ABIT AN-M2HD AM2 NVIDIA GeForce 7050PV HDMI Micro ATX AMD Motherboard

OUT OF STOCK.
  • NVIDIA GeForce 7050PV
  • Athlon 64 X2 / Athlon 64 FX / Athlon 64
  • DDR2 800
Specs
Reviews

Learn more about the Universal abit USA AN-M2HD

Model
Brand ABIT
Model AN-M2HD
Supported CPU
CPU Socket Type AM2
CPU Type Athlon 64 X2 / Athlon 64 FX / Athlon 64
FSB 1000 MHz
Chipsets
Chipset NVIDIA GeForce 7050PV
South Bridge NVIDIA nForce 630a
Memory
Number of Memory Slots 4x240pin
Memory Standard DDR2 800
Maximum Memory Supported 8GB
Channel Supported Dual Channel
Expansion Slots
PCI Express x16 1 x PCI Express x16
PCI Express x1 1 x PCI Express x1
PCI Slots 2 x PCI Slots
Storage Devices
PATA 1 x ATA100 2 Dev. Max
SATA 3Gb/s 4 x SATA 3Gb/s
SATA RAID NV RAID 0/1/0+1/5 JBOD
Onboard Video
Onboard Video Chipset NVIDIA GeForce 7050PV
Onboard Audio
Audio Chipset Realtek ALC888
Audio Channels 8 Channels
Onboard LAN
LAN Chipset Marvell 88E1116
Max LAN Speed 10/100/1000Mbps
Rear Panel Ports
PS/2 2
Video Ports D-Sub
HDMI 1 x HDMI
USB 1.1/2.0 4 x USB 2.0
IEEE 1394 1 x IEEE 1394a
S/PDIF Out 1 x Optical
Audio Ports 6 Ports
Internal I/O Connectors
Onboard USB 8 x USB 2.0
Onboard 1394 1 x 1394a
Physical Spec
Form Factor Micro ATX
Dimensions (W x L) 9.6" x 9.6"
Power Pin 24 Pin
Windows Vista Certified for Windows Vista
Additional Information
Date First Available September 18, 2007
