Model

Brand

Silex

Model

SX-DS-4000U2

Details

Type

Device Server

Specifications

Wired LAN: 10BASE-T, 100BASE-TX, 1000BASE-T (automatic detection)

Device Interface: 2 x USB 2.0 Hi-Speed ??(A type) with a total of 1A power supply

Supported protocols: TCP / IP

OS support: Windows 7 (32/64 bit), Vista (32/64 bit), XP, 2000, Windows Server 2008 (32/64 bit), Windows Server 2003 (32/64 bit)
Mac OS X - PowerPC: Ver 10.3.x ~ Ver 10.5.5, Intel: Ver 10.4.4 ~ Ver 10.7.x

Setting method: Configuration utility, Web browser, WPS

Maximum power consumption: 2.5W (DC5V .5A) up to 7.5W (DC5V 1.5A) including 1A for USB power

Other: Requires SX Virtual Link version 3.8.0 or later for Windows or version 3.7.0 for Macintosh

External dimensions: 99 x 67 x 30 mm (without rubber feet)

Weight: 97 g

Features

Features

High-Performance:
Higher data throughput due to optimized performance and Gigabit connection: Extremely powerful CPU (800MHz) and two USB Hi-Speed ports (TypeA)

Energy Saver Mode:
When the device server is not used for a certain period of time, the power supply to the USB bus is turned off to save energy. The power supply to the USB bus is automatically turned back on when the server is used again.

Print Server Function:
Supports standard TCP/IP printing (LPR/IPP/RAW)
The product supports the general RAW-mode, LPR-mode and IPP-mode network printing protocols. When the product is connected to a printer, the standard Windows print function can be used to print.

AutoConnect Feature:
The Printer AutoConnect feature allows multiple computers to easily share USB printer over the network by making an automatic connection to the printer. Then automatically disconnecting after the print job is sent making the device server available to the next user.

Isochronous Transfer Mode:
USB devices such as Webcams or USB sound cards, which require ongoing data transmission in real time, can also be used in the network environment. Both Full Speed and Hi-Speed USB are supported.

With the SX-DS-3000WAN, you can connect a variety of USB devices over the network, like USB dongles, MP3 players, CD/DVD/Zip drives, USB drives and other storage media, scanners, printers, digital cameras, USB sound cards, USB LCD monitor, telescopes, mixing consoles and many more.

Virtual environments: The USB Device Server is compatible with the following virtualization programs and environments:
VMware, Citrix, Microsoft Terminal Server and Hyper-V.

No special drivers or applications are needed to use the USB devices: The drivers and applications that worked when the USB device is directly connected to the computer will continue to work.
