Model

Brand

LevelOne

Model

WAN-1160

Details

Type

Antenna

Specifications

Frequency Band: 2400MHz – 2500MHz, 4900MHz – 5875MHz
Gain: 6.0dBi, 8.0dBi
VSWR: 2.0:1 Max, 2.0:1 Max
Polarization: Linear, Vertical; Linear, Vertical
HPBW / V: 65°, 60°
HPBW / H: 70°, 50°
Impedance: 50 Ohms
Connector: Quick RP-SMA Plug
Cable: ULA100; 1m
Cable loss: 1.3dB, 2.0dB
Temperature: -10°C - +55°C
Humidity: 92% @ 25°C
Radome Material: ABS
Weight: 0.2 lbs.
Dimension: 3.9" x 2.8" x 2.4"

Features

Features

Dual-band for 802.11a 5.0GHz and 802.11b/g 2.4GHz Wireless applications
Provides stable signals and extends coverage
Directional operation
Easy to located in limited space
ULA-100 1m cable for wireless device with SMA connector
