Brand | ASRock |
---|---|
Model | 890GX PRO3 |
CPU Socket Type | AM3+ |
---|---|
CPU Type | FX / Phenom II / Athlon II / Sempron 100 Series |
FSB | 2600 MHz |
Chipset | AMD 890GX |
---|---|
South Bridge | AMD SB850 |
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR3 2000(OC)/1866(OC)/1800(OC)/1600(OC)/1333/1066/800 |
Maximum Memory Supported | 32GB |
Channel Supported | Dual Channel |
PCI Express 2.0 x16 | 2 (x16, x4) |
---|---|
PCI Express x1 | 1 x PCI Express x1 |
PCI Slots | 3 x PCI Slots |
SATA 6Gb/s | 5 x SATA 6Gb/s |
---|---|
SATA RAID | 0/1/0+1/5 |
Onboard Video Chipset | ATI Radeon HD 4290 |
---|
Audio Chipset | Realtek ALC892 |
---|---|
Audio Channels | 8 Channels |
LAN Chipset | Atheros AR8151 |
---|---|
Max LAN Speed | 10/100/1000Mbps |
PS/2 | 1 |
---|---|
Video Ports | D-Sub + DVI |
HDMI | 1 x HDMI |
USB 3.0 | 2 x USB 3.0 |
USB 1.1/2.0 | 4 x USB 2.0 |
IEEE 1394 | 1 x IEEE 1394 |
eSATA | 1 x eSATA 6Gb/s |
S/PDIF Out | 1 x Optical |
Audio Ports | 5 Ports |
Onboard USB | 6 x USB 2.0 |
---|---|
Onboard 1394 | 1 x 1394 |
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12.0" x 9.6" |
Power Pin | 24 Pin |
Features | Supports 8-Core CPU 100% All Solid Capacitor design Supports Dual Channel DDR3 1866(OC) Supports ATI Quad CrossFireX , CrossFireX and Hybrid CrossFireX Integrated AMD Radeon HD 4290 graphics, DX10.1 class iGPU, Shader Model 4.1 Multi VGA Output : D-Sub, DVI-D and HDMI 2 x USB 3.0, 5 x SATA3, 2 x IEEE 1394 Dr. Debug, Power/Reset/Clear CMOS Switch with LED Supports XFast USB, AXTU, UEFI, Instant Boot, Instant Flash, APP Charger, SmartView, Turbo UCC 7.1 CH HD Audio with Content Protection (Realtek ALC892 AUdio Codec), Supports Premium Blu-ray audio |
---|
Date First Available | March 29, 2011 |
---|
Pros: AM3+ socket so Bulldozer ready (fingers crossed). High speed USB (yes, it works!) Externally accessible CMOS reset (if you overclock you want this). Heatsinked VRMs, very important for overclocking, particularly with 4+1 design. Excellent IGP for HTPC functions. On board power on and reset buttons - you may only use this once when you're breadboarding a new build but *very* useful in those circumstances. Sexy UEFI bios. It looks nice :)
Cons: No "Turbo UCC" although they brag about it on the Asrock website. It's not there for me, but no worries. I find the vertically stacked SATA connectors to be a PITA. If I had it do over again I'd attach all the SATA cables to the MB *before* I put it in the case. I had to retire two IDE drives I'd like to have used because this board doesn't have the PATA controller some others do, no big deal.
Overall Review: I started out in computers with Macs and had them for years (1992-1998). When I decided that the best shareware/freeware was being developed for Windows I switched, starting with Window 98 and a Celeron. I discovered I *love* choosing my own motherboard. I just love motherboards. The first Windows pc I built had an Abit BX MB. When it came time to upgrade I was disappointed Abit was oob. So I bought an Asus Intel board that was really solid for a number of years. When it came time to build again I'd decided to go AMD and I bought another Asus board. Unfortunately it was DOA and I then realized that Bulldozer was around the corner and I'd be better served with a "real" AM3+ socket board of which there were very few. Plus I needed MB graphics because I don't game and didn't want to pay for a GPU (plus 900 series boards don't support MB graphics). So this Asrock really fit the ticket. I'm very glad I bought it.
