General

Brand

GIGABYTE

Model

GB-BXi5-4570R

Color

Black

CPU Supported

CPU Type

Intel Core i5-4570R 3.20 GHz

Memory Supported

Memory slot

2 x 204Pin SO-DIMM

Memory Type Supported

DDR3L 1600/1333 (1.35V)

Max Memory Supported

16GB

Expansion Slots

Other

1 x mSATA slot
1 x Half-size mini-PCIe slot occupied by the WiFi+BT card

Graphics

Onboard Video

Intel Iris Pro graphics 5200

Audio

Onboard Audio

Realtek ALC269

Communications

LAN

Realtek RTL8111G

Max LAN Speed

10/100/1000Mbps

Wireless LAN

802.11 a/b/g/n/ac

Bluetooth

Bluetooth 4.0

Front Panel Ports

Front USB

2 x USB 3.0

Front Audio Ports

1 x head phone jack with SPDIF

Back Panel Ports

HDMI

1 x HDMI

VGA

1 x Mini DisplayPort

Rear USB

2 x USB 3.0

RJ45

1

Other Rear Ports

1 x DC-In
1 x Kensington lock slot

Power Supply

Input

AC 100-240V

Power Supply

Output: DC 19V
7.1A

Physical SPEC

Dimensions

4.5" x 4.4" x 2.4"

Features

Features

Features Intel 4rd generation Core processors

Intel Iris Pro graphics 5200

Supports 2.5" Hard Drives (1 x 6Gbps SATA 3)

Ultra compact PC design - 0.79L (62 x 111.4 x 114.4 mm)

1 x mSATA SSD Slot

2 x SO-DIMM DDR3L Slots (1333 / 1600 MHz)

802.11 a/b/g/n/ac Wi-Fi / Bluetooth 4.0 Mini-PCIe card

HDMI plus Mini DisplayPort Outputs (supports dual displays)

4K resolution output (4096 x 2304 via HDMI)

Headphone jack with S/PDIF

VESA mounting bracket (75 x 75mm + 100 x 100mm)
