General

Brand

Fargo

Model

DTC1250e (050605)

Printer

Print Technology

Dye-sublimation / resin thermal transfer

Print Speed

6 seconds per card (K); 8 seconds per card (KO); 16 seconds per card (YMCKO); 24 seconds per card (YMCKOK)

Max Resolution(B&W)

300 dpi (11.8 dots/mm) continuous tone

Memory

32 MB RAM

Media Handling

Media Type

PVC or polyester cards with polished PVC finish; monochrome resin required for100% polyester cards;
optical memory cards with PVC finish; rewrite

Media sizes supported

Accepted Standard Card Sizes:
CR-80 (3.375" L x 2.125" W / 85.6 mm L x 54 mm W)
CR-79 adhesive back (3.313" L x 2.063" W / 84.1 mm L x 52.4 mm W)

Accepted Card Thickness:
0.009" - .040" / 9.00 mil - 40.00 mil / 0.229 mm - 1.016 mm

Total Media Capacity

Input Hopper Card Capacity: 100 cards (0.030" / 0.762 mm)
Output Hopper Card Capacity: Up to 30 cards.

Connections

Interface

Single-wire Ethernet and USB 2.0 interface for inline printing and encoding

Features

Features

Print Area:
CR-80 edge-to-edge (3.36" L x 2.11" W / 85.30 mm L x 53.70 mm W)
CR-79 (3.30" L x 2.04" W / 83.80 mm L x 51.80 mm W)

Card Cleaning:
Card cleaning roller integrated into ribbon cartridge; cleaning roller is automatically replaced with each ribbon change

Software Drivers:
Windows XP / Vista (32 bit & 64 bit) / Server 2003 & 2008 / Windows 7 / Windows 8 (32 bit & 64 bit)/
MAC OS X 10.5 / 10.6 / 10.7 / 10.8 / 10.9
Linux (Available Soon)

Operating Temperature: 65° to 80° F / 18° to 27° C
Humidity: 20 - 80% non-condensing

Agency Listings:
Safety: UL 60950-2, CSA C22.2 (60950-07), and CE; EMC: FCC Class A, CE (EN 55022 Class A, EN 55024), CCC, BSMI, KC

Enviornmental Features:
ENERGY STAR qualified card printer (base models only without encoders) and refillable supply cartridges (ECO)

Supply Voltage: 100 - 240Vac, 50 - 60Hz, 1.6 Amps max
Supply Frequency: 50 Hz / 60 Hz

Display: Color changing status buttons

Features:
Fastest printer in its class:
Minimize wait time for cards and IDs with this speedy card printer.
?
High-quality output:
Simple, reliable and affordable photo ID card personalization, delivering a new level of durable, great-looking credentials.

Simple plug-and-play:
The intuitive user-focused design allows for easy set-up, loading and operation for increased efficiency.

Convenient and affordable:
Create ID cards right out of the box with plug-and-play Swift ID embedded badging application.

End-to-End Control, Flexibility and Security:
The optional iCLASS SE encoder (part of the iCLASS SE open encoder platform) can be fully integrated into your printer, allowing you to create, encode (read/write) and manage your secure credentials from start-to-finish. Design personalized ID badges locally and then program them to work with your current physical access control system (PACS), streamlining your ordering, inventory management, and issuance processes.

Package Contents

Software Included

Swift ID embedded badging application, FARGO Workbench diagnostic utility with Color Assist spot-color matching
