Model

Brand

Canon

Series

EOS

Model

EOS 7D MARK II

Part

9128B002

Details

Color

Black

Package Type

Body Only

Image Sensor

Image Sensor

CMOS

Image Sensor Size

Approx. 22.4 x 15.0 mm (APS-C size)

Gross Pixels

20.9 MP

Effective Pixels

20.2 MP

Aspect Ratio

3:2 (Horizontal: Vertical)

Color Filter System

RGB primary color filters

Dust Cleaning System

Self Cleaning Sensor Unit
* Removes dust adhering to the low-pass filter.
* Self-cleaning executed automatically (taking approx. 3 sec.) when power is turned on or off. Manual execution also possible (taking approx. 7 sec.).
* Low-pass filter has a fluorine coating.

Dust Delete Data acquisition and appending
* The coordinates of the dust adhering to the low-pass filter are detected by a test shot and appended to subsequent images.
* The dust coordinate data appended to the image is used by the EOS software to automatically erase the dust spots.

Manual cleaning

Image Processor

Dual DIGIC 6

Resolution

Large: Approx. 20.00 Megapixels (5472 x 3648)
Medium: Approx. 8.90 Megapixels (3648 x 2432)
S1 (Small 1): Approx. 5.00 Megapixels (2736 x 1824)
S2 (Small 2): Approx. 2.50 Megapixels (1920 x 1280)
S3 (Small 3): Approx. 350,000 pixels (720 x 480)
RAW: Approx. 20.00 Megapixels (5472 x 3648)
M-RAW: Approx. 11.20 Megapixels (4104 x 2736)
S-RAW: Approx. 5.00 Megapixels (2736 x 1824)

White Balance

White Balance

Auto white balance with the image sensor

Viewfinder

Viewfinder Type

Eye-level SLR with fixed pentaprism

Coverage

Approx. 100% vertically and horizontally (with eye point approx. 22mm eyepoint)

Magnification

Approx. 1.00x / 29.6 degrees (with 50mm lens at infinity, -1m-1 (dpt))

Eyepoint

Approx. 22mm (At -1m-1 from the eyepiece lens center)

Dioptric Adjustment

Adjustable from approx. -3.0 to +1.0m-1 (dpt)

Focusing Screen

Eh-A Standard Focusing Screen
Eh-S Super Precision Matte

Mirror

Quick-return half mirror (transmission: reflection ratio of 40:60)

Viewfinder Information

AF Point Information
Spot Metering Circle
Electronic Level
Grid
Shooting Mode
White Balance
Drive Mode
Focusing Modes
Metering Modes
JPEG/RAW
Flicker Detection
AF Status Indicator
Warning Symbol

Depth-of-Field Preview

Enabled with depth-of-field preview button

LCD Monitor

LCD

3.0" 1.04M

LCD Coverage

100%

Brightness Adjustment

Auto: Brightness adjusted automatically by the light sensor (Darker/ Standard/Brighter)
Manual: 7

Focus

Focus Type

TTL secondary image-forming phase-difference detection system with AF-dedicated CMOS sensor

Focusing Modes

Autofocus:
One-Shot AF
Predictive AI Servo AF (AI Servo AF III)
AI Focus AF
Switches between One-Shot AF and AI Servo AF automatically

Manual Focus

AF Points

65-point all cross-type AF

AF-assist Beam

Enable
Disable
Enable external flash only
IR AF assist beam only

Exposure

Exposure Control

Scene Intelligent Auto
Program AE (shiftable)
Shutter-priority AE (Safety shift possible)
Aperture-priority AE (Safety shift possible)
Manual exposure
Bulb
Custom shooting mode C1, C2, C3

Exposure Compensation

Manual: +/- 5 stops in 1/3-or 1/2-stop increments
AEB: +/- 3 stops in 1/3-or 1/2-stop increments

Metering System

Approx. 150,000-pixel RGB+IR metering sensor

AE Lock

Auto AE lock
*In the One-Shot AF mode with evaluative metering, AE lock takes effect when focus is achieved.

Manual AE lock
*With AE lock button. (AE lock is updated each time you press the button.) Enabled in all metering modes.

Shutter

Shutter Type

Vertical-travel, mechanical, focal-plane shutter with all speeds electronically-controlled

Shutter Speed

1/8000 to 30 sec., bulb (Total shutter speed range. Available range varies by shooting mode.)
X-sync at 1/250 sec.

Self-timer

10-sec. or 2-sec. delay

Flash

Flash Mode

Built-in Flash

External Flash

E-TTL II autoflash with all EX Series Speedlites

Drive System

Drive Modes

Single, High-speed continuous, Low-speed continuous shooting, Silent single shooting, Silent continuous shooting, 10-sec self-timer/remote control, 2-sec. self-timer / remote control

Continuous Shooting Speed

High-speed: Maximum approx. 10.0 fps (Maximum approx. 9.5 fps with EOS iTR AF)
*At 1/1000 sec. or faster shutter speed, and at the maximum aperture (varies depending on the lens)

Low-speed: Approx. 3 fps (default setting)

Silent continuous shooting: Maximum approx. 4.0 fps

Function

Live View Function

Still photo shooting and video shooting

Recording System

File Format

Design Rule for Camera File System 2.0 and Exif 2.3

Image Type

JPEG, RAW (14-bit, Canon original), sRAW, mRAW, RAW+JPEG

Color Space

Selectable between sRGB and Adobe RGB

Recording Media

SD / SDHC /SDXC Card

Movie

Movie Format

MOV (Image data: H.264, Audio: Linear PCM), MP4 (Image data: H.264, Audio: AAC)

Movie Recording

1920 x 1090 (Full HD), 1280 x 720 and 640 x 480

Max. Recording Resolution

1920 x 1080

Lens

Compatible Lenses

Canon EF lenses including EF-S lenses
(35mm-equivalent focal length is approx. 1.6x the lens focal length)

Lens Mount

Canon EF Mount

Interface

USB

Yes

A/V Out

NTSC / PAL selectable

HDMI

Yes

Power Source

Battery

Battery Pack LP-E6N

Dimensions & Weight

Dimensions

4.43" x 5.85" x 3.08"

Weight

Based on CIPA standard: Approx. 32.10 oz.
Body Only: Approx. 28.92 oz.

Package Contents

Package Contents

EOS 7D Mark II Digital SLR Body
Cable Protector
USB Interface Cable IFC-150U II
Battery Pack LP-E6
Battery Charger LC-E6
EOS Digital Solution Disc
Wide Neck Strap EW-EOS7DMARKII
