Specifications: Interface: IDE to SATA
Cable Length: 18.11" (460mm)
Features: Converts IDE Devices (Hard Drive, CD-ROM, CD-RW, DVD ROM, DVD + RW, etc…) to Serial ATA Connection
Supports ATAPI, ATA/133, ATA/100, ATA/66, ATA/33, and IDE Devices
Compliant with ATA Specifications
Compliant with Serial ATA Gen 1.0
1 IDE Input Port
1 SATA Output Port
Features: Unique bi-directional SATA – IDE converter
Supports 3.5-inch SATA and IDE (ATA) hard drive
Supports 5.25-inch SATA and IDE (ATA) optical drives
Power-On and HDD-Activity LED indicators
Ultra low power consumption
Connectors: one IDE (ATA) connector, one SATA host connector (Yellow), one SATA device connector (Black) and one 4-pin FDD power connector
Two independent Ultra ATA channels with 128/256 bytes buffer per channel
Driverless. No driver is needed
Serial ATA Interface
Complies with SATA 1.0a specification
Supports SATA Generation 1 with transfer rate up to 1.5Gbps (150MB/s)
Supports Spread Spectrum in receiver
Supports SATA power saving mode: Partial and Slumber
IDE (ATA) Interface
Complies with ATA Specification
Complies with Ultra ATA 133 with transfer rate up to 133MB/s
Supports PIO mode o, 1, 2, 3, 4, 5, 6, MDMA mode 0, 1, 2 and Ultr...
Specifications: Compliant with IDE-PATA PIO/DMA/Ultra DMA 66/100/133 Mbps
Power SATA and Molex cable, SATA cable and PATA cable included
Led indicators for power and hard disk activity
ON/OFF switch. Powered by 2A external power adapter
Specifications: Connector Types: 1 - IDE 40 pin Male
Connector Types: 1 - SATA Data 7 pin Plug
Connector Types: 1 - SATA Power Plug
Connector Types: 1 - SP4 Male
Enclosure Type: Steel
LBA support: 48-bit
Product Height: 1.02 in [26 mm]
Product Length: 3.98 in [101 mm]
Product Weight: 3.67 oz [104 g]
Product Width: 3.07 in [78 mm]
Humidity: 8% ~ 90% RH
Operating Temperature: 5°C to 80°C (41°F to 176°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Chipset ID: JMicron JM20330
OS Compatibility: OS independent; No software or drivers required
1 x 40 pin IDE connector for host connection
1 x 7+15pins Serial ATA port for SATA hard drive
1 x 4-pin power connector
Features: Converts IDE connector for Serial ATA Drive
Compatible with Ultra ATA 100/133 with Data transfer rate up to 1.5 Gbps (150 MB/s)
No Driver required
Supports SATA devices such as CD/DVD Drives, CD/DVD Burners....)
Supports up to 2 channels & 2 devices
With no Jumpers, makes it easy for configuration
Specifications: The serial ATA to IDE converter allows standard parallel ATA hard disk drive, CD-ROM, CD-RW, DVD ROM, DVD + RW, etc, to be used with serial ATA PCI cards or motherboards with serial ATA port and meet the specification of Serial ATA 1.0 interface.
Features: Compliance with Serial ATA Gen 1.0.
Master/slave device emulation support.
Support PIO mode 0~4.
Support Ultra DMA mode 0~7.
Support UDMA data transfer rates of up to 150MBps
Support ATAPI Packet command set.
Support 48-bit LBA addressing.
Support additional ATA command for serial ATA SCR access.
Serial ATA power save mode supported.
Serial ATA BIST operation.
Package Contents: Serial ATA to IDE Converter
Specifications: Chipset ID: Sunplus - SPIF223A
1 - SP4 (4 pin; Small Drive Power) Male
2 - SATA (7 pin; Data) Plug
Host Connectors: 1 - IDE (40 Pin; EIDE/PATA) Female
Type and Rate: SATA I (1.5 Gbps)
OS Compatibility: OS independent; No Software or drivers required
Specifications: Chipset ID: JMicron - JM20337
Color: Black & Silver
Compatible Drive Types (Type and Rate): SATA & IDE
Drive Connectors: IDE (44 Pin
2.5" HDD) Female
SATA Data & Power Combo (7+15 pin) Receptacle
Drive Installation: Fixed
Drive Size: 2.5in
Enclosure Type: Aluminum and Plastic
Host Connectors: USB Mini-B (5 pin) Female
Humidity: 0~90% RH
Included in Package: 2.5in HDD Enclosure
USB mini-B Y cable
Interface: USB 2.0
LED Indicators: Blue (Solid - Power, Blinking - Activity)
Max Drive Capacity: Currently tested with up to 1TB 5400 RPM hard drives
Number of Drives: 1
OS Compatibility: Windows® 8/8.1 (32/64bit), 7 (32/64bit), Server 2008 (32/64), Vista(32/64), Server 2003 (32/64) XP(32/64), 2000
Specifications: Interface: SuperSpeed USB 3.0, 10-Pin, Micro B, Female
Works with 2.5" IDE or SATA hard disk drives
Supports multiple 2.5" hard disk form factors(7mm, 9mm and 12.5mm)
Supports SuperSpeed USB 3.0 data transfer rate up to 5Gb/s
Supports Serial ATA bus bandwidth up to 6Gb/s
Compliant with Universal Serial Bus 3.0 Specification
Compliant with Serial ATA Specification 2.6
Supports USB Mass Storage Class Bulk-Only Transport
USB 3.0 Y-split cable:
9-Pin, Type A, USB 3.0, Male
10-pin, Micro B, Male
4-pin, Type A, USB 2.0, Male (to supply power only)
Length: 27 inches
Certifications/Standards: FCC, CE, RoHS
Desktop or notebook PC with an available USB 2.0/3.0 port (USB 3.0 recommended)
Windows 7 (32-/64-bit) / Vista (32...
