Q: Waiting to receive it. Will provide feedback of the build if I decide to keep it. Q: I reviewed the rebate and it seems to want my password for my email. If that's the case I am not going to provide it for $20. Am I wrong? What can I put in that space?

No, it is not for your actual email. It is for reference only and tracking purposes. Enter a made up password and use that for log in to the track your rebate.

Q: Is it compatible with the AMD Fx-6300 Vishera 3.5ghz?

That would be a big negative.. This is a Intel Haswell LGA1150 motherboard. Its compatible with Haswell processors and some LGA1150 server side processors. A AMD FX-6300 would only work on a AM3+ socket motherboard. I used to have a FX-6100 with an AM3+ motherboard myself, upgraded to a 4670k Haswell CPU with this particular motherboard, the difference is night and day..

Q: Is this board compatible with only 1 stick of ram or does it need 2? Please answer from personal experience!

As far as I know, [20 years of building and selling computers] ONE stick [must have two?] main boards went out in the 90s. I haven't seen any boards other than a few odd ball HPs, Gateways, and Compaqs back a few years ago that wouldn't run unless you had a matched pair or a dummy chip to make the connections. I bought two chips for this board and run them in the four slots [bank A & B] and that works fine. Perhaps one day I will expand it to the max. I thought I read if you run one chip, [and even a pair] set it in slot A? Also If you run two different sizes you MAY have to run them in different banks but that I cant swear on? Some boards don't count mis-matched sizes properly? If you need more I could locate the owners manual but from what I read it wasn't "one of those" that I have come across too many times, like the ones that you unplug and plug back in to "fix" the quirks?

Q: here are a few dumb questions from someone with no experience: This motherboard comes with a processor? Can i just replace this board in an existing tower PC? What about compatability with existing power supply,hard drive other components? What software is required? Thanks

So to answer your questions in order, No this board does not come with a processor. It's socket type is ONLY compatible with 4th generation intel processors. (these are more expensive and have a 4 at the beginning of their number sequence i.e i5 4670 etc.) You CAN physically replace a motherboard with your existing pc, but it has to match up with your pc's requirements, and your other hardware. if you posted a list of what you have then this question would be easy to answer. but in general this board will support most any DDR3 ram. You can find out what type of ram you have by phisically removing it (usually has a little sticker with info on it) or running a handy little program called CPU-Z (freeware) The only software you would need would be a windows OS. The board comes with driver tools both in cd form and in the BIOS menu when you boot up. Hope this answers your questions, I recently just completed my first build with this board and so far I absolutely love it. really great tools for overclocking and gaming features. As someone who recently had no experience with new mobos and hardware, I encourage you to check the compatibility of this mobo with other components, ie ram, cpu, graphics card, and psu. This board is for gamers and gamers who like to overclock and get more juice out of their pc. If that interests you, you gotta look at hardware that will allow you to overclock. There is a wealth of information and helpful dudes online especially at tomshardware forums who can help you out. Just find out and post your current components, or what you wanna build. Price out your upgrade/build on pcpartpicker as it automatically prices out compatible hardware. hope this helps, good luck!

Q: Does anyone know if this has onboard wi-fi and bluetooth?

It does NOT have on-board Wi-Fi or Bluetooth built in, you'd have to buy separate adpaters

Q: does this mobo suuport intel i5 4670k?

It sure does, it supports any 1150 socket chip which is anything currently under Intel's Haswell and upcoming Broadwell chips. Also that is the exact processor I have in my current setup :) highly recommend it as long as you get some type of aftermarket cooler.

Q: Has there been any bios upgrades since this was made? I am waiting for a 4770k to arrive and want to have everything ready for the build.

Latest BIOS release was 1.10 on Nov 20, 2013. A beta 1.10a was released on Nov 13 (yes, before the 1.10) claiming to improve i7 (non K) performance. ASRock's website for this board shows i7-4770k compatability since BIOS 1.0.

Q: I am really confused about where the power, and reset connectors go on this board, I can't seem to figure it out, I feel dumb for this but does anyone have a solution to my issue? Thanks

Upper right corner is where the reset and power LED connectors are located (orient the board with I/O USB, LAN, video to lower left). The manual included with the board has zoomed in diagrams. If you have good eyes or a magnifying glass, you can read the print on the board.

Q: Is this mother board compatible with ADATA XPG Gaming v2.0 Series 8Gb 240 pin ddr3 sdram ddr3 2400 (pc319200)? Thank you

Did you check the Memory support list? it can be found under the Support tab on ASROCK website. ADATA 8GB DDR3 2400 is on there list but you would need to know the full model number

Question 1

Does this mono come with 2-3 sata cables? And do I need a wireless card or is that on the mobo

Accepted Answer

Yes it came with a number of SATA cables, but there are plenty of good ones for cheap(~<= $1) on the Newegg site anyway (assuming you have free ship with shoprunner).

10/100/1000 Base T, no wireless.  Wireless is rare on a MOBO.  Just get one of the $20 deals for a router compatible with dd-wrt/tomato etc. and you can use that as an access point if you must.  It won't be anywhere near as fast as 1000 baseT though.

Question 2

Waiting to receive it. Will provide feedback of the build if I decide to keep it.

Q: I reviewed the rebate and it seems to want my password for my email. If that's the case I am not going to provide it for $20.
Am I wrong? What can I put in that space?

Accepted Answer

No,  it is not for your actual email.  It is for reference only and  tracking purposes.  Enter a made up password and use that for  log in to the track your rebate.

Question 3

Is it compatible with the AMD Fx-6300 Vishera 3.5ghz?

Accepted Answer

That would be a big negative.. This is a Intel Haswell LGA1150 motherboard. Its compatible with Haswell processors and some LGA1150 server side processors.

A AMD FX-6300 would only work on a AM3+ socket motherboard. I used to have a FX-6100 with an AM3+ motherboard myself, upgraded to a 4670k Haswell CPU with this particular motherboard, the difference is night and day..

Question 4

Is this board compatible with only 1 stick of ram or does it need 2? Please answer from personal experience!

Accepted Answer

As far as I know, [20 years of building and selling computers] ONE stick [must have two?] main boards went out in the 90s. I haven't seen any boards other than a few odd ball HPs, Gateways, and Compaqs back a few years ago that wouldn't run unless you had a matched pair or a dummy chip to make the connections. I bought two chips for this board and run them in the four slots [bank A & B] and that works fine. Perhaps one day I will expand it to the max. I thought I read if you run one chip, [and even a pair] set it in slot A? Also If you run two different sizes you MAY have to run them in different banks but that I cant swear on? Some boards don't count mis-matched sizes properly? If you need more I could locate the owners manual but from what I read it wasn't "one of those" that I have come across too many times, like the ones that you unplug and plug back in to "fix" the quirks?

Question 5

here are a few dumb questions from someone with no experience:
This motherboard comes with a processor?
Can i just replace this board in an existing tower PC?
What about compatability with existing power supply,hard drive other components?
What software is required?
Thanks

Accepted Answer

So to answer your questions in order,

No this board does not come with a processor. It's socket type is ONLY compatible with 4th generation intel processors. (these are more expensive and have a 4 at the beginning of their number sequence i.e i5 4670 etc.)

You CAN physically replace a motherboard with your existing pc, but it has to match up with your pc's requirements, and your other hardware. if you posted a list of what you have then this question would be easy to answer.

but in general this board will support most any DDR3 ram. You can find out what type of ram you have by phisically removing it (usually has a little sticker with info on it) or running a handy little program called CPU-Z (freeware)

The only software you would need would be a windows OS. The board comes with driver tools both in cd form and in the BIOS menu when you boot up.

Hope this answers your questions, I recently just completed my first build with this board and so far I absolutely love it. really great tools for overclocking and gaming features.

As someone who recently had no experience with new mobos and hardware, I encourage you to check the compatibility of this mobo with other components, ie ram, cpu, graphics card, and psu. This board is for gamers and gamers who like to overclock and get more juice out of their pc.

If that interests you, you gotta look at hardware that will allow you to overclock. There is a wealth of information and helpful dudes online especially at tomshardware forums who can help you out. Just find out and post your current components, or what you wanna build.

Price out your upgrade/build on pcpartpicker as it automatically prices out compatible hardware.

hope this helps,

good luck!

Question 6

Does anyone know if this has onboard wi-fi and bluetooth?

Accepted Answer

It does NOT have on-board Wi-Fi or Bluetooth built in, you'd have to buy separate adpaters

Question 7

does this mobo suuport intel i5 4670k?

Accepted Answer

It sure does, it supports any 1150 socket chip which is anything currently under Intel's Haswell and upcoming Broadwell chips.

Also that is the exact processor I have in my current setup :) highly recommend it as long as you get some type of aftermarket cooler.

Question 8

Has there been any bios upgrades since this was made? I am waiting for a 4770k to arrive and want to have everything ready for the build.

Accepted Answer

Latest BIOS release was 1.10 on Nov 20, 2013. A beta 1.10a was released on Nov 13 (yes, before the 1.10) claiming to improve i7 (non K) performance. ASRock's website for this board shows i7-4770k compatability since BIOS 1.0.

Question 9

I am really confused about where the power, and reset connectors go on this board, I can't seem to figure it out, I feel dumb for this but does anyone have a solution to my issue? Thanks

Accepted Answer

Upper right corner is where the reset and power LED connectors are located (orient the board with I/O USB, LAN, video to lower left).  The manual included with the board has zoomed in diagrams.  If you have good eyes or a magnifying glass, you can read the print on the board.

Question 10

Is this mother board compatible with ADATA XPG Gaming v2.0 Series 8Gb 240 pin ddr3 sdram ddr3 2400 (pc319200)? Thank you

Accepted Answer

Did you check the Memory support list?
it can be found under the Support tab on ASROCK website.

ADATA 8GB DDR3 2400 is on there list but you would need
to know the full model number

Brand	ASRock
Series	ASRock Fatal1ty Gaming
Model	Fatal1ty Z87 Killer

CPU Socket Type	LGA 1150
CPU Type	4th generation Corei7/i5/i3/Xeon/Pentium/Celeron(LGA 1150)
Supported CPU Technologies	Turbo Boost Technology 2.0

Number of Memory Slots	4x240pin
Memory Standard	DDR3 3050+(OC)/2800(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066
Maximum Memory Supported	32GB
Channel Supported	Dual Channel

PCI Express 3.0 x16	3 x PCI Express 3.0 x16 Slots (PCIE2/PCIE5/PCIE7: single at x16 (PCIE2); dual at x8 (PCIE2) / x8 (PCIE5); triple at x8 (PCIE2) / x4 (PCIE5) / x4 (PCIE7))
PCI Express x1	4 x PCI Express x1

Serial ATA (SATA)	6 x SATA 6Gb/s
SATA RAID	0/1/5/10

Meet Your Seller

ASRock ASRock Fatal1ty Gaming Fatal1ty Z87 Killer LGA 1150 Intel Z87 HDMI USB 3.0 ATX Intel Gaming Motherboard

Used - Very Good

ASRock Fatal1ty Z87 Killer LGA 1150 Intel Z87 HDMI SATA 6Gbps USB 3.0 ATX Intel Motherboard

Features

Learn more about the ASRock Fatal1ty Z87 Killer

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

LAN Chipset	Qualcomm Atheros Killer E2200 Series
Max LAN Speed	1Gbps

PS/2	1 x PS/2 keyboard/mouse port
Video Ports	1 x D-Sub 1 x DVI-D
HDMI	1 x HDMI-Out 1 x HDMI-In
USB 3.0	4 x USB 3.0
USB 1.1/2.0	3 x USB 2.0
S/PDIF Out	1 x Optical
Audio Ports	6 Ports

Onboard USB	2 x USB 3.0 + 4 x USB 2.0
Other Connectors	1 x IR Header 1 x COM Port Header 1 x Power LED Header 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin) 3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin) 1 x Power Fan Connector (3-pin) 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector (Hi-Density Power Connector) 1 x SLI/XFire Power Connector 1 x Front Panel Audio Connector

Onboard Audio
Audio Chipset	Realtek ALC1150
Audio Channels	7.1 Channels

Physical Spec
Form Factor	ATX
Power Pin	24 Pin
