Brand | BIOSTAR |
---|---|
Model | A785G3 |
CPU Socket Type | AM3 |
---|---|
CPU Type | Phenom II / Athlon II / Sempron 100 Series Maximum CPU TDP (Thermal Design Power): 125Watt |
FSB | 2600 MHz |
Chipset | AMD 785G |
---|---|
South Bridge | AMD SB710 |
Number of Memory Slots | 2x240pin |
---|---|
Memory Standard | DDR3 800/1066/1333 |
Maximum Memory Supported | 8GB |
Channel Supported | Dual Channel |
PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
---|---|
PCI Slots | 2 x PCI Slots |
PATA | 1 x ATA133 2 Dev. Max |
---|---|
SATA 3Gb/s | 4 x SATA 3Gb/s |
SATA RAID | 0/1/10 |
Onboard Video Chipset | ATI Radeon HD 4200 |
---|
Audio Chipset | Realtek ALC662 |
---|---|
Audio Channels | 6 Channels |
LAN Chipset | Realtek 8111DL |
---|---|
Max LAN Speed | 10/100/1000Mbps |
PS/2 | 2 |
---|---|
Video Ports | D-Sub + DVI |
USB 1.1/2.0 | 4 x USB 2.0 |
Audio Ports | 3 Ports |
Onboard USB | 4 x USB 2.0 |
---|
Form Factor | Micro ATX |
---|---|
Dimensions (W x L) | 9.6" x 7.9" |
Power Pin | 24 Pin |
Features | Supports CPU up to 125W AMD OverDrive with ACC feature (Advanced Clock Calibration) supported |
---|
Date First Available | January 18, 2010 |
---|
Pros: Another great Biostar product bios has plenty of options got my Sempron 140 to 3780mhz stable onboard video is more then enough for me. Win 7 64 gives the video 4.4 for aero and 5.4 for gaming. Very stable setup this mobo Sempron 140 (3780mhz) Corsair 2gb ddr3 1333 onboard 4200 vid
Cons: Only 2 rams slots is a downer but I knew this when I bought it so I can't knock an egg off
