Specifications: Max 1024 x 768 Range (ft): 150 ft.
Max 480P Range (ft): 154 ft.
Max 1440 x 900 Range (ft): 150 ft.
Max 1080i Range (ft): 150 ft.
Max 1080P Range (ft): 150 ft.
Max 480i Range (ft): 154 ft.
Max 640 x 480 Range (ft): 150 ft.
Max 800 x 600 Range (ft): 150 ft.
Max 1600 x 1200 Range (ft): 150 ft.
Max 720P Range (ft): 150 ft.
Specifications: Long-Distance Data Transfer to 1 Device—Up to 164 ft. (50 m) from the Source
Send data to a USB 2.0 device located up to 164 ft. from the source
USB signals travel over a single user-supplied Cat5/Cat6 cable
Includes transmitter with built-in USB-A cable and a 1-port receiver
Supports data transfer rates up to 480 Mbps
Greater Distance over Cat5/Cat6 Cable Provides Greater Flexibility
Cat5/Cat6 cabling exceeds the 16 ft. distance limitation of USB cables
Allows connection to devices that lack network connectivity in areas beyond the reach of standard USB cables
Makes connections in areas without network availability
Allows source to be in a secure location, separate from peripherals
Cat5/Cat6 cabling is cost-effective and readily available
For best resul...
Specifications: Unmanaged Network Switch for Home/Small Offices or Workgroups
8 twisted-pair RJ45 Gigabit Ethernet ports
Auto-negotiable 10/100/1000 Mbps
Automatic MDI/MDIX cross-over detection
16 Gbps switching capacity (2 Gbps per port with full duplex)
Easy-to-read LEDs indicate connection and activity status for each port
Supports 9k jumbo frames
Supports MAC address auto-learning and auto-aging
Supports 802.3x flow control (full duplex) and back pressure (half duplex)
Compliant with IEEE 802.3az Energy Efficient Ethernet Standards
Automatically shifts unused ports to low-power state without interrupting network connection
Consumes very little input power - just 1W
Also meets IEEE 802.3ab, 802.3i, 802.3u and 802.3 standards
Durable Housing
Fanless design for silent operation
Detachable 5 ft. AC power cord with...
Specifications: Unmanaged Network Switch for Home/Small Offices or Workgroups
5 twisted-pair RJ45 Gigabit Ethernet ports
Auto-negotiable 10/100/1000 Mbps
Automatic MDI/MDIX cross-over detection
10 Gbps switching capacity (2 Gbps per port with full duplex)
Easy-to-read LEDs indicate connection and activity status for each port
Supports 9k jumbo frames
Supports MAC address auto-learning and auto-aging
Supports 802.3x flow control (full duplex) and back pressure (half duplex)
Compliant with IEEE 802.3az Energy Efficient Ethernet Standards
Automatically shifts unused ports to low-power state without interrupting network connection
Consumes very little input power—just 1W
Also meets IEEE 802.3ab, 802.3i, 802.3u and 802.3 standards
Heavy-Duty Metal Housing
Fanless design for silent operation
Detachable 5 ft. AC power cord with NEMA 1-15P plug
...
Specifications: Unmanaged Network Switch for Home/Small Offices or Workgroups
5 twisted-pair RJ45 Gigabit Ethernet ports
Auto-negotiable 10/100/1000 Mbps
Automatic MDI/MDIX cross-over detection
10 Gbps switching capacity (2 Gbps per port with full duplex)
Easy-to-read LEDs indicate connection and activity status for each port
Supports 9k jumbo frames
Supports MAC address auto-learning and auto-aging
Supports 802.3x flow control (full duplex) and back pressure (half duplex)
Compliant with IEEE 802.3az Energy Efficient Ethernet Standards
Automatically shifts unused ports to low-power state without interrupting network connection
Consumes very little input power - just 1W
Also meets IEEE 802.3ab, 802.3i, 802.3u and 802.3 standards
Durable Housing
Fanless design for silent operation
Detachable 5 ft. AC power cord with...
Specifications: Max Supported Video Resolution: 4K x 2K (3840 x 2160) @60Hz
External Power Supply Input Specs (V / Hz / A): 100-240~50/60Hz, 0.35A
LED Indicators:
Tx: x3 ORANGE (Link Indicator, Local, Signal Transmission), x1 Green (Power)
RX: x1 Orange (Link Indicator), x1 Green (Power)
Connector A: Side A - Connector 1: (2) 3.5MM (FEMALE); MICRO-USB B (FEMALE)
Side A - Connector 2: (2) HDMI (FEMALE); LC DUPLEX (FEMALE)
Specifications: Voltage Compatibility (VAC): 100; 110; 120; 125; 127; 200; 208; 220; 230; 240
External Power Supply Input Specs (V / Hz / A): 100-240V~50/60Hz, 0.2A
External Power Supply Output Specs (V / A): 5V / 1A
External Power Supply Cord Length (ft.): 5
External Power Supply DC Barrel Connector Specs: OD: 5.5 x 2.1 x 10mm, Positive Pin, Negative Sleeve
External Power Supply Plug(s): NEMA 1-15P North America
External Power Supply Certifications: UL; cUL
Bus Powered: Yes
Max Supported Video Resolution: 4K x 2K (3840 x 2160) @30Hz
HDMI Specification: 1.4
HDCP Specification: 2.2
Audio Specification: Supports 7.1-channel LPCM, DTS-HD and Dolby-AC3 digital audio
System Requirements:
Source device with HDMI output (Blu-ray player, cable box, laptop)
Display device with H...
Specifications: Connector A: (x2) RJ45 (Female)
Connector B: (x2) DB9 (Female)
AC Adapter: (x2) Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A
Typical Applications:
Touch Screen displays
PC to PC File Transfer
Any Serial extension application
Package Contents: B165-101 Local Unit
B165-101 Remote Unit
2 External Power Supplies (Input: 100-240V, 50/60Hz, 0.5A; Output: 5V, 2A)
Owner's Manual
Connector A: Side A - Connector 1: 1 x HDMI (FEMALE)
Side A - Connector 2: 2 x RJ45 (FEMALE)
Connector B: Side B - Connector 1: 2 x RJ45 (FEMALE)
Side B - Connector 2: 2 x HDMI (MALE)
Package Contents: Transmitter unit
2 x Receiver units
2 x USB Micro-B cables, 1 ft.
External power supply w/NEMA 1-15P plug and 5 ft. cord (Input: 100–240V, 50/60 Hz, 0.5A; Output: 5V, 2A)
Mounting hardware
Owner’s manual
Specifications: Video:
Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Number of Monitors Supported: 1
Video Ports: (4) HDMI (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 1.4; HDCP 2.2
Supported Resolutions: 1280x720 (720p); 1920x1080 (1080p); 3840x2160 (4K)
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Audio:
Audio Ports: HDMI (FEMALE); TOSLINK (FEMALE)
Audio Ports Details: Pass-through audio to whichever display is currently in use, or via the Toslink port
Audio Input: HDMI
Audio Output: HDMI; Toslink
Audio Specification: Supports pass-through of Audio format including LPCM2.0/5.1/7.1
Power:
Power Source Type: AC Adapter
AC Plug Type AS/NZS 3112; BS1363; Bare Wire; CEE 7/16 Schuko; NEMA 1-15P
Power Source: Transmitter end only (Included)
Power Over Cable (Po...
Specifications: Extends and Distributes HDMI/DVI A/V, Serial and IR Control Signals over Cat5/6 Cabling
Converts source video to IP-based signal transmitted to and distributed through network switch
Adapter cable included for connecting a DVI display
Extends signal up to 328 ft.(100 m) from switch
Can also connect directly to transmitter up to 328 ft. away
Designed for Managed Network Switches with IGMP
Allows login and remote management via switch interface
Works with any analog or digital source, including DisplayPort and VGA
Connect up to 64 transmitters and 255 receivers in single managed switch installation
Enhanced Technical Features
Supports video resolutions up to 1920 x 1080(1080p) @ 60 Hz
Uses H.264 video compression standard
Transmits on 20–60 kHz IR frequency
Extends IR...
Specifications: Video Input: HDMI (FEMALE)
Video Output: HDMI (FEMALE)
Video Ports: HDMI (FEMALE); (4) RJ45 (FEMALE)
Video Ports Details: HDMI 2.0; HDCP 2.2
Max Supported Video Resolution: 3840 x 2160 @ 60 Hz
Audio Specification: True uncompressed 7.1 Channel digital audio and supports DTS-HD, Dolby-TrueHD digital audio
Type: VGA Video + Audio with RS-232 Serial and IR Control over IP Receiver
Max Extend Distance: 328 feet
Color: Black
Specifications: Extends and Distributes VGA Video + Audio, Serial and IR Control Signals over Cat5/6 Cabling
Converts source video to IP-based signal transmitted to and distributed through network switch
Extends signal up to 328 ft. (100 m) from switch
Can also connect directly to transmitter up to 328 ft. away
Designed for Managed Network Switches with IGMP
Allows login and remote management via switch interface
Works with any analog or digital source, including HDMI and DisplayPort
Connect up to 64 transmitters and 255 receivers in single managed switch installation
Enhanced Technical Features
Supports video resolutions up to 1920 x 1440, including 1080p
Uses H.264 video compression standard
Transmits on 20 - 60 kHz IR f...
Type: DisplayPort Audio/Video with RS-232 Serial and IR Control over IP Receiver
Max Extend Distance: 328 feet
Color: Black
Specifications: Communications:
Max 1024 x 768 Range (ft) 328
Max 480P Range (ft) 328
Max 1440 x 900 Range (ft) 328
Max 1080i Range (ft) 328
Max 1080P Range (ft) 328
Max 1920 x 1440 Range (ft) 328
Max 480i Range (ft) 328
Max 640 x 480 Range (ft) 328
Max 800 x 600 Range (ft) 328
Max 1600 x 1200 Range (ft) 328
Max 1920 x 1200 Range (ft) 328
Max 720P Range (ft) 328
Extends and Distributes DisplayPort A/V, Serial and IR Control Signals over Cat5/6 Cabling
Converts source video to IP-based signal transmitted to and distributed through network switch
Extends signal up to 328 ft. (100 m) from switch
Can also connect directly to transmitter up to 328 ft. away
Designed for Managed Network Switches with IGMP
Allow...
Specifications: Unmanaged Network Switch for Home/Small Offices or Workgroups
8 twisted-pair RJ45 Gigabit Ethernet ports
Auto-negotiable 10/100/1000 Mbps
Automatic MDI/MDIX cross-over detection
16 Gbps switching capacity (2 Gbps per port with full duplex)
Easy-to-read LEDs indicate connection and activity status for each port
Supports 9k jumbo frames
Supports MAC address auto-learning and auto-aging
Supports 802.3x flow control (full duplex) and back pressure (half duplex)
Compliant with IEEE 802.3az Energy Efficient Ethernet Standards
Automatically shifts unused ports to low-power state without interrupting network connection
Consumes very little input power - just 1W
Also meets IEEE 802.3ab, 802.3i, 802.3u and 802.3 standards
Heavy-Duty Metal Housing
Fanless design for silent operation
Detachable 5 ft. AC power ...
