Item#: N82E16833168135

EnGenius EGS5110P 8-Port Gigabit PoE+ (802.3at/af) Smart Switch with 2 SFP ports

  • 8 Gigabit Ethernet ports
  • 2 SFP slots
  • IEEE 802.3at/af Support
  • 130w PoE Budget
  • PoE Management on PoE Ports
  • Loopback Detection
  • Pin It
  • Email this page
ICON Loading...
EnGenius Logo Business Solutions
EnGenius EGS5110P

EGS5110P Is an Eight-Port Gigabit POE+ Smart Switch with Two SFP Ports

The EGS5110P is an 8-Port Gigabit PoE+ Smart Switch with two SFP ports. This switch can connect and supply power to Power-over-Ethernet devices like IP cameras, IP phones, and Wireless Access Points. Its Gigabit ports support IEEE 802.3at/af PoE and can supply up to 30 Watts for a total PoE budget of 130 Watts.

Gigabit Wired Speed
Utilizes Gigabit Ethernet standard speeds, up to 1,000Mbps - ideal for media streaming and large file transfers throughout the network.

Two SFP Ports
Includes to SFP ports to support transceivers for fiber cabling for connectivity to offices, buildings or other parts of the network that exceed the distance capability of Ethernet.

POE+ IEEE 802.3AT/AF Support
Enables PoE devices like Access Points, Client Bridges, IP Cameras, VoIP telephones and other PoE devices to be powered directly from the switch over Ethernet cable. Features a total PoE budget of 130 Watts.

PoE Management on All PoE Ports
For monitoring and allocating more precise power levels to PoE devices.

LoopBack Detection
For configuring the system to shut down the current port once the port is found in a loop in addition to sending a trap message.

IGMP Snooping
Monitors the Internet Group Management Protocol (IGMP) traffic between hosts and multicast routers. The switch uses what IGMP snooping learns to forward multicast traffic only to interfaces that are connected to interested receivers.

Bandwidth Control
Provides priority to identified network traffic including dedicated bandwidth, controlled jitter, and latency that is required in real time applications while improving quality by reducing packet loss.



EGS5110P Lifestyle



Features

  • 8 Gigabit Ethernet ports
  • 2 SFP slots
  • IEEE 802.3at/af Support
  • 130w PoE Budget
  • PoE Management on PoE Ports
  • Loopback Detection

  • IGMP Snooping
  • Bandwidth Control





EGS5110P Diagram


Connect Computers, VoIP Phones, Access Points and IP Cameras Throughout Your Office and Move Data at Gigabit Speeds

The EGS5110P is a Smart PoE Switch that offers eight Gigabit ports with IEEE802.3at/af PoE Support on all its ports and two SFP slots for fiber uplinks.







Business Series - Switches Table

Learn more about the EnGenius Technologies EGS5110P

Quick Info

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year


Customer Reviews of the EnGenius Technologies EGS5110P

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go

4 out of 5 eggsExcellent for Surveillance

Pros: Physical installation was plug and play. Brackets are included with packaging for rack-mount installs. AC Power consumption was moderate under full load. Cat 5e/6 cabling performance was persistent. User interface accessible via internet browser was simple and easy to use. EnGenius had a firmware update on their website (easy to install). PoE was convenient for certain devices. Switch also supports Fiber input/output (bandwidth distributed between two channels). Devices connected will auto-negotiate via DHCP by default.

Cons: PoE (Power Over Ethernet) is very useful for ethernet dependent camera systems, although the 130watt maximum threshold was not guaranteed across all cameras used as each output was limited to 30watts. 4 Cameras at 30watts each will bring you near this threshold. Drawing power over the threshold will leave this switch useless.

Other Thoughts: I ran 6 Ethernet IP Cameras (rated at 15watts) via Cat5e 350mhz cabling, 1 4TB NAS, and bridged the switch onto a cable modem. Each device was configured with a static IP and controlled through a Camera System DVR connected through my modem. Local access was seamless, however any remote connectivity experienced some delay due to bandwidth limitations.

Did you find this review helpful? Yes No

  • Richard H.
  • 5/12/2014 12:08:59 PM
  • Tech Level: High
  • Ownership: 1 week to 1 month

4 out of 5 eggsPOE SWITCH

Pros: THIS UNIT WILL PUT OUT 130 watts total of POE power, on all 8 of the ports. So, if you want POE, this is a good unit to use. Has optical ports No AC brick to get in way. Unit feels heavy and sturdy. Steel construction. Good WEB based GUI for remote management.

Cons: None really. The fan, on the back side, is pretty loud. Not to be placed on your desk.

Other Thoughts: EnGenius is a good company. This is a premium offering, for those who want the features offered.

Did you find this review helpful? Yes No

4 out of 5 eggsVery nice unit

Pros: • Latest firmware loaded.
• Detailed user’s manual available on-line for download.
• Solidly built unit.
• Flexible mounting, desktop or rack.
• Good management tools available via HTML login to switch. Cable diagnostics tool can be very help to avoid trial and error replacement. Also “Zero Configuration” minimizes installation efforts into an existing network.

Cons: • Fan (40mm?) noise, high pitched whine, typical for small fans. On a business network these things are typically isolated so not a big issue. If you’re a home user, you will need to place away from your immediate vicinity or acoustically isolate it in some manner.
• Strong competition in this price range. See “Other thoughts” below related to your needs.

Other Thoughts: These comments aimed at potential user.
• The buyer needs to identify his or her needs. These considerations include 1) do you need and can you make use of the POE (Power Over Ethernet) feature, 2) if you can use POE what is the power level you need (POE or POE+), and 3) do you need a managed network switch (unmanaged, smart or managed switch)? These will affect both energy costs for large networks and data transmission rate on any network.
• Ensure your Ethernet cables are sufficient, Cat6 or better is best. These can affect energy costs for large networks.

Instructions say wait for bootup but doesn’t say how you’ll know. After a minute or so, I just plugged things in and it worked fine.

Detailed user’s manual not included but understandable since it is 46 pages. Equipment guides always handy for ITs to have. Home users will need it.

1 out of 1 people found this review helpful. Did you? Yes No
