- Optimized Low 300 RPM
- Exclusive Enerflo Channel Blade For Ultra Silent Performance
- Patented Aluminum Modular Frame
T.B.SILENCE ADV - an ultra silent fan, inherits the outstanding silent performance of ENERMAX legendary T.B.SILENCE series. With the patented Twister Bearing and advanced electronic technologies, T.B.SILENCE ADV optimizes the start speed to as low as 300 RPM to deliver unparalleled silent performance. Moreover, the exclusive EnerfloTM channel blade design reduces the turbulence and increases the rotational stability.
- The exclusive Enerflo channel blade design reduces the turbulence and increases the rotational stability.
- Advanced aerodynamic blades incorporate precision engineering of the blade angle and shape calculation for ultra silent performance and low acoustic noise.
- Patented modular frame with premium aluminum ring reflects both luxurious and quality.
- Patented Twister Bearing technology.
Long life and low noise
Detachable blade for easy cleaning
- Vibration-damping rubber pads absorb the excessive vibration and noise.
| UCTBA14P | UCTBA12P | |
|---|---|---|
| Bearing Type | Twister Bearing | |
| MTBF | 160,000h @ 25℃ | |
| Number of Blades | 7 | |
| Fan Dimensions | 140 x 140 x 25mm | 120 x 120 x 25mm |
| Fan Speed | 300 – 1200RPM | 300 – 1500RPM |
| Rated Voltage | 12V | |
| Rated Current Fan | 0,25A | |
| Rated Current LED | – | |
| Fan Power Connector |
 4 pin PWM (GND/12V/Tacho/PWM) |
|
| Noise Level | 7 – 15.8dB(A) | 7 – 14.9dB(A) |
| Air Flow | 113.1m3/h (max.) | 108.55m3/h (max.) |
| Air Flow | 66.57CFM (max.) | 63.89CFM (max.) |
| Static Pressure | 1.63mm-H2O (max.) | 1.82mm-H2O (max.) |
| Included in the delivery | 4 x screw, 4-pin molex adapter | |
