POWER SUPPLY/CHARGER WITH ACCESS POWER

Model AL600ULACM converts a 115VAC 60Hz input into eight (8) independently controlled 12VDC or 24VDC non power limited fuse protected Fail-Safe and/or Fail-Secure outputs with a total of 6 amp continuous supply current. The fire alarm disconnect feature enables emergency egress in the event the fire alarm system is activated. It is individually selectable for any or all of the eight (8) outputs. Model AL600ULACMCB is a PTC protected version of this unit. Product Type: Proprietary Power Supply Input Voltage: 110 V AC Output Voltage: 24 V DC Output Voltage: 12 V DC Product Type: Proprietary Power Supply Input Voltage: 110 V AC Manufacturer Part Number: AL600ULACM Packaged Quantity: 1 Limited Warranty: Lifetime Output Voltage: 24 V DC @ 6 A Output Voltage: 12 V DC @ 6 A Weight (Approximate): 11.60 lb Form Factor: Internal Form Factor: Internal Manufacturer: Altronix Corporation Product Model: AL600ULACM Product Name: ACM AL600ULACM Proprietary Power Supply Brand Name: Altronix Product Series: ACM Brand Name: Altronix Country of Origin: United States Product Family: ACM Environmentally Friendly: Yes Environmental Certification: RoHS
