COOLMAX V-500 500W ATX Power Supply

  • ATX
  • 115 / 230 V
  • 120mm silent fan
IronEgg
BUY WITH CONFIDENCE
This product qualifies for the Iron Egg guarantee. We'll match any qualifying competitor's price.
  • Pin It
  • Email this page
ICON Loading...

With its robust output, premium quality, and reliability, the COOLMAX V-500 redefines what an ultra-affordable PSU should be. It delivers all the power necessary to run your system smoothly, and is constructed with quality components for long life. A silent 120mm fan ensures efficient, quiet cooling. Also with tidy cable wires, the V-500 is simple to use and easy to install, making it a great candidate for your PC build or system upgrade.

  • newegg 500W Output The COOLMAX V-500 PSU delivers a maximum 500 watts of robust and reliable output for your entire system.
  • newegg Sleeved Main Cable The cable-tube on the main power cables allows for better routing and tidiness.
  • newegg Superb Protection Over-voltage- and short-circuit protections on all output levels ensure reliable safety for your components.
  • newegg 120mm Cooling Fan The silent 120mm fan delivers efficient and quiet cooling, keeping your PSU running at peak performance while not disturbing others.


Learn more about the CoolMax V-500

Model

Brand
COOLMAX
Model
V-500

Spec

Type
ATX
Maximum Power
500W
Fans
120mm silent fan
PFC
No
Main Connector
20+4Pin
+12V Rails
Single
PCI-Express Connector
No
SATA Power Connector
2
SLI
No
Haswell Support
No
Modular
No
Over Voltage Protection
Yes
Input Voltage
115 / 230 V
Input Frequency Range
50/60 Hz
Input Current
10A/5.5A
Output
+3.3V@21A, +5V@22A, +12V1@17A, +12V2@17A, -12V@0.5A, +5VSB@2.5A
MTBF
>100,000 Hours
Approvals
UL, CSA, FCC, TUV
Dimensions
5.60" x 5.90" x 3.30"
Weight
2.99 lbs.

Features

Connectors
1 x Main connector (20+4 pin)
1 x 12V(P4)
3 x peripheral
2 x SATA
1 x Floppy
Features
Specially selected components & high performance heat sink to cool down system
Serial ATA 150 ready & fully support all AMD & Intel series demand
Cable-tube on main power cables for better cable routing and neatness
Universal Connector Fits Most of Branded Motherboard
Over voltage protection, short circuit protection on all output level

Manufacturer Warranty

Parts
1 year limited
Labor
1 year limited

Quick Info

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year


Customer Reviews of the CoolMax V-500

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • Erik B.
  • 4/7/2014 9:02:16 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggs

Pros: WORKS!

Cons: NONE

Did you find this review helpful? Yes No

  • Joseph A.
  • 2/1/2014 4:19:25 PM
  • Tech Level: Somewhat High
  • Ownership: more than 1 year
  • Verified Owner

5 out of 5 eggsGreat PSU for the price.

Pros: Cheap and reliable.

Cons: None.

Other Thoughts: I've had this PSU for just over a year, running 24/7, and it's been very stable. Keeps case cool with just one intake fan and no additional exhaust fans.

Did you find this review helpful? Yes No

  • James S.
  • 8/10/2013 12:31:06 PM
  • Tech Level: Somewhat High
  • Ownership: less than 1 day
  • Verified Owner

5 out of 5 eggsFingers Crossed

Pros: Very inexpensive. Was apparently enough power to get my basic computer to work with additional video card. For this kind of money, it's a win if it works at all.

Cons: Just 2 SATA power connections, but that was all I needed for this machine.

I was as scared as everybody else by the reviews about overheating, but at least so far, everything is running perfectly cool. Granted, I don't need 500w. Probably less than 300, to be perfectly honest, though the video card said minimum 350. So, I'm not taxing this thing much. Will update the review if the fan gives out or I encounter an overheating problem in the future.

Did you find this review helpful? Yes No

  • CHI T.
  • 3/29/2013 12:27:46 PM
  • Tech Level: Somewhat High
  • Ownership: more than 1 year

1 out of 5 eggsPlastic melted

Pros: High Wattage

Cons: The black plastic near the power supply plug pins melted. Thankfully I noticed the smell and acted in time.

Other Thoughts: Brought this in november of 2009, yes 2009. It worked for a couple of months till the plastic melted.

I would not recommend getting this.

0 out of 3 people found this review helpful. Did you? Yes No

  • Dylan W.
  • 2/2/2013 6:09:46 PM
  • Tech Level: Average
  • Ownership: 1 week to 1 month

5 out of 5 eggsGood

Pros: Runs well, Powers what I need.

Cons: None so far

Other Thoughts: Runs a:
I3-2120
AMD HD 7770 Core Edition
MSI MB
8 GB
500 HDD
Opictal drive
Fans, Lights

1 out of 1 people found this review helpful. Did you? Yes No

  • Brandon P.
  • 10/29/2012 6:04:09 AM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsCheap and Works

Pros: Works, fits, and powers what I need it to power.

Cons: None at the moment.

Did you find this review helpful? Yes No

  • Nick G.
  • 6/29/2012 7:24:42 AM
  • Tech Level: High
  • Ownership: 1 month to 1 year

5 out of 5 eggsVery Good For The Price

Pros: Never had any problems, no frying, no automaticly shuting down, no nothing.

Cons: not black, but hey, it's cheap, who cares?

Did you find this review helpful? Yes No

  • brian r.
  • 4/17/2012 5:51:16 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year

3 out of 5 eggsfan was "quiet"

Pros: still working

Cons: sounds like morse code

Other Thoughts: i think i discovered what it's telling me. replace the fan soon or you'll be sorry.

3 out of 3 people found this review helpful. Did you? Yes No

  • F A.
  • 2/16/2012 2:27:38 PM
  • Tech Level: Somewhat High
  • Ownership: less than 1 day

1 out of 5 eggsstay away

Pros: Non

Cons: Ordered this unit and have seen two as they do not work. Find a different unit

Did you find this review helpful? Yes No

  • Gerardo D.
  • 11/1/2011 4:04:00 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsVery Affordable and Great Value

Pros: Great Value and Quality, these installed in a system build and had no problems from the start. Quiet fan keeps the PSU cool without being overly distracting when on. Good cable length for mATX system build and is a good cost effective solution to power your new build. The two 12V rails keeps your power nice and steady for other peripherals without taking from the CPU and other critical systems.

Cons: As an reminder this PSU is for standard economy builds and wasn't meant for high end gaming machines. It does have the standard connectors but does lack the PCIe power adapters for SLI and or external Video cards requiring external power sources.

Other Thoughts: A quick note, if memory serves this PSU doesn't have the 8 pin 2nd Gen intel processor power connector for CPU. So I believe this is not compatible for an intel 2nd gen system setup.

1 out of 2 people found this review helpful. Did you? Yes No
