Item#: N82E16835999034

LOGISYS Computer MC4002IW 120mm Hydro Bearing Ice Wind CPU Cooler

  • 500±200~1500±10%RPM
  • 66.3CFM
  • Email this page
ICON Loading...

Learn more about the Logisys Computer MC4002IW

Model

Brand
LOGISYS Computer
Model
MC4002IW

Spec

Type
Fan & Heatsinks
Fan Size
120mm
Compatibility
Intel: LGA1155/1156/LGA1366/LGA775
AMD: AM3/AM2+/AM2/940/939/754
Bearing Type
Hydro Bearing
RPM
500±200~1500±10%RPM
Air Flow
66.3CFM
Noise Level
17.8~27.6dB(A)
Color
Blue Fan

Physical Spec

Fan Dimensions
120 x 120 x 25mm
Heatsink Dimensions
151 x 83 x 160mm
Weight
915g

Features

Features
High performance universal CPU cooler for Intel & AMD CPUs comes with 120mm PWM fan with 4 heat pipes for maximum heat transfer.

Rubber buckles reduces operating vibration and noise.

Use with Core Touch Technology (CTT) gives perfect contact with CPU surface.

Quick Info

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year


Customer Reviews of the Logisys Computer MC4002IW

Do you own this product? Write a Review

ICON Loading...

Filter Results

Go
  • Donald C.
  • 10/8/2014 8:33:40 AM
  • Tech Level: Average
  • Ownership: 1 week to 1 month
  • Verified Owner

4 out of 5 eggsWorks fine

Pros: The contact surface was completely flat.

The installation could be done without access to the rear of the motherboard.

It keeps the processor reasonably cool despite a low volume, nearly silent replacement fan being used.

Cons: I'm not sure I would trust the plastic mounting ring if I were going to move the case often. The plastic mounts which pass through the motherboard from only the front are not as robust as a rear plate system. But they can easily be installed without board removal. This mount resulted in a 1 egg reduction.

The ring to mount the heat sink to is very close to the top of some components on my Gigabyte GA-Z97X-SLI.

Other Thoughts: The fan seemed adequate but I had a Noctua NF-F12 to mount. While nearly noiseless, the air flow through the heat exchanger is not very impressive.

I did not use the included paste. I used AC Silver 5.

Rig: i5-4690K (not overclocked) mounted to GA-Z97X-SLI. Windows 8.1.

The case is a Corsair C70 Vengeance. This fan fit within the case with a clearance of about 1/2" to the side cover. While that is too tight to mount a fan on the inside of the cover, the proximity allows for external air to be drafted through the cover holes by the fan as it blows toward the heat exchanger and rear of the case.

I've not had 200 hours of burn in yet to set the AC-5 properly, but here are some closed case temperatures at 74 degree room temperature:

Intel XTU 5.1.0.23 (which does not properly report processor speeds) raised the maximum core temperature to 64C during a 10 minute stress test.

Prime95 26.6 for 20 minutes created a maximum core temperature to 66 C

Prime 95 28.5 (not recommended) raised the maximum core temperature to 84 C

Prime95 26.6 run at the same time as Furmark 1.14.1 for a 20 minute test raised the maximum core temperature to 68 C

I would say that the heat exchanger works fine even with modest airflow. For my use, this was a great deal at $22.

Once the paste sets up, I will try overclocking and posting a follow up.

Did you find this review helpful? Yes No

  • Jeffrey M.
  • 3/8/2014 4:36:21 PM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsSolid HSF

Pros: 1. Easy installation on AMD system
2. Good cooling on par with most other 120mm tower coolers
3. Reasonable price
4. Quiet rubberized fan

Cons: None

Other Thoughts: I bought this on a whim when assembling an AM3 system. I noticed it had an integrated AMD clip so no tools would be needed. Installation was a snap and the X4 980 is idling at 33C and hitting 48C running Prime95. This is in a somewhat cramped case with only one intake, one exhaust and one side panel fan. All in all I'm pretty happy with one of the less popular brands and am glad I didn't go the usual Cooler Master 212 Evo route. I feel this one's just as good for my build.
