Question 1

Does this board support PCIE bifurcation?

Accepted Answer

The ASRock X870 LiveMixer WiFi motherboard does not support PCIe bifurcation for its primary x16 slot. The primary PCIe 5.0 x16 slot (PCIE1) operates exclusively in x16 mode and does not share bandwidth with other slots.
According to ASRock's official product manual and specifications:
The PCIE1 slot is connected directly to the CPU and supports only x16 mode.
Other PCIe slots on the board are connected to the chipset and operate at lower bandwidths (e.g., PCIe 3.0 x1 or PCIe 4.0 x4).
A general trend noted for some ASRock X870/E boards is a lack of bifurcation support for the main GPU slot, a key consideration for users who need to split the lanes for multiple devices (like an M.2 expansion card).
You can verify these details on the official ASRock product page for the X870 LiveMixer WiFi or by consulting the manual's PCIe bandwidth table.

Question 2

What processors are compatible with this motherboard?

Accepted Answer

This motherboard is compatible with AMD Socket AM5 Ryzen 9000, 8000, and 7000 Series Processors.

Question 3

What are the audio features of this motherboard?

Accepted Answer

The motherboard features Realtek ALC4082 7.1 CH HD Audio Codec with Content Protection, Nahimic Audio, and individual PCB layers for R/L audio channel.

Question 4

How many RAM slots does the motherboard have and what type of RAM does it support?

Accepted Answer

The motherboard has 4 RAM slots and supports DDR5 RAM.

Question 5

Can I use this motherboard with Windows 11?

Accepted Answer

Yes, this motherboard supports Windows 11.

Question 6

Are there any specifications regarding the M.2 slots on this motherboard?

Accepted Answer

The motherboard includes 2 Blazing M.2 sockets supporting PCIe Gen5x4 and 2 Hyper M.2 sockets supporting PCIe Gen4x4.
