Security: 802.1X: RADIUS authentication and accounting, MD5 hash
Supports time-based 802.1X
Dynamic VLAN assignment
Locks MAC addresses to ports, and limits the number of learned MAC addresses
Broadcast, multicast, and unknown unicast
Standards: IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100 Base-Tx Ethernet
IEEE 802.3ab 1000 Base-T Ethernet
IEEE 802.3z 1000Base-X Ethernet
IEEE 802.3x Flow control
IEEE 802.1d Spanning tree protocol
IEEE 802.1w Rapid Spanning tree protocol
IEEE 802.1p Class of service
IEEE 802.1Q VLAN tagging
IEEE 802.1x Port authentication
IEEE 802.3ad LACP aggregation
Ports: 8 x 10/100Base-T and 1 dual personality Gigabit interface (RJ-45 or SFP open slot)
1 x D-Sub 9-pin Female (DCE) console port.
MAC Address Table: 8K
Security: MAC filtering per port secures access to each port
Specific MAC forwarding per port allows only specified MAC addresses to access the network (port lock)
IEEE 802.1x port-based security preventing unauthorized users from accessing the network
256 static VLAN and up to 4K dynamic VLAN
Full range 4K PVID
MAC Freeze
...
Standards: IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100 Base-Tx Ethernet
IEEE 802.3ab 1000 Base-T Ethernet
IEEE 802.3z
IEEE 802.3x Flow control
IEEE 802.1d Spanning tree protocol
IEEE 802.1w Rapid Spanning tree protocol
IEEE 802.1p Class of service, priority protocols
IEEE 802.1Q VLAN tagging
IEEE 802.1x Port Authentication
IEEE 802.3ad LACP aggregation
Ports: 24 x 10/100M RJ-45 + 2 x RJ-45 or SFP Gigabit Port
MAC Address Table: 8K
Security: MAC filtering per port secures access to each port
Specific MAC forwarding per port: only specified MAC addresses can access the network (port lock)
802.1x port-based security, prevent unauthorized client access to the network
256 static VLAN, up to 4K dynamic VLAN
MAC Freeze
Security: 802.1X: RADIUS authentication and accounting, MD5 hash
Supports time-based 802.1X
Dynamic VLAN assignment
Locks MAC addresses to ports, and limits the number of learned MAC addresses
Broadcast, multicast, and unknown unicast
Standards: IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100 Base-Tx Ethernet
IEEE 802.3ab 1000 Base-T Ethernet
IEEE 802.3z 1000Base-X Ethernet
IEEE 802.3af Power over Ethernet
IEEE 802.3x Flow control
IEEE 802.1d Spanning tree protocol
IEEE 802.1w Rapid Spanning tree protocol
IEEE 802.1p Class of service, priority protocols
IEEE 802.1Q VLAN tagging
IEEE 802.1x Port Authentication
IEEE 802.3ad LACP aggregation
Ports: 8 x 10/100Base-T and 1 dual personality Gigabit interface (RJ-45 or SFP open slot).
1 x D-Sub 9-pin Female (DCE) Console port.
MAC Address Table: 8K
Security: MAC filtering per port secures access to each port
Specific MAC forwarding per port: only specified MAC addresses can access the network (port lock)
802.1x port-based authentication, preventing unauthorized users from accessing the network
256 static VLAN, up t...
Ports: 24 x auto-sensing 10/100 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX)
1 x RJ-45 serial console port
2 x dual-personality ports
each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T; IEEE 802.3u Type 100Base-TX; IEEE 802.3ab 1000Base-T Gigabit Ethernet) or an open mini-GBIC slot (for use with mini-GBIC transceivers)
Type: NC382m PCI Express Dual Port Multifunction Gigabit Server Adapter
Specifications: Compliant Standards: IEEE 802.3, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP)
Processor: 1 x BCM5709S - Broadcom
Interface (Bus) Type: PCI Express x4
Interfaces: 2 x Network
Data Transfer Rate: 1 Gbps
Power supply type: 4 Watt maximum
OS Required:
SuSE Linux Enterprise Server, Novell NetWare 6.5, Red Hat Enterprise Linux, SunSoft Solaris 10, Novell Open Enterprise Server, Microsoft Windows 2003, Microsoft Windows Server 2008.
Dimensions: 1.44" x 8.75" x 11.31"
Weight: 1 lbs.
