Brand | ASUS |
---|---|
Model | EN6200TC256/TD/64M |
Interface | PCI Express x16 |
---|
Chipset Manufacturer | NVIDIA |
---|---|
GPU | GeForce 6200TC |
Core Clock | 350 MHz |
PixelPipelines | 4 |
Effective Memory Clock | 550 MHz |
---|---|
Memory Size | 256MB(64MB on Board ) |
Memory Interface | 64-Bit |
Memory Type | DDR |
DirectX | DirectX 9 |
---|---|
OpenGL | OpenGL 1.5 |
D-SUB | 1 x D-SUB |
---|---|
DVI | 1 x DVI |
TV-Out | Composite Out |
VIVO | No |
Tuner | None |
---|---|
RAMDAC | 400MHz |
Max Resolution | 2048 x 1536 |
Cooler | Fanless |
Operating Systems Supported | Windows 2000/XP |
Features | NVIDIA TurboCache technology Microsoft DirectX 9.0 Shader Model 3.0 support NVIDIA CineFX 3.0 engine NVIDIA UltraShadow II technology NVIDIA Intellisample 3.0 technology NVIDIA PureVideo technology NVIDIA ForceWare Unified Driver Architecture (UDA) NVIDIA nView multi-display technology Vertex Shaders 3.0 Pixel Shaders 3.0 |
---|
Package Contents | EN6200TC256/TD/64M Driver Disk User Manual Software Disk |
---|
Date First Available | February 24, 2005 |
---|
Comments: Good card, as I've consitently found with ASUS - with one exception: Don't expect this card to have stand-alone dual monitor support. The DVI port is DVI-D - digital only, so you can only connect a dvi cable to it, not a vga-dvi adapter. I'm running it along with another pci video card and it's worked fine, however I had to install the drivers for the pci card BEFORE installing the asus driver. Quite a headache at the time, but I hope this helps someone else.
