12V Rail The Corsair Professional Series GOLD AX650 delivers 650W reliable, continuous output for mid-wattage computer systems. Powerful single +12V rail at up to 54A design ensures the maximum provision of 12V power to energy-hungry CPU and VGA card perfect for future high-end component upgrades or overclocking.
  • newegg Flat Modular Design The fully modular cable design allows only use of the cables you need to improve internal airflow and reduce clutter. Additionally, low-profile, flat cable design reduces air friction and helps maximize airflow through your computer's chassis.
  • newegg Ultra-quiet 120mm Double Ball-bearing Fan The Corsair Professional Series GOLD AX650 utilizes a low-noise, thermally-controlled 120mm fan, and employs sophisticated techniques to enhance cooling performance and reduce noise. This includes a specially designed PCB that channels airflow to reduce back-pressure and maximize the fan’s cooling ability.
  • newegg Uncompromising Reliability High-quality Japanese capacitors provide uncompromised performance and reliability. Over-voltage and over-current protection, under-voltage protection, and short circuit protection provide maximum safety to your critical system components.

Learn more about the Corsair AX650

Model

Brand
CORSAIR
Model
AX650
Series
Professional Series Gold

Spec

Type
ATX12V v2.31 / EPSV12 v2.92
Maximum Power
650W
Fans
1 x double ball-bearing fan
PFC
Active
Main Connector
24Pin
+12V Rails
Single
PCI-Express Connector
4 x 6+2-Pin
SATA Power Connector
8
Modular
Full Modular
Efficiency
up to 90%
Energy-Efficient
80 PLUS GOLD Certified
Over Voltage Protection
Yes
Input Voltage
100 - 240 V
Output
+3.3V@25A, +5V@25A, +12V@54A, -12V@0.5A, +5VSB@3A
MTBF
>100,000 Hours
Approvals
UL, CUL, CE, CB, FCC Class B, TÜV, CCC, C-tick
Dimensions
5.9"(W) x 3.4"(H) x 6.3"(L)
Weight
6.72 lbs

Features

Connectors
1 x Main connector (24Pin)
1 x 4+4-Pin CPU 12V
10 x Peripheral
8 x SATA
2 x Floppy
4 x PCI-E
Features
The latest ATX12V v2.31 and EPS 2.92 standards and it is backward compatible with ATX12V 2.2 and ATX12V 2.01 systems.

An ultra-quiet double ball-bearing fan delivers excellent airflow at an exceptionally low noise level by varying fan speed in response to temperature.

80PLUS Gold certified, delivering up to 90% energy efficiency at real world load conditions.

Active Power Factor Correction (PFC) with PF value of 0.99.

Universal AC input from 100~240V. No more hassle of flipping that tiny red switch to select the voltage input!

A dedicated single +12V rail offers maximum compatibility with the latest components.

Over-voltage and over-current protection, under-voltage protection, and short circuit protection provide maximum safety to your critical system components.

High-quality Japanese capacitors provide uncompromised performance and reliability.

The completely modular cable system allows you to use only the cables you need. Power supply upgrade and replacement is easy, as the cables only need to be disconnected at the power supply.

Low-profile, flat cable design reduces air friction and helps maximize airflow through your computer’s chassis.

Quick Info

Warranty

  • Limited Warranty period (parts): 7 years
  • Limited Warranty period (labor): 7 years


Customer Reviews of the Corsair AX650

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • Steven M.
  • 2/2/2014 9:00:25 PM
  • Tech Level: Somewhat High
  • Ownership: more than 1 year
  • Verified Owner

5 out of 5 eggsbest psu ive eve owned

Pros: all black and not too large

Cons: wish I had the money for a ax1200

Did you find this review helpful? Yes No

  • Andrew D.
  • 4/10/2013 7:48:11 AM
  • Tech Level: High
  • Ownership: more than 1 year
  • Verified Owner

5 out of 5 eggsGreat Power Supply

Pros: I stand by Corsair, especially in their power supplies. These things are rock solid, and the ONLY time I've seen one fail is when I spilled a beer on it.

Cons: None, performs as advertised.

Other Thoughts: If I need a strong power supply, I go right to Corsair now.

Did you find this review helpful? Yes No

  • Anonymous
  • 11/11/2012 9:38:44 AM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year

5 out of 5 eggsA King of High End PSUs

Pros: This thing runs really quiet. The fan doesn't spin up until it detects a certain temperature or when the power supply is at 50C load. I've never heard this fan run at all, so good job Corsair. Good features and extremely quiet.

The cables are sleeved extremely well and fit well into the power supply cable holes. Cables are plenty and long enough for 99% of the cases out there. Full modularity on the cables is an extremely good feature and really helps with cable management.

Also saw a $1 decrease from my power bill. I'm not sure if it's because of this PSU or something, but it definitely is really efficient at 80+ Gold.

Cons: A con? For this device? Haha. You're funny. Cons. For this high end PSU. No, but on a serious note, I think this PSU is somewhat overpriced. Should be around $120-$140.

Other Thoughts: I bought this to replace my GS600 since the cable management was very hard to manage.

Also, if you hear a click sound when you boot your system up, then it probably means that the fan is testing itself to make sure it works. Which, in turn, lets you know the fan is working.

Corsair customer support is A+ material and their quality on PSUs is over A++!

1 out of 1 people found this review helpful. Did you? Yes No

  • Richard R.
  • 11/10/2012 5:36:33 PM
  • Tech Level: High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsNice

Pros: Very Quite

Cons: None

Other Thoughts: My second Corsair power supply. Always a winner.

1 out of 1 people found this review helpful. Did you? Yes No

  • Mitchell M.
  • 10/9/2012 3:40:34 PM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month

4 out of 5 eggs

Pros: Looks nice, runs as quiet as other simular models and brands, Nice modular connections to power supply.

Cons: SATA cables wired backward for top mounted power supply and need to be twisted to install. Wires stiff and difficult to bend.

0 out of 1 people found this review helpful. Did you? Yes No

  • Scott C.
  • 10/4/2012 12:57:02 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsAmazing!

Pros: Best power supply you can find, unless you're getting the AX850 or higher.
Runs smooth and quite, fan barley comes on unless I am really running a ton of stuff.
The graph on the box shows you fan speed and power consumption for the amount you are pulling.
Great packing.
All around good buy.

Cons: None

Other Thoughts: It doesnt make bacon...

1 out of 1 people found this review helpful. Did you? Yes No

  • Louis C.
  • 9/20/2012 8:16:08 AM
  • Tech Level: Average
  • Ownership: 1 day to 1 week
  • Verified Owner

2 out of 5 eggsFlawed product

Pros: Nicely packaged, long cords and quiet fan.

Cons: Very loud coil whine while in use, unbearable under normal conditions.

All the SATA cables were wired backwards. If the PSU fan is mounted down (clips down) while at the bottom of the case the 'L' teeth normally on the left side of the SATA device are very difficult to reach without twisting the stiff cables 180 degrees.

Also the SATA cables were very tight fitting. It takes almost 30 to 40 pounds of force to get them in place and remove them.

Other Thoughts: Corsairs if you're reading this please redesign the SATA cables. It should take no more than 15 pounds of force to attach/remove a SATA cable and flip the orientation of the SATA power connecter 180 degrees so I can string three devices easily if the PSU is mounted fan down.

The black, string-like cables are too stiff for normal use making the SATA cable design mistake a very good reason to not buy this power supply.

Test for coil whine. I turned off all the power saving features in the BIOS and swapped the kettle plug and the power supply and the coil whine is louder than my UPS and 140mm fans combined. It would ebb and flow to the 12-volt draw making my nearly silent computer unusable.

Flipping the PSU fan up (clips up) would align the SATA power cables but reverse remaining cables, creating a far greater problem.

0 out of 1 people found this review helpful. Did you? Yes No

  • Ryan C.
  • 9/19/2012 7:04:15 AM
  • Tech Level: Somewhat High
  • Ownership: 1 day to 1 week
  • Verified Owner

3 out of 5 eggs

Pros: -Sleek look
-Fully modular
-80+ Gold

Cons: -DOA
-Cables were a bit stiff, somewhat hard to route

Other Thoughts: Just RMA'd it. Disheartening thing to happen on my first build. Now to wait however long it may take for the RMA to actually go through. Guess Borderlands 2, Guild Wars and Mists will have to wait. =(

0 out of 1 people found this review helpful. Did you? Yes No

  • Brian A.
  • 9/12/2012 6:15:52 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsexudes high-end quality

Pros: What more can I want?

looks classy, clean, simple, and sturdy
works well so far with little noise
modular cabling is awesome
efficiency is awesome
packaging is awesome

Cons: price is not cheap, but you get what u pay for.

Did you find this review helpful? Yes No

  • Anonymous
  • 8/29/2012 6:33:36 PM
  • Tech Level: High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggs

Pros: Each cable is separate from the power supply. Not forced to hide unnecessary cables that are not in use. Over 90% efficiency! I think its more like 98%

Fan only comes on when needed. Which i havent herd it come on yet so it runs cool. Keeps the computer nice and quiet.

Very clean and organized!

Cons: none

Other Thoughts: FYI, the fan does work. It spins when the computer first turns on and then goes off.

Did you find this review helpful? Yes No
