SUPERMICRO MBD-X10SAT-O ATX Server Motherboard LGA 1150 DDR3 1600/1333/1066

Sold and Shipped by Newegg

Purchases from these Sellers are generally covered under our Newegg Marketplace Guarantee.
Marketplace Seller
  • LGA 1150
  • Intel C226 Express chipset
  • 4 x 240pin

LOADING... LOADING...
  • Overview
  • Specifications
  • Warranty & Returns
  • Reviews
MBD-X10SAT-O

SUPERMICRO MBD-X10SAT-O ATX Server Motherboard

Features

MBD-X10SAT-O
  • Single socket H3 (LGA 1150) supports Intel® Xeon® E3-1200 v3/v4, 4th/5th gen. Core i7/i5/i3 processors
  • Intel® C226 Express PCH
  • Up to 32GB DDR3 ECC/non-ECC 1600MHz UDIMM in 4 sockets
  • Dual Gigabit Ethernet LAN ports (1x Intel® i217LM & 1x Intel® i210AT)
  • 8x SATA3 (6Gbps); 6x SATA3 via C226 and 2x SATA3 via ASM1061®
  • 3x PCI-E 3.0 x16 slots and 3x PCI-E 2.0 x1 (in x4) slots
  • 8x USB 3.0 (4 rear + 4 via headers) 6x USB 2.0 (2 rear + 4 via headers)
  • HD Audio 7.1 channel connector by Realtek ALC1150
  • 1x DOM power connector and 1x SPDIF Out Header
  • UEFI BIOS support

Specifications

Product SKUs
MBD-X10SAT X10SAT (Bulk Pack)
Physical Stats
Form Factor ATX
Dimensions 12" x 9.6", (30.48cm x 24.4 cm)
Processor/Cache
CPU
  • Intel® Xeon® processor E3-1200 v3/v4 and 4th/5th Gen Core i7/i5/i3, Pentium, Celeron processors
  • Single Socket H3 (LGA 1150)
  • A Graphic Integrated CPU is required to have the on-board video functioned. Examples: E3-1265L v3, E3-1275 v3*
System Memory
Memory Capacity
  • 4x 240-pin DDR3 DIMM sockets
  • Supports up to 32 GB DDR3 ECC/non-ECC Un-Buffered memory (UDIMM)
Memory Type 1600MHz ECC/non-ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs
DIMM Sizes 8GB, 4GB, 2GB, 1GB
Memory Voltage 1.5V, 1.35V
Error Detection
  • Corrects single-bit errors
  • Detects double-bit errors (using ECC memory)
On-Board Devices
SATA
  • SATA3 via PCH w/ RAID 0, 1, 5, 10
  • SATA3 via ASM1061®
Network Controllers
  • Intel® i217LM + Intel® i210AT Controllers
  • Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Audio RealTek ALC1150 High Definition Audio>
Chipset Intel® C226 Express PCH
Input / Output
Serial ATA
  • 6x SATA3 (6Gbps) ports via PCH
  • 2x SATA3 (6Gbps) ports via ASM1061®
  • Total of 8x SATA3 ports (6Gbps)
LAN 2x RJ45 Gigabit Ethernet LAN ports
Display* 1x VGA, 1x HDMI, 1x DVI, 1x Thunderbolt
Serial Port / Header 1x COM port (headers)
DOM SATA DOM (Disk on Module) power connector support
USB
  • 8x USB 3.0 ports (4 rear, 4 via headers)
  • 6x USB 2.0 ports (2 rear, 4 via headers)
TPM 1x TPM 1.2 20-pin Header
Firewire 1x Type B 1394a header
System BIOS
BIOS Type 128Mb SPI Flash EEPROM with AMI BIOS
BIOS Features
  • DMI (SMBIOS) 2.7
  • ACPI 5.0
  • USB Keyboard support

Whats in the Box

MBD-X10SAT-O

Learn more about the Supermicro MBD-X10SAT-O

Warranty, Returns, And Additional Information
  • Warranty
  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 3 years
  • Read full details
  • Return Policies
    • Return for refund within: Non-refundable
    • Return for replacement within: 30 days
  • This item is covered by Newegg.com's Replacement Only Return Policy.
Ownership: 1 month to 1 year
Verified Owner
1/ 5

Pros: Bought nice bundle with CPU from Newegg.

Cons: Worst support I've ever seen!

They don't reply at all absolutely ignoring your e-mails.

Then they send sudden e-mail (dated 2 months earlier!) and threatening this is the "final notice".

I'm not even sure they understand what I was talking about in my inquiries.

BTW, have you ever read Supermicro manuals? Specs are not in comply offten, they use older models manuals for new products, then trying to adjust it "on the fly".


Shortly, chinese product and chinese quality support.

Other Thoughts: Wasted money.

2 out of 6 people found this review helpful. Did you?
Ownership: 1 month to 1 year
1/ 5

Pros: Didn't have a chance to taste them

Cons: Mine was dead. Seems poor quality of assembly or parts.

0 out of 4 people found this review helpful. Did you?
Ownership: 1 week to 1 month
Verified Owner
5/ 5
Pretty awesome board

Pros: Reliable

Cons: Nada

0 out of 1 people found this review helpful. Did you?
Ownership: 1 month to 1 year
Verified Owner
5/ 5
Solid board

Pros: Easy set up. Running it with Plextor M6e and no setup problems. Very stable, Reliable

Cons: None.

Other Thoughts: I like the board. I am using it as a home workstation and gaming system running it with Plextor M6e boot drive, two Samsung EVOs, Intel 4790k, AMD 290x, and Ripjaw ram. No compatibility issues, all plug and play. The only thing I can really say that is not positive is that it can’t overclock. Clearly that is not what this board is meant for, but man that would be pretty great. I appreciate stability and stableness of the board.

4 out of 4 people found this review helpful. Did you?
Ownership: less than 1 day
1/ 5
Beware

Pros: None

Cons: Almost got ripped off and purchased this board.
The Newegg data says
"ECC Supported - Yes".
BUT... The manual downloaded from Supermicro, they say is for this motherboard, "MNL-1544" says
"DDR3 Unbuffered Non-ECC"

Also, the Newegg Data lists
SATA 8 x SATA 6.0Gb/s
Additional SATA 2 x SATA 6.0Gb/s
giving the impression of the board having 10 SATA 3 ports.
The Manual says there is a TOTAL of 8. Not 8 with 2 additional
Six (6) I-SATA
Two (2) A-SATA

Other Thoughts: The Supermicro web site is terrible and is very difficult to locate information. A search on MBD-X10SAT-O comes up "NOT FOUND". The manual is for the X10SAT.

8 out of 17 people found this review helpful. Did you?
Manufacturer Response:
Greetings,

Your comments are very important to us. The X10SAT motherboard does support ECC memory modules. As far as the manual, I have taken note of your feedback and will bring this matter to the proper people. If or when this information is internally verified, action will be taken and we will correct any issue or discrepancy in the manual . Thank you.

Regards,

Mark
Super Micro Computer
markk@supermicro.com
Ownership: less than 1 day
Verified Owner
4/ 5
You need Unbuffered Memory!

Pros: Seems like a very solid Mobo. Has a head for just about everything you could need. LGA 1150 socket is nice for cheaper Xeons / Core i series processors.

Cons: Newegg isn't specific about what kind of RAM you need to buy for it; only says ECC, doesn't say it needs to be unbuffered (UDIMM) memory. I knocked an egg for the lack of info, and the delay it has now caused in my DIY SAN project because I need to return the old RAM and get refunded so I can repurchase correct memory.

Other Thoughts: Will come back and add any other information I get once the board becomes a bootable server.

4 out of 9 people found this review helpful. Did you?
Ownership: 1 month to 1 year
Verified Owner
5/ 5
Works like a charm

Pros: Up to date features and plug and play ease.

Cons: None

Other Thoughts: My first sever build updating a 9 year old server with new board, cpu, ram and windows server 2008r2. Took me a day and a half to get my office (10 workstations running Windows 7) up and running. I am very pleased!

1 out of 1 people found this review helpful. Did you?
Ownership: 1 month to 1 year
Verified Owner
4/ 5
Decent

Pros: Nice board. Thunderbolt port. 4 USB 3.0 ports.

Cons: Was not able to get Linux installed on it.

Other Thoughts: Linux wasn't a deal breaker as I did have a Windows 7 Pro key. I think if I would have dug deeper I could have found my issue and had Linux working fine, but didn't have the time to get it working.

3 out of 4 people found this review helpful. Did you?
