A simple and inexpensive motherboard for the enthusiast or the first time builder, the MSI K9MM-V is a great starting point for anyone wanting to build a system or upgrade their motherboard. Designed with the small form factor case in mind, this motherboard will fit into most smaller desktop systems. Equipped with an AMD socket AM2, suitable for Athlon 64 processors, including the X2 and FX series, the K9MM-V is more than capable of handling anything you may want to run.
Using the VIA K8M800 chipset, the K9MM-V adds up to 2GB’s of DDR2 memory to give you powerful support for memory intensive applications. It also includes a 10/100 Ethernet port, onboard 5.1 channel sound, and 2 SATA ports. Add multiple hard drives to the system through those ports -- the K9MM-V supports RAID 0 and RAID 1.
It has multiple expansion slots, including one AGP slot for those older graphics cards, and three additional PCI slots. Build your ideal system: the MSI K9MM-V is a great start.
-
- 5
-
- 32%
- 4
-
- 33%
- 3
-
- 9%
- 2
-
- 13%
- 1
-
- 13%
| Product Rating: |

|
| Total Reviews: |
231 |
Rather impressive for such a good price
- Pros: Great price for an AM2 mobo that will still support AGP for those of us who just recently bought good video cards (such as the Radeon x-series) and don't want to have wasted that money. Board also installs perfectly in standard ATX case and hooks up just fine to a 20-pin power supply (doesn't actually need an adapter - the pins are safety-designed so you can't hook it up incorrectly).
- Cons: Took awhile to get booted into the O.S. The BIOS has a regular boot sequence setting (disk, CD, hard drives...), and then there is another setting for the order to check the hard drives for an O.S., so I left my O.S. drive at #2 in that sequence figuring it didn't matter. However, the mobo never checked that disk until I set it to #1, so just keep an eye out for this if you are running multiple disks.
- Other Thoughts: One of VERY few choices left for those of us who need a decent dual-core processor but aren't ready to sacrifice our AGP cards to spend a bunch more for PCI-E. Also, this board maxes out at 2GB RAM, but I put 2GB in it, and it performs absolutely smoothly, so I don't think this will be an issue.
Great Board
- Pros: AGP 8x and DDR2 800 support... Installed AMD 64 3800+ clocked stable with stock heatsink fan 2.63gh. Im sure it could go 2.71 with better cooling. Used my old geforce 6600gt runs BF2, quake4, Far CRy very smooth...
1600x1200 everything on low to mid 1024x768 on high
- Cons: Max mem voltage 2.0 !!!!
Keep that in mind when buying ram for this board.
PNY gaming ram will only run at 667 @ 2 volts needs 2.1
- Other Thoughts: Went from amd xp 1900+ 1gb pc133
TO this board amd 3800+ ddr2 667 1gb
DIdnt even have to redo the os. changed out the board cpu and ram and she updated no problems.
Old board was sk11 via chipset.
Had the latest via 4in1 installed befor the update.
| Model | K9MM-V |
| CPU Socket Type | AM2 |
| CPU Type | Athlon 64 X2 / Athlon 64 FX / Athlon 64 |
| FSB | 800MHz Hyper Transport (1600MT/s) |
| North Bridge | VIA K8M800 |
-
- 5
-
- 32%
- 4
-
- 33%
- 3
-
- 9%
- 2
-
- 13%
- 1
-
- 13%
| Product Rating: |
|
| Total Reviews: |
231 |
- Pros: Decent if you plan to use without a newer AGP 1.5v 8x card.
- Cons: MB is setup for a 1.5v slotted AGP card. However I could only get older dual slotted (1.5 & 3.3v) cards to work in the slot. I have an Powercolor HD3850 and it will boot up initially, but if you reboot/shutdown & restart - the MB will not post. Using 1.7 BIOS. Does not matter what setting you change. MSI would not troubleshoot and said to refer to their list of 12 cards for the ones that work.
- Other Thoughts: Their support response time was very prompt. But their actual support service was very very poor. I mean they basically said if it is not on their support list then you are OOL. If you look on the list you will see 1.5v slotted AGP cards. What is the point in having standard specsifications anymore?
Return Of The Penguin.....
- Pros: The price and design. You can keep your AGP video card and step up to the dual core spectrum. You'll be covered if the board gives you any problems - you got it from Newegg!
- Cons: Only one ide slot, the usb coding and haphazzard bios functionality.
- Other Thoughts: All other aspects considered, this MB enabled me to build my first dual-core machine. Against a great deal of odds, I succeeded and that in itself makes me feel great. I read all the reviews first, then proceeded to build the board with only the bare requirements before loading my OS. This worked fine, then as I added each card (video, 1394, etc., etc.) I went back in and checked the bios and made necessary adjustments to the setting. The 'Halt On Errors' was the trickiest setting to over come and I'm still dealing with it when I forget to use my keyboard if the application ask me to load something from a disk. My system has an AMD 5600+ CPU, 500 GB SATA HDD, 2 GB DDR800 RAM with an Ati Radeon X1550 video card and a 1394 firewire card. It enables me to produce great DVDs.
A Great Budget Board !!!
- Pros: It's a Solid little Board With a verry user friendly BIOS that has a lot of options for those that don't know too much. Super Easy to set up and everything worked right out of the box(Memeory, CPU etc...) Easy and forgiving to mount. There are also tons of AGP settings which pull a lot of preformance out of an AGP card
- Cons: I would have to say one con would be that the heatsink mount kinda sucks it is a bit hard to mount it but once it's on it's solid.
only one IDE slot but thats not such a big deal cuz I would rather have a working system instead of a dead one and once I get the 2 SATA drives I want it won't matter.
- Other Thoughts: I like the board, I got it cuz my system was dying and I needed something that ran a Dual-core and an AGP card cuz I didn't have money for a new Video card. The over view on newegg's site and Msi's site say that it runs an FX and the book it comes with say's on the cover "Designed for FX/X2 Processor's" Yet on MSI's Site it says the FX-62 won't work....But mine is doing just fine and it hase been on for about 3 days and I have been trying to stress it a little to see if anything is going to happen, Nothing so far. Also it list's on MSI's site the supported memory and my G.skill isn't there but it seems to be running that fine as-well. So 40 a $50 board I would say get it !
| Model |
| Brand |
MSI |
| Model |
K9MM-V |
| Supported CPU |
| CPU Socket Type |
AM2 |
| CPU Type |
Athlon 64 X2 / Athlon 64 FX / Athlon 64 |
| FSB |
800MHz Hyper Transport (1600MT/s) |
| Chipsets |
| North Bridge |
VIA K8M800 |
| South Bridge |
VIA VT8237R |
| Memory |
| Number of Memory Slots |
2×240pin |
| Memory Standard |
DDR2 800 |
| Maximum Memory Supported |
2GB |
| Channel Supported |
Dual Channel |
| Expansion Slots |
| AGP Slots |
1 x AGP 4X / 8X |
| PCI Express x16 |
None |
| PCI Slots |
3 |
| Storage Devices |
| PATA |
1 x ATA100 2 Dev. Max |
| SATA 1.5 Gb/s |
2 |
| SATA RAID |
0/1 |
| Onboard Video |
| Onboard Video Chipset |
None |
| Onboard Audio |
| Audio Chipset |
Realtek ALC655 |
| Audio Channels |
6 Channels |
| Onboard LAN |
| LAN Chipset |
Realtek 8201 PHY |
| Max LAN Speed |
10/100Mbps |
| Rear Panel Ports |
| PS/2 |
2 |
| COM |
1 |
| LPT |
1 |
| Video Ports |
D-Sub |
| USB 1.1/2.0 |
4 x USB 2.0 |
| Audio Ports |
3 Ports |
| Onboard USB |
| Onboard USB |
2 x USB 2.0 connectors support 4 ports |
| Physical Spec |
| Form Factor |
Micro ATX |
| Dimensions |
9.6 " x 8.2" |
| Power Pin |
24 Pin |
| Features |
| Features |
Due to the High Performance Memory design, motherboards or system configurations may or may not operate smoothly at the JEDEC (Joint Electron Device Engineering Council) standard settings (BIOS Default on the motherboard) such as DDR2 voltage, memory speeds and memory timing. Please confirm and adjust your memory setting in the BIOS accordingly for better system stability
Example: Kingston HyperX DDR2-800 PC-6400 operates at 2.0V, 4-4-4-12.
For more information about specification of high performance memory modules, please check with your Memory Manufactures for more details |
| Packaging |
| Package Contents |
K9MM-V
Driver Disk
User Manual
Rear I/O Panel Shield
IDE/PATA Cable
SATA Cable
Power Cable |
Introduction
A simple and inexpensive motherboard for the enthusiast or the first time builder, the MSI K9MM-V is a great starting point for anyone wanting to build a system or upgrade their motherboard. Designed with the small form factor case in mind, this motherboard will fit into most smaller desktop systems. Equipped with an AMD socket AM2, suitable for Athlon 64 processors, including the X2 and FX series, the K9MM-V is more than capable of handling anything you may want to run.
Using the VIA K8M800 chipset, the K9MM-V adds up to 2GB’s of DDR2 memory to give you powerful support for memory intensive applications. It also includes a 10/100 Ethernet port, onboard 5.1 channel sound, and 2 SATA ports. Add multiple hard drives to the system through those ports -- the K9MM-V supports RAID 0 and RAID 1.
It has multiple expansion slots, including one AGP slot for those older graphics cards, and three additional PCI slots. Build your ideal system: the MSI K9MM-V is a great start.
Highlights
 |
AMD Socket AM2
This motherboard supports AMD's Socket AM2-based CPUs, including the Athlon 64 X2, Athlon 64 FX and Athlon 64 series. With a 1600MHz system bus using Hyper Transport Technology and support for dual-channel DDR2 RAM, AM2 motherboards form the basis for phenomenal system performance.
|
 |
VIA K8M800+VT8237R Chipset
The VIA K8M800 is the world's first chipset for the AMD64 platform to feature an Integrated Graphics Processor (IGP) and an unparalleled range of cutting edge I/O and multimedia functions. Consumers and business users alike enjoy an exceptional graphics experience while unleashing the full performance potential of the AMD Athlon 64/64 X2/64 FX and Sempron processor.
|
 |
Dual-Channel DDR2 800
DDR2 next generation memory technology replaces current DDR memory and provides a walloping performance boost. With support for up to 800MHz DDR2 memory, the MSI K9MM-V delivers fantastic performance in extreme 3D graphics environments and in memory intensive applications.
|
 |
AGP 4X/8X Support
The MSI K9MM-V features a highly flexible and scalable architecture with an AGP 4X/8X port for optional graphics card upgrades. With double the bandwidth of AGP 4X, the AGP 8X video card slot produces smoother video streaming and faster, seamless gameplay while compatible backwards with 4X graphics cards.
|
 |
Serial ATA with RAID
The revolutionary Serial ATA interface provides scalable performance for storage devices. SATA technology enables easy-to-install, high-performance and low-power hard drives. Two SATA ports support RAID 0 and 1 for better performance and enhanced data security.
|
Quick Specs
| CPU Socket Type | AM2 |
| CPU Type | Athlon 64 X2 / Athlon 64 FX / Athlon 64 |
| FSB | 800MHz Hyper Transport (1600MT/s) |
| North Bridge | VIA K8M800 |
| South Bridge | VIA VT8237R |
| Memory Standard | DDR2 800 |
| SATA 1.5 Gb/s | 2 |
| PATA | 1 x ATA100 2 Dev. Max |
| Max LAN Speed | 10/100Mbps |
| USB 1.1/2.0 | 4 x USB 2.0 |
| Form Factor | Micro ATX |
|
Reviewed By: RedCorner on 5/14/2007
Tech Level: somewhat high - Ownership: 1 week to 1 month
