Item#: N82E16833166058

Rosewill RC-410LX Unmanaged 10/100/1000Mbps Switch with 2-Year Warranty

  • 8 x RJ45 Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
  • 4K MAC Address Table
  • 1152 Kbit Buffer Memory
  • Unmanaged
  • Pin It
  • Email this page
ICON Loading...

The Rosewill RC-410LX switch offers robust performance and features at budget-friendly price, an ideal choice to build or upgrade your home/office network. 8x Gigabit Ethernet ports with non-blocking switching architecture deliver full wire-speed for maximum throughput. 4K entry MAC address table with self-learning and auto MDI/MDIX enable easy network deployment and configuration.

The Rosewill RC-410LX utilizes Store-and-Forward switching, which verifies the integrity of data before forwarding it across the network, so you don't waste bandwidth on junk transmissions. It supports IEEE 802.3x flow control for Full Duplex mode and backpressure for half-duplex mode. RC-410LX is also designed with energy saving in mind. It adopts Green Ethernet technology with ability to detect cable length for best adjust power consumption. The Rosewill RC-410LX is a simple, economical path to high-speed Ethernet connectivity, giving you solid performance and running usability!



Rosewill Gigabit Unmanaged Switch

Model RC-409LX RC-410LX RC-415 RC-416 RGS-1016 RGS-1024
Product
5-Port
Gigabit
Switch
8-Port
Gigabit
Switch
5-Port
Gigabit
Switch
8-Port
Gigabit
Switch
16-Port
Gigabit
Rack Mountable
Switch
24-Port
Gigabit
Rack Mountable
Switch
Warranty
1 to 1
Replacement
1 to 1
Replacement
1 to 1
Replacement
1 to 1
Replacement
1 to 1
Replacement
1 to 1
Replacement
Enclosure Plastic Plastic Metal
-Sturdy
-Better Heat Dissipation
Metal
-Sturdy
-Better Heat Dissipation
Metal
-Sturdy
-Better Heat Dissipation
Metal
-Sturdy
-Better Heat Dissipation
Switch
Capacity
10 Gbps 16 Gbps 10 Gbps 16 Gbps 32 Gbps 48 Gbps
Data
RAM
Buffering
1 Mbit 1 Mbit 1 Mbit 1 Mbit 2 Mbit 2 Mbit
Mac
Address
Table
2K 4K 8K 8K 8K 8K
Jumbo
Frame
16 KB 9 KB 9 KB 9 KB 9 KB 9 KB
802.3x
Flow
Control
Yes Yes Yes Yes Yes Yes
802.1p
QoS
- - - - Yes Yes
LED Power
Link / Act
Power
Link / Act
Speed
Power
Link / Act
Power
Link / Act
Power
Link / Act
Power
Link / Act
1000 Mbps (Speed)
Green
Ethernet
Yes Yes Yes Yes Yes Yes
Rack
mountable
- - Yes Yes Yes Yes



  • newegg 10/100/1000 Port The Rosewill RC-410LX Switch features 8x Gigabit Ethernet ports which provide substantial throughput to address high bandwidth intensive application from today's network environment.
  • newegg Auto-Negotiation Auto-Negotiation between 10/100/1000Mbps to auto sense the link speed of each device to optimize the performance.
  • newegg Energy Saving RC-410LX supports Green Ethernet to significantly save port usage power and cable length power.
  • newegg Other Features Auto MDI / MDIX to eliminate the crossover cables. 9KB jumbo frame optimizes the large file transferring. 4K MAC Address Table, 1152 Kbit Buffer Memory and 16Gbps Switching Capacity meets the demand of nowadays bandwidth-intensive application.
  • newegg 2-Year Warranty – One to One Replacement 2-Year Warranty puts you into full protection for extreme peace of mind. Rosewill will replace your defective units with a new one during the warranty period with original proof of purchase.

Learn more about the Rosewill RC-410LX

Model

Brand
Rosewill
Model
RC-410LX

Spec

Switch Type
External
Standards
IEEE 802.3i 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3x Full-duplex Flow Control
Network Management Type
Unmanaged
Jumbo Frames
Yes
Ports
8 x RJ45 Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
Speed
10/100/1000Mbps
MAC Address Table
4K
Buffer Memory
1152 Kbit
Switching Method
Store and Forward
PoE
No
Stackable
No
SNMP
No
QoS
No
LACP
No
Layer
2
Port Mirroring
No
Module Support
No
LEDs
Power, Link, Speed, and Activity indicators for each port
VLAN Support
No
Power
9VDC, 0.85A
Power Consumption: 5.4 Watts Maximum
Dimensions
6.5" x 4.3" x 1.1"
Weight
1.0 lbs.
Temperature
0ºC to 40ºC (32ºF to 104ºF)
Humidity
5% - 90%, Non-condensing

Features

Features
Adopts Green Ethernet technology with ability to detect cable length with best adjust power consumption
Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput
Supports MAC address self-learning and auto MDI/MDIX
Store-and-Forward switching method
Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for half-duplex mode
Plastic case, desktop or wall-mounting design
Background Bandwidth: 16Gbps
Forwarding Rate:
10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port
1000BASE-T: 1488000pps/port
External power adapter supply

Manufacturer Warranty

Parts
2 years limited
Labor
2 years limited

Quick Info

Warranty

  • Limited Warranty period (parts): 2 years
  • Limited Warranty period (labor): 2 years


Customer Reviews of the Rosewill RC-410LX

Do you own this product? Write a Review

Filter Results

Go
  • N/A
  • 2/25/2013 7:12:37 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggs

Pros: Cheap, works as advertised, full gigabit speeds between my PCs and file server.

Cons: None

Did you find this review helpful? Yes No

  • Traveler
  • 2/22/2013 7:26:23 PM
  • Tech Level: Somewhat High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsWorks great

Pros: The price was good - cheap. Took it out of the box, moved the network cables from my old 8 port 10/100 switch and plugged in the power. It just works as advertised - simple and fast.

Cons: Lightweight - the cables try to pull it off the back of the shelf, but I set my router on top of it (with air clearance) and all is well.

Did you find this review helpful? Yes No

  • Bobby
  • 2/21/2013 1:32:31 PM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsNice device

Pros: Cheap
Fast
Works as described

Cons: none

Other Thoughts: The power cord is a tad short but not enough to even consider a Con. I like this device and plan on getting another for diff spot in house.

Did you find this review helpful? Yes No

  • N/A
  • 1/24/2013 2:32:12 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsWorks great.

Pros: High speed and 8 ports. Just what my home office and entertainment center was looking for.

Cons: Light plastic, but reading the reviews of others and you already know this. The power cord was a bit shorther than I'd like too, but no real complaints.

Other Thoughts: All in all a great unit for the price. It's lightweight, but if placed right, the cable won't drag it over the edge, I don't see that being a real problem anyway. Works awesome for all your high speed needs.

Did you find this review helpful? Yes No

  • N/A
  • 1/19/2013 11:15:09 AM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsFAST

Pros: So far so good, getting over 80MBs transfer, limited only by the write speed of the old HD.
Runs cool.
Dirt Cheap, got it onsale 4 19.

Cons: Noone so far.

Other Thoughts: If u r looking at it, just buy it. 1000BaseT is fast, remember back in 2000, this only work on fiber, and it's only for backbone use. At this speed, I can run Premiere over it, if needed to.

Did you find this review helpful? Yes No

  • N/A
  • 1/14/2013 10:40:27 PM
  • Tech Level: Somewhat High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsgreat product

Pros: Gigabit switch
8 ports
cheap

Cons: I don't have any

Other Thoughts: Great product. Was easy just to unplug from my old 100megabit switch to this one and everything is so much faster :) can transfer 10 gigs in like a minute rather than 10 minutes. I'm not complaining.

Did you find this review helpful? Yes No

  • N/A
  • 1/7/2013 7:02:26 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsGreat Deal

Pros: Works great. Fanless. Gigabit. So cheap I can order a spare for less than the gas that it costs to drive to the store.

Cons: It's so lightweight that the ethernet wires will pull it right off the shelf if the wires are hanging down.

Other Thoughts: This switch cost 90% less than the switch it replaced and it uses 90% less power. It's so small that it fits inside the structured wiring cabinet.

Did you find this review helpful? Yes No

  • N/A
  • 12/27/2012 5:15:10 PM
  • Tech Level: Average
  • Ownership: 1 week to 1 month
  • Verified Owner

4 out of 5 eggsGood for the price

Pros: 1. 8 GB ports
2. Speed is okay
3. Low price

Cons: I tested the speed port 2 port. It's around 600mbps. Not so good, right. One of possibility is the network cable I used is not good enough.

Other Thoughts: Although it's not as fast as expected, it's still a okay buy.

1 out of 1 people found this review helpful. Did you? Yes No

  • tong
  • 12/11/2012 9:53:08 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week
  • Verified Owner

5 out of 5 eggsBest $16 upgrade

Pros: Cheap! $16 shipped on sale
Speed increased from 13mb to 125mb per second. Worth every $

Cons: none

1 out of 1 people found this review helpful. Did you? Yes No

  • N/A
  • 12/11/2012 7:16:47 PM
  • Tech Level: Average
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsNo issues

Pros: Plugged into my Uverse router then plugged my home network cables to it. No Problems

Cons: Ports are close together. Can be a challenge to fill all the ports with the plugs so close but manageable. Same as most switches.

1 out of 1 people found this review helpful. Did you? Yes No
