ABS Forge - Ryzen 7 3800X - Corsair RGB Liquid Cooler (240mm) - MSI MEG X570 ACE Gaming - Corsair iCUE 465X Case - DIY Barebone Gaming Desktop System

Sold and Shipped by Newegg

Purchases from these Sellers are generally covered under our Newegg Marketplace Guarantee.
Marketplace Seller
  • AMD RYZEN 7 3800X 8-Core 3.9 GHz (4.5 GHz Max Boost)
  • CORSAIR H100i RGB PLATINUM, 240mm, 2 X ML PRO 120mm
  • MSI MEG X570 ACE Gaming Motherboard AMD ATX
  • Corsair Crystal iCUE 465X RGB
  • Barebone System

  • Overview
  • Specifications
  • Warranty & Returns
  • Reviews
ABS Forge - Ryzen 7 3800X - Corsair RGB Liquid Cooler facing forward and ABS logo ABS Forge - Ryzen 7 3800X - Corsair RGB Liquid Cooler side view and CPU icon, COOLING icon, MOTHERBOARD icon, CASE icon

MEG X570 ACE
ACE YOUR ENEMY

MSI MEG X570 ACE Gaming labeling
Core Boost icon

Core Boost Technology

Dual 8-pin CPU power connectors and optimized power circuits let ACE unleash maximum performance.

Server-Grade PCB icon

Server-Grade PCB

Server-grade PCB fully supports the high bandwidth and fast transfer speeds of PCIe Gen 4.

M.2 Shield Frozr icon

M.2 Shield Frozr

Sustain maximum high-speed M.2 SSD data transfer with M.2 SHIELD FROZR and prevent SSD thermal throttling.

IR Digital PWM icon

IR Digital PWM

A selection of the highest quality power delivery components including IR digital power, DrMOS, and titanium choke II lets the system run reliably even under extreme conditions.

Extended Heat-Pipe icon

Extended Heat-Pipe

A heatpipe redistributes heat across the MOS heatsinks to the chipset heatsink for expanded thermal dissipation.

PCIe Steel Armor icon

PCIe Steel Armor

Reinforced and shielded PCIe slots for strength and stability.

Zero Frozr Technology icon

Zero Frozr Technology

Fan speed is automatically controlled by an AI tuning system that monitors chipset temperature and can power down temporarily in low-load situations to produce no fan noise.

Frozr Heatsink icon

Frozr Heatsink Design

The X570 chipset, with its PCIe Gen 4 capabilities, is actively cooled to sustain massive data bandwidth. The airflow fan is built with a durable ball-bearing core for long lasting operation.

ABS Forge - Ryzen 7 3800X - Corsair RGB Liquid Cooler AMD RYZEN 7 close-up ABS Forge - Ryzen 7 3800X - Corsair RGB Liquid Cooler 8 cores and 3.9 GHZ icon
ABS logo

ABS Gaming PCs are forged by Newegg to fulfill every gamer's fantasy in performance and presence. Our systems are built to withstand the most competitive players, and designed to distinguish you from the crowd. Our goal is to equip you with the most epic and unique gaming systems so you can stay ahead of the competition.

1 year warranty icon

Gamers need quality and performance to stay competitive. ABS has you covered with a no-hassle 1-year parts & labor warranty and free lifetime tech support while you game.

Our commitment text icon

To provide high-quality, high-performance gaming PCs that have been designed and tested for your gaming needs.

PERFORMANCE and QUALITY and TESTED icon

Learn more about the ABS ALA153

General

|
Brand
ABS
Series
Forge
Model
ALA153

CPU Supported

|
CPU Installed
AMD RYZEN 7 3800X 8-Core 3.9 GHz (4.5 GHz Max Boost)
CPU Socket
AMD Socket AM4

Chipset

|
North Bridge
AMD X570

Memory Supported

|
Memory installed
No Memory

Expansion Slots

|
PCI Express 4.0 x16
2 x PCIe 4.0/3.0 x16 slots (PCI_E1, PCI_E3)
- 3rd Gen AMD Ryzen support PCIe 4.0 x16/x0, x8/x8 modes
- 2nd Gen AMD Ryzen support PCIe 3.0 x16/x0, x8/x8 modes
- Ryzen with Radeon Vega Graphics and 2nd Gen AMD Ryzen with Radeon Graphics support PCIe 3.0 x8
mode*
1 x PCIe 4.0/3.0 x16 slot (PCI_E5, supports x4 mode)
* PCI_E3 slot is only available for 2nd and 3rd Gen AMD Ryzen processors
PCI Express
2 x PCIe 4.0/3.0 x1 slots (PCIE_2, PCIE_4)*
* The PCIe x1 slots can not be used simultaneously. PCI_E2 will be unavailable when installing the PCIe card
in PCI_E4 slot.
Other
1 x M2_4 Socket with E key

Storage

|
Hard Drive Installed
No Hard Drive

Communications

|
Wireless LAN
Intel Wi-Fi 6 AX200
- Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4-5 GHz (160 MHz) up to 2.4 Gbps
- The Wireless module is pre-install in the M2_4 (Key-E) slot
Max LAN Speed
10/100/1000Mbps

Front Panel Ports

|
Front USB
2 x USB 3.0

Back Panel Ports

|
PS/2
1 x PS/2 keyboard/mouse combo port
Rear USB
2 x USB 2.0 ports
2 x USB 3.2 Gen1 ports
3 x USB 3.2 Gen 2 Type A ports
1 x USB 3.2 Gen 2 Type C port
RJ45
2
Rear S/PDIF Out
1 x Optical S/PDIF OUT connector
Rear Audio Ports
5 x OFC audio jacks
Other Rear Ports
1 x Clear CMOS Button
1 x Flash BIOS Button
1 x Wi-Fi/Bluetooth module

Physical SPEC

|
Dimensions
17.91" x 8.50" x 18.39"

Additional Information

|
Date First Available
October 02, 2019
Warranty, Returns, And Additional Information
  • Warranty
  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year
  • Read full details
  • Return Policies
    • Return for refund within: 30 days
    • Return for replacement within: 30 days
  • This item is covered by Newegg.com's Standard Return Policy.
Ownership: 1 week to 1 month
Verified Owner
2/ 5
Excellent System, Poor Assembly 3/11/2020 3:27:58 PM

Pros: Amazing processor

Cons: Wrong connections and an unlabeled rats nest of wires hidden in the side opposite of the glass. There was an unlabeled SATA connector in a jumble of wires that turned out to be the power for the liquid cooling pump..a system critical wire mixed in with a nest of RGB cables, none labeled. Part of the rats nest was the RGB hub for the fans, this module was connected wrong so that the top two fans had no colors but the front 3 did. This was due to the fact they plugged in ports 1, 2 , 3 , 5, and 6..they skipped port 4. It clearly states in the iCue case manual that they must be plugged in sequential order. Changing to 1,2,3,4,5 allowed all fans to light up and be controlled.

Overall Review: Great system that I am extremely pleased with after sorting out the sloppy case and coolant wiring.

Did you find this review helpful?
Manufacturer Response:
Hi Harrison,

We are very sorry for the inconvenience that you've experienced. This order does not meet our high quality standards and I will forward your experience to our assembly for further investigation. I'm glad you were taken care of by our customer service. If you have any questions about your product please feel free to contact customercare@abs.com or call us at (800)685-3471. We will be glad to answer all your questions in a timely manner.

Thank you again,
ABS Customer Support
Ownership: 1 week to 1 month
Verified Owner
5/ 5
My first build 12/12/2019 9:33:08 AM

Pros: Nicely done barebones system. Great price on sale. Its quite easy to complete the build.

Cons: Wish it had diagram of connections to PSU and mark those that are not needed.

Overall Review: Good deal which resulted in in great looking PC build. Highly recommend.
