General

Brand

Zebra

Series

140Xi4

Model

140-801-00000

Printer

Print Technology

Direct Thermal/Thermal Transfer Printer

Printer Type

Industrial

Print Speed

14 ips

Max Resolution(B&W)

203 dpi

Memory

16 MB SDRAM
8 MB Flash

Barcode Type

Code 11
Code 39
Code 93
Code 128
Code 128-B
Code 128-A
Code 128-C
Code 128 UCC
UPC-A
UPC-E
EAN-8
EAN-13
UPC 2 or 5 Digit Extension
EAN With 2 or 5 Digit Extension
Plessey
POSTNET
Standard 2 of 5
Industrial 2 of 5
Interleaved 2 of 5
LOGMARS
MSI
Planet Code
Codabar
CODABLOCK
PDF-417
Code 49
Data Matrix
Maxi Code
QR Code
TLC 39
Micro PDF
Aztec Code
RSS
GS1 DataBar

Cutter

Tear Bar

Media Handling

Media Type

Black Mark
Continuous Form
Roll Fed
Die-cut Label
Fanfold

Connections

Interface

Ethernet / Parallel / Serial / USB

Features

Features

Construction: 12-gauge steel frame
Single 32 bit 133 Mhz RISC processor
Automatic media/ribbon sensing capability
Improved head test for element out
Auto calibration
Clear media side door for ease of supplies monitoring
300 unique darkness settings
Internal ZebraNet 10/100 PrintServer
ZPL or ZPL II Programming Language
XML enabled printing
Mirror feature allows user-defined printer configurations to be retrieved from the network
Create and design customizable printer LCD menus
Large (240 W x 128 H pixel), graphical, multilingual, backlit LCD display
Transmissive and reflective media sensors
Multi-level Element Energy Equalizer (E3) for superior print quality
Unicode - Compliant
Intelligent printhead

Operating temperature:
TT: Operating temperature 40° F (5° C) to 105° F (40° C) Thermal transfer
DT: Operating temperature 32° F (0° C) to 105° F (40° C) Direct thermal
Storage temperatures: -40° F (-40° C) to 140° F (60° C)
Operating humidity: 20% to 85% non-condensing relative humidity
Storage humidity: 5% to 85% non-condensing relative humidity
Electrical: Universal power supply with power factor connection 90-264 VAC; 48 - 62 Hz

Dimensions & Weight

Dimensions

10.31" x 15.50" x 20.38"

Weight

50.00 lbs.
