ASUS ROG RAMPAGE VI APEX Intel LGA2066 DDR4 M.2 X299 EATX Motherboard

Chipset
Intel® X299
Memory
Intel® Core™ X-series Processors (6-core above)
4 x DIMM, Max. 64GB, DDR4 4133(O.C.)/4000(O.C.)/3866(O.C.)/3800(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2600(O.C.)/2400/2133 MHz Non-ECC, Un-buffered Memory
Intel® Core™ X-series Processors (4-core)
2 x DIMM, Max. 32GB, DDR4 4500(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3333(O.C.)/3300(O.C.)/3200(O.C.)/3000(O.C.)/2800(O.C.)/2666(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory
Multi-GPU Support
Supports NVIDIA® Quad-GPU SLI™ Technology
Supports NVIDIA® 4-Way SLI™ Technology
Supports NVIDIA® 3-Way SLI™ Technology
Supports NVIDIA® 2-Way SLI™ Technology
Supports AMD Quad-GPU CrossFireX™ Technology
Supports AMD 4-Way CrossFireX Technology
Supports AMD 3-Way CrossFireX™ Technology
Supports AMD 2-Way CrossFireX Technology
Expansion Slots
Intel® Core™ X-Series Processors Family
4 x PCIe 3.0 x16 *
Intel® X299 Chipset
1 x PCIe 3.0 x4
Storage
Intel® Core™ X-Series Processors Family :
1 x ROG DIMM.2 Module support(CPU_DIMM.2)*, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
2 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
Intel® X299 Chipset :
1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x ROG DIMM.2 Module support(PCH_DIMM.2)
Supports Intel® Smart Response Technology
Intel® Optane™ Memory Ready
LAN
Intel® I219V
Anti-surge LANGuard
Dual interconnect between the integrated Media Access Controller (MAC) and physical layer (PHY)
Wireless Data Network
Wi-Fi 802.11 a/b/g/n/ac
Supports dual band frequency 2.4/5 GHz
Supports MU-MIMO
Bluetooth
Bluetooth V4.2
Audio
ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
- Impedance sense for front and rear headphone outputs
- Supports : Jack-detection
- SupremeFX Shielding Technology
- Supports up to 32-Bit/192kHz playback
USB Ports
Intel® X299 Chipset :
6 x USB 3.1 Gen 1 port(s) (4 at mid-board)
Intel® X299 Chipset :
5 x USB 2.0 port(s) (3 at mid-board)
ASMedia® USB 3.1 Gen 2 controller :
1 x USB 3.1 Gen 2 front panel connector port(s)
ASMedia® USB 3.1 Gen 2 controller :
2 x USB 3.1 Gen 2 port(s)
ASMedia® USB 3.1 Gen 1 controller :
4 x USB 3.1 Gen 1 port(s)
ROG Exclusive Features
Clear CMOS button
ROG RAMCache II
ROG CPU-Z
ROG CloneDrive
MemOK! Button
Slow Mode
Overwolf
ReTry Button
Safe Boot Button
Start Button
Reset Button
LN2 Mode
ROG Aura
- Aura Lighting Control
- Aura RGB Strip Headers
Extreme Engine Digi+ :
- IR3555 PoweIRstage®
- MicroFine Alloy Chokes
- 10K Black Metallic Capacitors
Mem TweakIt
ROG Extreme OC kit :
- PCIe x16 Lane Switch
Double Power :
- Dual 8 -pin CPU
ProbeIt
UEFI BIOS features :
- O.C. Profile
- Tweakers' Paradise
- ROG SSD Secure Erase
Extreme Tweaker
USB BIOS Flashback
Special Features
OC Design - ASUS PRO Clock II Technology
5-Way Optimization by Dual Intelligent Processors
ASUS 5X Protection III :
Gamer's Guardian:
- DRAM Overcurrent Protection
- 10K Black Metallic Capacitors
- SafeSlot
ASUS EPU :

ASUS Protect Technology :
- Anti-Surge Protection
AURA :
- Aura Lighting Control
- Aura RGB Strip Headers
- Aura Lighting Effects Synchronization with compatible ASUS ROG devices
ASUS Exclusive Features :
- AI Suite 3
ASUS Quiet Thermal Solution :
- ASUS Fan Xpert 4
ASUS EZ DIY :
- ASUS MyLogo
ASUS Q-Design :
- ASUS Q-Shield
- ASUS Q-Code
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED, HDD LED)
- ASUS Q-Connector
Gaming Aesthetics :
- 3D printing friendly
- AURA-RGB Lighting
Operating System Support
Windows® 10
Internal I/O Ports
1 x VROC_HW_Key
