DIAMOND Radeon HD 3870 X2 1GB (512MB x 2) GDDR3 PCI Express x16 CrossFireX Support Graphics Card 3870X2PE31G

(30) Write a Review
  • 1GB (512MB x 2) 512-bit (256-bit x 2) GDDR3
  • Core Clock 825 MHZ
  • 2 x DVI 1 x HDMI (via Adapter)
  • 640 (320x2) Stream Processing Units
  • PCI Express x16
🔥Don't forget your OS, we have Windows 11 OEM, Download and USB versions available
Specs
Reviews (30)

Learn more about the Diamond Multimedia 3870X2PE31G

Model
Brand DIAMOND
Model 3870X2PE31G
Interface
Interface PCI Express x16
Chipset
Chipset Manufacturer AMD
GPU Radeon HD 3870 X2
Core Clock 825 MHZ
Stream Processors 640 (320x2) Stream Processing Units
Memory
Effective Memory Clock 1800 MHz
Memory Size 1GB (512MB x 2)
Memory Interface 512-bit (256-bit x 2)
Memory Type GDDR3
3D API
DirectX DirectX 10.1
OpenGL OpenGL 2.0
Ports
HDMI 1 x HDMI (via Adapter)
DVI 2 x DVI
TV-Out HDTV / S-Video Out
Details
RAMDAC 400MHz
Max Resolution 2560 x 1600
CrossFireX Support Yes
Cooler With Fan
Operating Systems Supported Windows XP with Service Pack 2 (SP2)
Windows Vista Ready
System Requirements AMD Athlon or Intel Pentium 4
PCI Express based PC is required with one X16 lane graphics slot available on the motherboard
450 Watt or greater power supply with 75 Watt 6-pin PCI Express power connector recommended (550 Watt for ATI CrossFireX with two 6-pin connectors)
1GB of system memory
Installation software requires CD-ROM drive
DVD playback requires DVD drive
Blu-ray / HD DVD playback requires Blu-ray / HD DVD drive
For a complete ATI CrossFireX system, a second ATI Radeon HD 3850 graphics card, an ATI CrossFireX Ready motherboard and one ATI CrossFireX Bridge Interconnect cable per board (included) are required
Power Connector 1 x 6-Pin + 1 x 8-Pin
Dual-Link DVI Supported Yes
Windows Vista Certified for Windows Vista
HDCP Ready Yes
Features
Features 55nm process technology
ATI Avivo HD Video and Display Technology
Game Physics processing capability
Up to 24X Custom Filter Anti-Aliasing
Built-in HDMI with Multi-channel 5.1 surround audio
Support for the ATI Radeon DVI to HDMI adapter
Unified Video Deoder (UVD) for Blu-ray and HD DVD
ATI PowerPlay energy conserving technology
Packaging
Package Contents 3870X2PE31G
Driver Disk
User Manual
HDTV Cable
DVI to VGA/D-sub Adapter
DVI to HDMI Adapter
CrossFire Bridge
Additional Information
First Listed on Newegg January 27, 2008

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 5 years
  • Limited Warranty period (labor): 5 years
  • Read full details

Return Policies

  • Return for refund within: 30 days
  • Return for replacement within: 30 days
  • This item is covered by Newegg.com's 30-Day Return Policy.
  • 15% restocking fee may apply.
  • Read full return policy for details.
