Currently Unavailable
-
-
-
Manufacturer Warranty
Beyond any applicable Newegg return policy, this item is warranted independently by the product's Manufacturer. Below is a summary provided for convenience only and may not be accurate or current.
Use this link for full details.
- Manufacturer Limited Warranty period (parts): 1 year
- Manufacturer Limited Warranty period (labor): 1 year
Manufacturer Contact Info
Return Policies
This item is covered by Newegg.com's Standard Return Policy.
- Return for refund within: 30 days
- Return for replacement within: 30 days
- Restocking Fee: Yes
|
-
- 5
-
- 54%
- 4
-
- 25%
- 3
-
- 5%
- 2
-
- 9%
- 1
-
- 7%
| Product Rating: |

|
| Total Reviews: |
235 |
2 DoAs
- Pros: None, Two DOAS in a row, i got my 3rd one at my house now, HOPEFULLY it will work and I can write a review about it
- Cons: Read previous
- Other Thoughts: Im so tired of being stuck with my P4.. if this doesnt work this time im sending it back for refund and buying local
Copper Heatsinks (:
- Pros: Great. Very satisfied with. It has a copper heatsink for the NB and SB coolers
- Cons: Big NB cooler makes it realativelly hard to install Aftermarket big coolers
- Other Thoughts: Good Joob Gigabyte!!
Awesome Board!
- Pros: This board rocks! Running an E6300 with AC Freezer 7 Pro at 3.08ghz on stock voltage! Using 440FSB with Transcend AxeRAM DDR2-800 2x1gb memory. Memory currently running at 880mhz.
- Cons: My only complaint is the lack of rear USB ports, but doesn't deserve an egg off IMO.
- Other Thoughts: Buy this board, cheap alternative for learning how to overclock.
| Model |
| Brand |
GIGABYTE |
| Model |
GA-965P-S3 |
| Supported CPU |
| CPU Socket Type |
LGA 775 |
| CPU Type |
Core 2 Quad / Core 2 Extreme / Core 2 Duo |
| FSB |
1066/800MHz |
| Supported CPU Technologies |
Hyper-Threading Technology |
| Chipsets |
| North Bridge |
Intel P965 Express |
| South Bridge |
Intel ICH8 |
| Memory |
| Number of Memory Slots |
4×240pin |
| Memory Standard |
DDR2 800 |
| Maximum Memory Supported |
8GB |
| Channel Supported |
Dual Channel |
| Expansion Slots |
| PCI Express x16 |
1 |
| PCI Express x1 |
3 |
| PCI Slots |
3 |
| Storage Devices |
| PATA |
1 x ATA100 2 Dev. Max |
| SATA 3Gb/s |
6 |
| Onboard Video |
| Onboard Video Chipset |
None |
| Onboard Audio |
| Audio Chipset |
Realtek ALC883 |
| Audio Channels |
8 Channels |
| Onboard LAN |
| LAN Chipset |
Marvell 8056 |
| Max LAN Speed |
10/100/1000Mbps |
| Rear Panel Ports |
| PS/2 |
2 |
| COM |
1 |
| LPT |
1 |
| USB 1.1/2.0 |
4 x USB 2.0 |
| S/PDIF Out |
1 x Optical, 1 x Coaxial |
| Audio Ports |
6 Ports |
| Onboard USB |
| Onboard USB |
4 x USB 2.0 |
| Physical Spec |
| Form Factor |
ATX |
| Dimensions |
12.0" x 8.3" |
| Windows Vista |
Certified for Windows Vista |
| Power Pin |
24 Pin |
| Features |
| Features |
This product does not support Win9X/ME
Notice: Only DDR2-800 memory supporting JEDEC approved 1.8V operation with timings of 5-5-5 or 6-6-6 is supported on Intel Desktop Boards based on Intel 965 Express Chipsets. |
| Manufacturer Warranty |
| Parts |
1 year limited |
| Labor |
1 year limited |
Introduction
Supporting the next-generation Intel Core 2 Duo and Core 2 Extreme processors, the GIGABYTE GA-965P-S3 motherboard delivers high performance and a complete arsenal of great tuning tools for DIY and power users to customize system performance to incredible heights.
The GIGABYTE GA-965P-S3 motherboard utilizes the latest Intel P965 chipset to deliver up to 8 GB dual-channel DDR2 800/667/533 memory with Fast Memory Access technology for maximum platform performance. Other features include 6 SATA 3Gb/s connectors, 8-channel onboard HD Audio and PCIe Gigabit LAN support.
Highlights
 |
Intel P965+ICH8 Chipset
The Intel P965 Express Chipset incorporates Intel Fast Memory Access technology to significantly increase overall system performance by optimizing available bandwidth and reduction of memory access latency. Up to dual-channel DDR2 800 memory is supported by the P965 chipset to provide 12.8 GB/s peak memory bandwidth for greater platform performance and memory flexibility. The ICH8 also features SATA 3Gb/s, High-Speed USB 2.0 and HD Audio support.
|
 |
Intel Core 2 Processor Support
This motherboard supports the next-generation LGA 775 Intel Core 2 processors, including the Core 2 Duo and Core 2 Extreme. With new Intel Core microarchitecture technology, the Intel Core 2 processors are considered some of the most powerful and energy efficient CPUs in the world.
|
 |
Speed
"Speed"-compliant GIGABYTE S-series motherboards provide extensive over-clocking and over-voltage settings through both the BIOS and an intelligent software interface for user-friendly operation.
|
 |
Smart
GIGABYTE S-series motherboards provide GIGABYTE proprietary "Smart" software such as Download Center, @BIOS, Q-Flash, Xpress Install, Boot menu, and Smart Fan. BIOS as well as driver updates and management become much easier and user friendly with GIGABYTE Smart features!
|
 |
Safe
"Safe" is a key feature of the GIGABYTE S-series motherboards with the following elements: Excellent hardware reinforced BIOS protection through GIGABYTE Virtual Dual BIOS Technology and GIGABYTE BIOS Setting Recovery Technology. Unique system software such as Xpress Recovery 2, PC Health Monitor, HDD S.M.A.R.T., and Corporate Online Manager (C.O.M.) further strengthen the stability and reliability of your PC!
|
Quick Specs
| CPU Socket Type | LGA 775 |
| CPU Type | Core 2 Quad / Core 2 Extreme / Core 2 Duo |
| FSB | 1066/800MHz |
| North Bridge | Intel P965 Express |
| South Bridge | Intel ICH8 |
| PCI Express x16 | 1 |
| SATA 3Gb/s | 6 |
| Max LAN Speed | 10/100/1000Mbps |
| USB 1.1/2.0 | 4 x USB 2.0 |
| Form Factor | ATX |
|
|
Reviewed By: tvdang7 on 9/24/2006
Tech Level: somewhat high - Ownership: less than 1 day
