Item#: 9SIA24G28N4187

Antec Basiq BP500U 500W Continuous Power ATX12V Version 2.01 Active PFC Power Supply - Intel Haswell Fully Compatible

Sold and Shipped by antonline.com a-seller

Purchases from these Sellers are generally covered under our Newegg Marketplace Guarantee.
Marketplace Seller
  • ATX2.03
  • 80 PLUS Certified
  • 100 - 240 V 47 - 63 Hz
  • +3.3V@30A, +5V@30A, +12V1@18A, +12V2@18A, -12V@0.8A, +5VSB@2.5A

LOADING... LOADING...
  • Overview
  • Specifications
  • Warranty & Returns
  • Reviews

Basiq, the Simple Choice in High Quality, Value Priced Power Supplies

Building on a budget doesn't mean you have to trust your components to an un-reliable, no-name brand. That's why Antec put its years of experience and knowledge into building world-class power supplies and the result is Basiq. The workhorse of the Antec family, Basiq is built with solid quality you have come to expect from Antec products at an unbeatable price. It does the job simply, efficiently and reliably, making Basiq a solid power supply built to satisfy the demands from the entry-level power user to the budget minded system builder.

icon for aq3icon for 80plusicon for Intel Haswellicon for rohs

Features

features
  • 80 PLUS® Certified: Reduces operating costs and protects the environment
  • Universal Input with Active PFC
  • Low Noise 80mm Cooling Fan
  • ATX12V Version 2.3 Compliant
  • Dual +12V Outputs provides maximum stable power for the CPU independently of the other peripherals.
  • Industrial Grade Protection: OVP (Over Voltage Protection), SCP (Short Circuit Protection), and OCP (Over Current Protection)
  • Backed by a 3-year parts and labor warranty
  • Safety: cUL, FCC, CB, BSMI, Gost-R
  • Dimensions (H x W x D): 3.5 x 5.8 x 5.5"
  • Weight: 3.7lbs

Output

Output Voltage Range Max. Reg. OCP Set Point Ripple & Noise
+5V 30.0A ±5% 48A 50
+12V1 18.0A ±5% 25A 120
+12V2 18.0A ±5% 25A 120
-12V 0.3A ±10% 120
+5V5B 2.5A ±5% 50
+3.3V 30.0A ±5% 50A 50

Connectors

1 x 20+4 Pin

1 x 20 + 4-Pin

1 x 6+2 PCI-E

1 x 6 + 2-PCI-E

1 x 6 Pin PCI-E

1 x 6 Pin PCI-E

4 x SATA

4 x SATA

4 x Molex

4 x Molex

1 x Floppy

1 x Aux.

1 x 4+4 Pin ATX/EPS

1 x 4 + 4-Pin ATX / EPS

What's in the Box

what's in the box

Learn more about the Antec BP500U

Warranty, Returns, And Additional Information
  • Warranty
  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years
  • Read full details
