ASUS P5B SE LGA 775 Intel P965 Express ATX Intel Motherboard
- Intel P965 Express
- DDR2 800
Specs
Reviews (12)
Learn more about the ASUS P5B SE
| Brand | ASUS |
|---|---|
| Model | P5B SE |
| CPU Socket Type | LGA 775 |
|---|---|
| FSB | 1333(O.C)/1066 |
| Supported CPU Technologies | Hyper-Threading Technology |
| Chipset | Intel P965 Express |
|---|---|
| South Bridge | Intel ICH8 |
| Onboard Video Chipset | None |
|---|
| Number of Memory Slots | 4x240pin |
|---|---|
| Memory Standard | DDR2 800 |
| Maximum Memory Supported | 8GB |
| Channel Supported | Dual Channel |
| PCI Express x16 | 1 x PCI Express x16 |
|---|---|
| PCI Express x1 | 2 x PCI Express x1 |
| PCI Slots | 3 x PCI Slots |
| PATA | 1 x ATA100 2 Dev. Max |
|---|---|
| SATA RAID | RAID 0/1/JBOD, by 1x External & 1x internal SATA |
| Additional RAID Controller | JMB363 |
| Audio Chipset | Realtek ALC662 |
|---|---|
| Audio Channels | 6 Channels |
| Max LAN Speed | 1Gbps |
|---|
| Back I/O Ports | 1 x eSATA 3GB/S / 2 x PS/2 / 4 x USB 2.0/1.1 |
|---|---|
| PS/2 | 2 |
| COM | 1 |
| LPT | 1 |
| USB 1.1/2.0 | 4 x USB 2.0 |
| eSATA | 1 x eSATA 3Gb/s |
| Audio Ports | 3 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|
| Form Factor | ATX |
|---|---|
| Dimensions (W x L) | 12.0" x 7.4" |
| Power Pin | 24 Pin |
| Windows Vista | Certified for Windows Vista |
|---|
| First Listed on Newegg | September 19, 2007 |
|---|
