ASRock 890GX EXTREME4 AM3 AMD 890GX USB 3.0 HDMI ATX AMD Motherboard
- AMD 890GX
- Phenom II / Athlon II / Sempron 100 Series Supports CPU up to 140W
- DDR3 2000(OC)/1866(OC)/1800(OC)/1600(OC)/1333/1066/800
Specs
Reviews (35)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the ASRock 890GX EXTREME4
| Brand | ASRock |
|---|---|
| Model | 890GX EXTREME4 |
| CPU Socket Type | AM3 |
|---|---|
| CPU Type | Phenom II / Athlon II / Sempron 100 Series Supports CPU up to 140W |
| FSB | 2600 MHz |
| Chipset | AMD 890GX |
|---|---|
| South Bridge | AMD SB850 |
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR3 2000(OC)/1866(OC)/1800(OC)/1600(OC)/1333/1066/800 |
| Maximum Memory Supported | 16GB |
| Channel Supported | Dual Channel |
| PCI Express 2.0 x16 | 3 (PCIE2/PCIE3: single at x16 or dual at x8/x8 mode; PCIE4: x4 mode) |
|---|---|
| PCI Express x1 | 1 x PCI Express x1 |
| PCI Slots | 3 x PCI Slots |
| Serial ATA (SATA) | 5 x SATA 6Gb/s |
|---|---|
| SATA RAID | 0/1/5/10 |
| Onboard Video Chipset | ATI Radeon HD 4290 |
|---|
| Audio Chipset | Realtek ALC892 |
|---|---|
| Audio Channels | 8 Channels |
| LAN Chipset | Realtek 8111E |
|---|---|
| Max LAN Speed | 1Gbps |
| Back I/O Ports | 1 x D-Sub / 1 x DVI / 1 x HDMI / 1 x PS/2 / 2 x USB 3.1 Gen 1 / 4 x USB 2.0/1.1 / 5 x Audio Jacks |
|---|---|
| PS/2 | 1 x PS/2 Keyboard Port |
| Video Ports | D-Sub + DVI |
| HDMI | 1 x HDMI |
| USB 3.0 | 2 x USB 3.0 |
| USB 1.1/2.0 | 4 x USB 2.0 |
| IEEE 1394 | 1 x IEEE 1394 Port |
| eSATA | 1 x eSATA 6Gb/s |
| S/PDIF Out | 1 x Optical |
| Audio Ports | 5 Ports |
| Onboard USB | 2 x USB 3.0 + 6 x USB 2.0 |
|---|---|
| Onboard 1394 | 1 x IEEE 1394 |
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 9.6" |
| Power Pin | 24 Pin |
| Features | ErP/EuP Ready Six-Core CPU Ready Supports UCC feature (Unlock CPU Core) Supports ATI Quad CrossFireX, 3-Way CrossFireX, CrossFireX and Hybrid CrossFireX ASRock DuraCap (2.5 longer life time), 100% Japan-made high-quality Conductive Polymer Capacitors Dr. Debug, Smart Swith Design: Power/Reset/Clear CMOS Switch with LED Supports ASRock Instant Boot, Instant Flash, OC Tuner, IES, OC DNA, Good Night LED, Multi-Speed Fan Control, AIWI, APP Charger |
|---|
| Date First Available | August 25, 2010 |
|---|
