BIOSTAR COMBO6S3B AMD Sempron 130 AM3 NVIDIA MCP68S Micro ATX Motherboard / CPU Combo
- Phenom II / Athlon II / Sempron
- DDR3 800/1066/1333(supported by CPU model)
- NVIDIA GeForce 7025
Specs
Reviews (10)
Learn more about the Biostar COMBO6S3B
| Brand | BIOSTAR |
|---|---|
| Model | COMBO6S3B |
| Combo Type | Motherboard / CPU Combo |
| CPU | AMD Sempron 130 |
|---|---|
| With Cooler | Yes |
| CPU Socket Type | AM3 |
|---|---|
| CPU Type | Phenom II / Athlon II / Sempron |
| FSB | 1000 MHz |
| North Bridge | NVIDIA MCP68S |
|---|
| Number of Memory Slots | 2x240pin |
|---|---|
| Memory Standard | DDR3 800/1066/1333(supported by CPU model) |
| Maximum Memory Supported | 8GB |
| Channel Supported | Dual Channel |
| PCI Express x16 | 1 x PCI Express x16 |
|---|---|
| PCI Slots | 1 x PCI Slot |
| PATA | 1 x ATA 100 2 Dev. Max |
|---|---|
| SATA | 2 x SATA 3.0Gb/s |
| SATA RAID | 0/1 |
| Onboard Video Chipset | NVIDIA GeForce 7025 |
|---|
| Audio Chipset | VIA VT1708B |
|---|---|
| Audio Channels | 6 Channels |
| LAN Chipset | Realtek 8201CL |
|---|---|
| Max LAN Speed | 100Mbps |
| PS/2 | 2 |
|---|---|
| Video Ports | D-Sub |
| USB 1.1/2.0 | 4 x USB 2.0 |
| Audio Ports | 3 Ports |
| Onboard USB | 4 x USB 2.0 |
|---|
| Features | Maximum CPU TDP (Thermal Design Power) : 95Watt |
|---|
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 9.25" x 6.7" |
| Date First Available | June 01, 2011 |
|---|
